BỘ GIAO THÔNG VẬN TẢI
CỤC HÀNG KHÔNG VIỆT NAM
_____________

Số: 1062/QĐ-CHK

CỘNG HÒA XÃ HỘI CHỦ NGHĨA VIỆT NAM
Độc lập - Tự do - Hạnh phúc

_____________

Hà Nội, ngày 13 tháng 05 năm 2024





QUYẾT ĐỊNH

Về việc phê duyệt ngân hàng câu hỏi thi sát hạch giấy phép, năng định

bảo dưỡng tàu bay B737NG và B737MAX

_________________________

CỤC TRƯỞNG CỤC HÀNG KHÔNG VIỆT NAM



Căn cứ Nghị định số 66/2015/NĐ-CP ngày 12/08/2015 của Chính phủ quy định về nhà chức trách hàng không;

Căn cứ Nghị định số 66/2015/NĐ-CP ngày 12/08/2015 của Chính phủ quy định về nhà chức trách hàng không;

Căn cứ Thông tư số 01/2011/TT-BGTVT ngày 27/01/2011 của Bộ trưởng Bộ Giao thông vận tải ban hành Bộ quy chế an toàn hàng không dân dụng lĩnh vực tàu bay và khai thác tàu bay và Thông tư số 03/2016/TT-BGTVT ngày 31/03/2016, Thông tư số 21/2017/TT-BGTVT ngày 30/6/2017, Thông tư số 56/2018/TT-BGTVT ngày 11/12/2018 và Thông tư số 42/2020/TT-BGTVT ngày 31/12/2020, Thông tư số11/2022/TT-BGTVT ngày 29/06/2022, Thông tư số 09/2023/TT-BGTVT ngày 09/06/2023 sửa đổi, bổ sung một số điều của Bộ quy chế an toàn hàng không dân dụng lĩnh vực tàu bay và khai thác tàu bay;

Căn cứ Quyết định số 651/QĐ-BGTVT ngày 29/05/2023 của Bộ trưởng Bộ Giao thông vận tải quy định chức năng, nhiệm vụ, quyền hạn và cơ cấu tổ chức của Cục Hàng không Việt Nam và quyết định số 371/QĐ-BGTVT ngày 02/04/2024 về việc sửa đổi quyết định 651/QĐ-BGTVT ngày 29/05/2023;

Theo đề nghị của Trưởng phòng Tiêu chuẩn an toàn bay – Cục Hàng không Việt Nam.



QUYẾT ĐỊNH:



Điều 1. Phê duyệt ngân hàng câu hỏi thi sát hạch giấy phép, năng định bảo dưỡng tàu bay B737NG và B737Max chi tiết nêu tại phụ lục I và II kèm theo.

Điều 2. Quyết định này có hiệu lực kể từ ngày ký.

Điều 3. Trưởng phòng Tiêu chuẩn an toàn bay- Cục Hàng không Việt Nam, Thủ trưởng các cơ quan, đơn vị và cá nhân liên quan chịu trách nhiệm thi hành Quyết định này.



Nơi nhận:
- Như Điều 3;
- Cục trưởng (để b/c);
- Lưu: VT, TCATB (Ph03b).

KT. CỤC TRƯỞNG
PHÓ CỤC TRƯỞNG




Hồ Minh Tấn





PHỤ LỤC I:

SỐ LƯỢNG CÂU HỎI THI SÁT HẠCH GIẤY PHÉP, NĂNG ĐỊNH

BẢO DƯỠNG TÀU BAY B737NG VÀ B737MAX

(kèm theo quyết định số 1062/QĐ-CHK ngày 13/05/2024)



Năng định tàu bay, động cơ

Số lượng câu hỏi

B737 NG (Boeing 737-

600/700/800/900) (CFM56)

1. Số lượng câu hỏi tàu bay mức A gồm 400 câu

2. Số lượng câu hỏi tàu bay mức B1 gồm 605 câu

3. Số lượng câu hỏi tàu bay mức B2 gồm 605 câu

4. Số lượng câu hỏi động cơ mức A gồm 54 câu

5. Số lượng câu hỏi động cơ mức B1gồm 100 câu

6. Số lượng câu hỏi động cơ mức B2 gồm 50 câu

B737 Max (Boeing 737-7/8/9)

(CFM LEAP-1B)

7. Số lượng câu hỏi tàu bay mức A gồm 400 câu

8. Số lượng câu hỏi tàu bay mức B1 gồm 605 câu

9. Số lượng câu hỏi tàu bay mức B2 gồm 604 câu

10. Số lượng câu hỏi động cơ mức A gồm 50 câu

11. Số lượng câu hỏi động cơ mức B1 gồm 101 câu

12. Số lượng câu hỏi động cơ mức B2 gồm 54 câu





PHỤ LỤC II:

CÁC BỘ CÂU HỎI THI SÁT HẠCH GIẤY PHÉP, NĂNG ĐỊNH

BẢO DƯỠNG TÀU BAY B737NG VÀ B737MAX

(kèm theo quyết định số 1062/QĐ-CHK ngày 13/05/2024)



A. QUESTION BANK FOR B737NG CAT A (AIRFRAME)

B. QUESTION BANK FOR B737NG CAT B1 (AIRFRAME)

C. QUESTION BANK FOR B737NG CAT B2 (AIRFRAME)

D. QUESTION BANK FOR CFM56 (B737NG) CAT A (ENGINE)

E. QUESTION BANK FOR CFM56 (B737NG) CAT B1 (ENGINE)

F. QUESTION BANK FOR CFM56 (B737NG) CAT B2 (ENGINE)

G. QUESTION BANK FOR B737MAX CAT A (AIRFRAME)

H. QUESTION BANK FOR B737MAX CAT B1 (AIRFRAME)

I. QUESTION BANK FOR B737MAX CAT B2 (AIRFRAME)

J. QUESTION BANK FOR CFM LEAP-1B (B737MAX) CAT A (ENGINE)

K. QUESTION BANK FOR CFM LEAP-1B (B737MAX) CAT B1 (ENGINE



A. QUESTION BANK FOR B737NG CAT A (AIRFRAME)



ATA 6:

1. The body station line (STA) is a

a) Lateral dimension

b) Horizontal dimension.

c) Height dimension.

(A) AMM TASK 06-21-00-800-801



2. The body buttock line (BL) is a

a) Lateral dimension

b) Height dimension

c) Horizontal dimension

(A) AMM TASK 06-21-00-800-801



3. The water line (WL) is a

a) Lateral dimension

b) Horizontal dimension.

c) Height dimension.

(A) AMM TASK 06-21-00-800-801



4. The airplane has

a) Eight major zones

b) Six major zones

c) Seven

(A) AMM TASK 06-30-00-800-801



5. The general left wing section base number is

a) 500

b) 600

c) 700

(A) AMM TASK 06-30-00-800-801



6. Location zone for Lower Half of Fuselage is

a) 100

b) 200

c) 300

(A) AMM TASK 06-30-00-800-801



7. Location zone for Landing Gear and Landing Gear Doors is

a) 600

b) 700

c) 800

(A) AMM TASK 06-30-00-800-801



8. Fuselage station diagram gives reference to find out components, features and major fuselage structural openings in relation to

a) Datum plane which is perpendicular to fuselage centerline and located 130.0 Inch forward of airplane nose

b) Nose of airplane

c) Floor of airplane passenger cabin

(A) AMM TASK 06-21-00-800-801



9. Major zone 200 is

a) Lower half of fuselage

b) Upper half of fuselage

c) L/H and R/H wing

(A) AMM TASK 06-30-00-800-801



ATA 7:

10. The airplane has

a) Three main jack points and four auxiliary jack points

b) Four main jack points and three auxiliary jack points.

c) Three main jack points and three auxiliary jack points (A) AMM TASK 07-11-01-580-815



12. Can the aircraft be jacked at axle jack points

a) Yes, at Max Zero Fuel Weight

b) Yes, At Max Taxi Weight

c) Not permitted

(A) AMM TASK 07-11-01-580-815



ATA 8:

13. The location of the inclinometers are in

a) main wheel gear well

b) the nose wheel well

c) The E & E compartment

(A) AMM TASK 08-21-04-000-801



ATA 9:

14. The design of the airplane will permit you to tow the airplane from

a) The nose landing gear

b) The main landing gear

c) The nose landing gear or main landing gear

(A) AMM TASK 09-11-00-580-801



15. The maximum normal towing turning limits are indicated by the painted stripes on

a) The lower fuselage below left pax door

b) The nose gear doors.

c) The lower fuselage below right pax door

(A) AMM TASK 09-11-00-580-801



16. When tow the aircraft, maximum normal turning angle is

a) 68 degrees

b) 78 degrees

c) 88 degrees

(A) AMM TASK 09-11-00 PAGE 206



17. What is the correct sequence

a) Install the tow bar on the tow fitting then install the tow lever safety pin

b) Install the tow lever safety pin then install the tow bar on the tow fitting

c) There is no specific sequence.

(A) AMM TASK 09-11-00 PAGE 204 & 205



ATA 10:

18. Prolonged Parking means

a) When an airplane is not operated for 7 days or more

b) When an airplane is not operated for 14 days or more

c) When an airplane is not operated for 30 days or more (A) AMM TASK 10-12-02-550-802



19. When aircraft stop overnight

a) Pitot probe and static port are covered.

b) Static port are covered

c) Pitot port are covered

(A) AMM TASK 10-11-01-580-801



ATA 12:

20. When you do the Aircraft Grounding for the Refuel/Defuel Operations

a) Connect the ground cable to parking ground point before you connect it to the aircraft

b) Attach the cable to aircraft first then connect to parking ground point

c) Grounding is not necessary

(A) AMM TASK 20-40-11-760-801



23. When doing the Hydraulic Fluid Reservoir Filling

a) The reservoirs air pressurize system must be depressurized

b) Do not depressurize the system reservoirs

c) The hydraulic system operating normally

(A) AMM TASK 12-12-00-610-801



ATA 20:

24. Which statement is NOT correct for Lockwire Procedure

a) Do not use lockwire more than twice

b) Install lockwire so it is in tension when the parts become loose

c) Make three to six twists at the end of the wire. Bend the twists back or under to give the ends protection so they will not catch something

(A) AMM 20-10-44



25. How to find out broken wire of control cable

a) rub along cable by hand to find out broken wire

b) rub along cable by a cloth, the cloth will catch any broken cable

c) remove cable

(A) AMM 20-20-31



26. What type of locking wire is to be used on emergency equipment

a) stainless steel wire

b) plastic tie

c) copper wire

(A) AMM 20-10-44



ATA 21:

27. On B737-800/900 which component controls pack cooling temperature?

a) Pack/zone temperature controller

b) Cabin temperature controller

c) Air conditioning accessory unit

(A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 12



28. On B737 800/900, these components in the EE compartment control the functions of the air conditioning system:

a) Two cabin temperature controller and two air conditioning accessory units (ACAU)

b) Two pack/zone temperature controllers and two air conditioning accessory units (ACAU)

c) Two pack/zone temperature controllers and two cabin pressure controller

(A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 12



29. On B737-800/900, the primary parts of the air conditioning (A/C) system are

a) Pack flow control, Pack cooling system, Zone temperature control, Air distribution.

b) Pack flow control, Pack/Zone temperature control, Recirculation, Air distribution.

c) Pack flow control, Pack cooling system, Zone temperature control, Recirculation, Air distribution.

(A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 19



30. On B737-800/900, the pack has overheat protection components that automatically stop operation of the pack, these are:

a) Compressor discharge overheat switch, Turbine inlet overheat switch, Pack discharge overheat switch.

b) Compressor discharge overheat switch, Turbine inlet overheat switch, Pack temp sensor.

c) Compressor discharge overheat switch, Ram air sensor, Pack discharge overheat switch. (A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 36



31. How to control and actuate the flow control and shutoff valve (FCSOV) ?

a) The FCSOV is electrically controlled and electrically actuated.

b) The FCSOV is electrically controlled and pneumatically actuated.

c) The FCSOV is pneumatically controlled and pneumatically actuated.

(A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 40



32. What is the primary heat exchanger used for ?

a) The primary heat exchanger removes heat from bleed air going to the compressor section of the air cycle machine.

b) The primary heat exchanger removes heat from bleed air that comes from the compressor section of the air cycle machine.

c) The primary heat exchanger removes heat from bleed air that comes from the reheater.

(A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 46



33. These are the three modes of control for the ram air system:

a) Open, Partial open, Close.

b) Ground, Takeoff/ Landing, Cruise.

c) Ground, Flight (flaps not up), Flight cruise (flaps up).

(A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 57, 61



34. The air cycle machine is a high-speed rotating assembly. It has these sections:

a) Turbine, Compressor and Ram air impeller fan.

b) Turbine and Compressor.

c) Turbine, Compressor and Gearbox.

(A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 64



35. What is the secondary heat exchanger used for ?

a) The secondary heat exchanger removes heat from bleed air going to the compressor section of the air cycle machine.

b) The secondary heat exchanger removes heat from bleed air that comes from the compressor section of the air cycle machine.

c) The secondary heat exchanger removes heat from bleed air that comes from pneumatic system.

(A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 80



36. How many water extractors are installed on B737-800/900 ?

a) There are four water extractors, two in each air conditioning pack

b) There are two water extractors, one in each air conditioning pack

c) This aircraft type does not use water extractor

(A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 88



37. What are the indications when a pack trip occurs on B737 800/900:

a) MASTER CAUTION and AIR COND annunciator lights.

b) PACK amber light, MASTER CAUTION and AIR COND annunciator lights.

c) PACK amber light and MASTER CAUTION lights.

(A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 114



38. The flight compartment gets conditioned air from

a) the right pack and the mix manifold.

b) the mix manifold.

c) the left pack and the mix manifold.

(A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 118



39. Where are the main air distribution components ?

a) in the distribution compartment aft of the forward cargo compartment.

b) in the distribution compartment in aft cargo compartment.

c) in the distribution compartment in avionic compartment.

(A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 122



40. On the temperature controls panel, which component controls the trim air pressure regulating and shutoff valve ?

a) The three temperature selectors

b) The trim air switch

c) The air temperature source selector

(A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 196



41. On B737 800/900, primary flight compartment zone temperature control channel is

a) a channel of ACAU.

b) a channel of LEFT pack/zone temperature controller.

c) a channel of RIGHT pack/zone temperature controller.

(A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 203



42. Which components are the interface between the normal temperature control system and the airplane safety logic ?

a) Two ACAUs.

b) Two pack/zone temperature controller.

c) Related ducting and wires.

(A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 221



43. What system removes heat from electronic components in the flight compartment and the E/E compartment ?

a) The ram air system

b) The equipment cooling system

c) The ventilation system

(A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 242



44. On the ground, to give a warning when there is not sufficient cooling air flow, the equipment cooling system has

a) indicator lights

b) the crew call horn

c) indicator lights and the crew call horn

(A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 248



45. The supply and exhaust fans move air around electrical equipment to remove heat. There are

a) two sets of fans (normal and alternate) for the supply and the exhaust systems

b) two fans for the supply and the exhaust systems

c) two fans (normal and alternate) for both supply and exhaust systems

(A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 252



46. These are the parts of the heating system:

a) Flight compartment heating, Supplemental heating and Aft cargo compartment heating

b) Forward cargo compartment heating, Supplemental heating and Aft cargo compartment heating

c) Flight compartment heating, Passenger compartment heating and Cargo compartment heating (A) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 274



47. The cabin pressure control system controls

a) the rate that the air flows into the cabin.

b) the rate that the air flows into and out of the cabin.

c) the rate that the air flows out of the cabin.

(A) Reference: ATA 21 Air conditioning system (2 of 2) - B737 Training book - Page 2



48. The CPCs show FAULT on the front panel display only when

a) there is an existing fault on cabin pressure control system.

b) there is a history fault on cabin pressure control system.

c) there is a fault on CPCs.

(A) Reference: ATA 21 Air conditioning system (2 of 2) - B737 Training book - Page 18



49. How many motors does the outflow valve have ?

a) three automatic mode motors

b) two automatic mode motors and one manual mode motor

c) one automatic mode motors and one manual mode motor

(A) Reference: ATA 21 Air conditioning system (2 of 2) - B737 Training book - Page 38



50. The amber AUTO FAIL light gives the flight crew an indication that

a) one auto channels are inoperative.

b) all auto channels are inoperative

c) one or both auto channels are inoperative.

(A) Reference: ATA 21 Air conditioning system (2 of 2) - B737 Training book - Page 45



51. The off schedule descent (OFF SCHED DESCENT) indication tells the crew that

a) the cabin pressure control system will control cabin pressure for a return to the take-off field.

b) the cabin pressure control system will turn off cabin pressure control in descent mode.

c) the cabin pressure control system turned off the schedule descent mode.

(A) Reference: ATA 21 Air conditioning system (2 of 2) - B737 Training book - Page 50



52. Which componets prevent damage to the airplane structure during sudden decompression in the cargo compartment.

a) The pressure equalization valves

b) The cargo compartment blowout panels

c) The negative pressure relief valve

(A) Reference: ATA 21 Air conditioning system (2 of 2) - B737 Training book - Page 60



53. The E & E compartment is cooled by?

a) The equipment cooling system

b) The ram air system

c) The AUTO or STANDBY pressurisation systems

(A) AMM 21-27-00 PAGE 2



54. The Re-circulating Fan air shroud is located

a) Forward of the E & E compartment.

b) Above the forward cargo compartment

c) Above the aft cargo compartment

(A) AMM 21-25-00



55. The Re-circulating Fan system provides?

a) A filtered air supply into the mix manifold

b) An unfiltered air supply into the mix manifold

c) An air supply directly from the mix manifold into the passenger cabin only

(A) AMM 21-25-00



56. The aft cargo compartment is heated by

a) The exhaust air from the control cabin

b) The exhaust air from the passenger cabin

c) The exhaust air from the E & E compartment

(A) AMM 21-40-00



ATA 22:

57. These are part of the stall management function of the SMYD:

a) Stall warning, EFS, Autoslat, Performance data.

b) Stall warning, Yaw damping, Autoslat, Performance data.

c) Stall warning, Turn coordination, Autoslat, Performance data.

(A) ATA 22 Autoflight system - B737 Training book - Page 13



58. You engage the yaw damper system with a switch on the flight control panel. These conditions are necessary for primary yaw damping:

a) The system A hydraulic pressure is available and the FLT CTRL A switch must be ON.

b) The system B hydraulic pressure is available and the FLT CTRL B switch must be ON.

c) The system A & B hydraulic pressure is available.

(A) ATA 22 Autoflight system - B737 Training book - Page 46



59. The wheel-to-rudder interconnect system (WTRIS) moves the rudder to help turns during flight control manual reversion

a) When on standby hydraulics.

b) When put the FLT CONT A or B switches to ON position.

c) When put the yaw damper switch to OFF.

(A) ATA 22 Autoflight system - B737 Training book - Page 58



60. The digital flight control system (DFCS) does these functions:

a) Autopilot, Flight director, Altitude alert, Speed trim, Mach trim, Autothrottle.

b) Autopilot, Flight director, Altitude alert, Speed trim, Mach trim.

c) Autopilot, Altitude alert, Speed trim, Mach trim, Autothrottle. (A) ATA 22 Autoflight system - B737 Training book - Page 93



61. When does the receivers use the VOR/LOC antenna in the vertical stabilizer ?

a) When the FCC is in the approach or localizer mode and a localizer frequency is selected on the navigation control panel.

b) When the FCC is in the approach or localizer mode and an ILS frequency is not selected on the navigation control panel.

c) Always use when the FCC is in the approach or localizer mode.

(A) ATA 22 Autoflight system - B737 Training book - Page 186



62. When does the receivers use the localizer antenna in the nose radome ?

a) When the FCC is in the approach or localizer mode and a localizer frequency is selected on the navigation control panel.

b) When the FCC is in the approach or localizer mode and an ILS frequency is not selected on the navigation control panel.

c) Always use when the FCC is in the approach or localizer mode.

(A) ATA 22 Autoflight system - B737 Training book - Page 186



63. The red A/T warning lights on the ASAs come on

a) Only when the A/T disconnects.

b) Only when the A/T is in BITE.

c) When the A/T disconnects or when the A/T is in BITE.

(A) ATA 22 Autoflight system - B737 Training book - Page 348



64. This is the takeoff sequence:

a) Preflight, Takeoff start, Takeoff roll, Climb out.

b) Preflight, Takeoff roll, Takeoff start, Climb out.

c) Preflight, Takeoff roll, Climb out, Takeoff start.

(A) ATA 22 Autoflight system - B737 Training book - Page 364



65. The localizer antenna switches

a) Turn ON/OFF the localizer antenna.

b) Determine if the dual VOR/LOC antenna or the localizer antenna is supplying the RF signals to the receivers.

c) Receive the localizer signal and send it directly to the localizer antenna.

(A) ATA 22 Autoflight system - B737 Training book - Page 186



66. When the crew push a TO/GA switch one time during a fully automatic approach

a) The autothrottle decreased thrust go-around mode operate.

b) The autothrottle maximum thrust go-around mode operate.

c) The autothrottle disengage.

(A) ATA 22 Autoflight system - B737 Training book - Page 381



ATA 23:

67. Where is the pilots audio selector panel located.

a) In Cockpit P8 panel

b) In Cockpit P8 and P6 panels

c) In cockpit Captain side only

(A) ATA 23 Communication System - B737 Training book - Page 36



68. The Cockpit Voice Recorder in AUTO:

a) Always powers the CVR when DC bus 1 is powered.

b) Always powers the CVR when DC bus 2 is powered.

c) Always powers the CVR from first engine start until 5 minutes after last engine shutdown.

(A) ATA 23 Communication System - B737 Training book - Page 387



69. Where is observer audio control panel?

a) On the P5 aft overhead panel or the P8 aft electronics panel

b) On the P5 aft overhead panel or the P11 fwd electronics panel

c) On the P8 aft electronics panel and P11 fwd electronics panel

(A) ATA 23 Communication System - B737 Training book - Page 36



70. The CVR (orange box) is located:

a) In the forward Electronic & Equipment bay (E&E).

b) In the aft right side of the aft cargo compartment.

c) In the flight deck (under the captain's seat).

(A) ATA 23 Communication System - B737 Training book - Page 368



71. Where are The REU and the audio switching relays?

a) Above overhead panel in the cabin compartment

b) on the E4-1 rack in Electronic Equipment Compartment

c) In the flight compartment

(A) ATA 23 Communication System - B737 Training book - Page 37



72. Where is the external flight interphone jack?

a) On the P19 external power panel

b) In the electronic equipment compartment

c) In the main wheel well

(A) ATA 23 Communication System - B737 Training book - Page 40



73. The Service Interphone switch on the Aft overhead panel when selected ON

a) Deactivates external jacks sockets from the Service Interphone system.

b) Allows communications between the flight deck and the flight attendants when using the Flight Interphone system.

c) Adds external jack sockets to the Service Interphone system.

(A) ATA 23 Communication System - B737 Training book - Page 83



74. The Cockpit CALL (blue) light will illuminate along with an associated chime whenever the cockpit is being called

a) By the flight attendants or the ground crew

b) By the ground crew only.

c) By the flight attendants only.

(A) ATA 23 Communication System - B737 Training book - Page 59, 91



75. To test the Cockpit Voice Recorder

a) Press the test CVR test switch and after a slight delay observe the Monitor Indicator rise into the red band.

b) Plug a headset into the jack socket in the CVR panel and press the Erase switch.

c) Press the test CVR test switch and after a slight delay observe the Monitor Indicator rise into the green band.

(A) ATA 23 Communication System - B737 Training book - Page 385



76. Where are the HF antenna couplers?

a) On the top of the vertical stabilizer

b) Inside the vertical stabilizer

c) On the E6 rack at the aft cargo compartment

(A) ATA 23 Communication System - B737 Training book - Page 184



77. Each radio communication panel can

a) Tune only one transceiver at a time

b) Tune all transceivers at a time

c) Tune only one transceiver

(A) ATA 23 Communication System - B737 Training book - Page 152



78. The ATTEND (attendants call) is pressed and released in the cockpit and

a) A HIGHT chime sound will be heard in the passenger cabin.

b) A LOW tone chime sound will be heard in the passenger cabin.

c) A HIGHT/LOW chime sound will be heard in the passenger cabin.

(A) ATA 23 Communication System - B737 Training book - Page 59



79. Where is observer audio control panel?

a) On the P5 aft overhead panel or the P8 aft electronics panel

b) On the P5 aft overhead panel or the P11 fwd electronics panel

c) On the P8 aft electronics panel and P11 fwd electronics panel

(A) ATA 23 Communication System - B737 Training book - Page 36



80. Communications between the cockpit and the ground crew is possible by using the

a) Flight interphone system or the Service Interphone system provided the Service Interphone switch is ON.

b) Flight interphone system only.

c) The Service interphone system irrespective of the position of the Service Interphone switch.

(A) ATA 23 Communication System - B737 Training book - Page 29,71



81. The VHF-1 transmitter selector switch on an audio selector panel is illuminated

a) Reception on VHF-1 is automatically provided

b) The ALT/NORM switch must be in NORM to obtain reception at a comfortable volume level.

c) Reception is achieved by pulling and rotating VHF-1 receiver switch.

(A) ATA 23 Communication System - B737 Training book - Page 162



82. Where are the service interphone jacks located.

a) External power only

b) At all flight attendance stations

c) C.APU, R&L W W, refuel station, external power, aft cabin rear ceiling, E&E, lower fuselage section 48.

(A) ATA 23 Communication System - B737 Training book - Page 82



83. The Cockpit Voice Recorder in ON:

a) Power the CVR and will go back to the AUTO position only when you put the switch to AUTO position

b) Power the CVR and will go back to AUTO position when you manual put switch to AUTO or when engine running relay energizes.

c) Power the CVR and will go back to AUTO position when you manual put switch to AUTO or when engine running relay de-energizes.

(A) ATA 23 Communication System - B737 Training book - Page 387



84. The selcal system monitors selected frequencies in use on the

a) HF communications radios.

b) HF and VHF communications radios.

c) VHF communications radios.

(A) ATA 23 Communication System - B737 Training book - Page 213



85. The cockpit voice recorder keeps

a) Last 25 hour of communication data in memory.

b) Last 60 minutes of communication data in memory

c) Last 120 minutes of communication data in memory.

(A) ATA 23 Communication System - B737 Training book - Page 358



ATA 24:

86. The GROUND POWER AVAILABLE light will extinguish when:

a) The GROUND POWER switch is positioned ON

b) The GROUND SERVICE switch is positioned ON

c) The AC ground power cart has been disconnected

(A) ATA 24 Electrical Power System - B737 Training book - Page 33



87. Generator Drive Disconnect switch when operated

a) Disconnects the Generator Drive from the engine in the event of a Generator Drive malfunction, only if the engine has been shut down first

b) Disconnects the Generator Drive from the engine in the event of a Generator Drive malfunction

c) Disconnects the CSD from the generator in the event of a Generator Drive malfunction

(A) ATA 24 Electrical Power System - B737 Training book - Page 81



88. Re-coupling of the Generator Drive drive shaft to the engine may be accomplished

a) At any time in flight provided the Generator Breaker and the Generator Control Relay have previously been tripped.

b) Only on the ground.

c) At any time on the ground or in flight.

(A) ATA 24 Electrical Power System - B737 Training book - Page 71



89. One of the basic principles of the electrical system is

a) The AC sources of power can be connected in parallel if necessary

b) There is no paralleling of the AC sources of power.

c) The AC sources of power are always connected in parallel.

(A) ATA 24 Electrical Power System - B737 Training book - Page 91



90. When both engines are running with external power connected then

a) External power will automatically disconnect when both engine generators are brought on line.

b) External power must be selected OFF before the engine generators are brought on-line.

c) External power will automatically disconnect when either engine generator is brought on-line.

(A) ATA 24 Electrical Power System - B737 Training book - Page 91,110



91. An engine electrical generator is rated at

a) 90 KVA

b) 45 KVA

c) 55 KVA

(A) ATA 24 Electrical Power System - B737 Training book - Page 9



92. To connect the External Ground power to the aircraft's Generator busses

a) The Battery switch must be OFF

b) The Battery switch must be ON.

c) The Bus Transfer switch must be in the AUTO position

(A) ATA 24 Electrical Power System - B737 Training book - Page 59



94. The 115V AC Standby Bus is powered by:

a) The 115V Transfer Bus No.1 under normal conditions.

b) The Battery Bus through the Static Inverter under normal conditions.

c) The Battery through the Static Inverter with a failure of both engine driven generators.

(A) ATA 24 Electrical Power System - B737 Training book - Page 172



95. Illumination of the GND POWER AVAILABLE light indicates:

a) The Ground Service Bus is powered by a ground power supply.

b) Ground power is connected however no airplane power quality is measured.

c) Ground power is connected and meets airplane power quality standards.

(A) ATA 24 Electrical Power System - B737 Training book - Page 33



96. The switched hot battery bus is powered whenever:

a) Transfer bus 1 is powered.

b) AC ground service bus is powered.

c) The battery switch is ON.

(A) ATA 24 Electrical Power System - B737 Training book - Page 25



97. After an overload situation has been resolved, how do you recover the galley buses?

a) It happens automatically.

b) Move the CAB/UTIL switch to OFF then ON.

c) A ground engineer should reselect the appropriate switch in the E/E

(A) ATA 24 Electrical Power System - B737 Training book - Page 190



98. To connect the External Ground power to the aircraft's Generator busses

a) The Battery switch must be OFF

b) The Battery switch must be ON.

c) The Bus Transfer switch must be in the AUTO position

(A) ATA 24 Electrical Power System - B737 Training book - Page 59



99. The APU generator has

a) A Generator drive unit which will disconnect when the APU Generator drive disconnect switch is activated from the flight deck.

b) A Generator drive unit which will automatically disconnect when its oil temperature is high.

c) No Generator drive unit since the APU itself is governed and will maintain a constant generator speed.

(A) ATA 24 Electrical Power System - B737 Training book - Page 118



100. To have all three Generators (APU and engines) on-line simultaneously

a) Is possible in flight only.

b) Is not possible.

c) Is possible on the ground only.

(A) ATA 24 Electrical Power System - B737 Training book - Page 91



101. Under normal conditions the Standby AC bus is energised from the

a) 115-volt Transfer bus No. 1

b) 115-volt Transfer bus No. 2

c) The Static Invertor.

(A) ATA 24 Electrical Power System - B737 Training book - Page 21



102. If ground power is available and the Ground Service switch on the forward attendant's panel is switched on, then power is supplied to

a) All the aircraft electrical busses.

b) The Ground Service bus for utility outlets, cabin lighting and battery charger.

c) The Ground Service bus for utility outlets and cabin lighting only

(A) ATA 24 Electrical Power System - B737 Training book - Page 22



103. The TR UNIT will illuminate in flight if:

a) Any TR unit fails.

b) TR1 fails or TR2 and TR3 fail.

c) TR2 fails.

(A) ATA 24 Electrical Power System - B737 Training book - Page 25



104. The ELEC light will illuminate in flight if:

a) A fault exists in the AC or Standby power system.

b) A fault exists in the AC, DC or the Standby system.

c) The ELEC light only operates on the ground.

(A) ATA 24 Electrical Power System - B737 Training book - Page 25



105. What is the purpose of the GROUND SERVICE switch?

a) Provide automatic control of ground handling bus.

b) Provide manual control of ground service bus.

c) Provide automatic control of ground service bus.

(A) ATA 24 Electrical Power System - B737 Training book - Page 22



106. Illumination of the STANDBY POWER OFF light indicates:

a) DC bus 1 unpowered

b) DC bus 2 unpowered

c) AC standby bus unpowered

(A) ATA 24 Electrical Power System - B737 Training book - Page 29



107. The purpose of the DC BUS tie relay is to:

a) Isolate DC bus 1 and DC bus 2

b) Connect DC bus 1 and DC bus 2

c) Disconnect TR1 and TR3

(A) ATA 24 Electrical Power System - B737 Training book - Page 147



108. With the STANDBY switch in the AUTO position, battery switch ON, the loss of all engine or APU electrical power results in the automatic switching from the normal power source to the alternate source for standby power:

a) On the ground only.

b) Either inflight or on the ground.

c) Will not occur.

(A) ATA 24 Electrical Power System - B737 Training book - Page 177



109. The constant speed drive (CSD):

a) Are not use in this A/C

b) Turn the generator at variable speed

c) Turn the generator at constant speed

(A) ATA 24 Electrical Power System - B737 Training book - Page 81



110. DC Standby Bus power is normally supplied from

a) The Battery Bus

b) The Hot Battery Bus

c) DC Bus No. 1

(A) ATA 24 Electrical Power System - B737 Training book - Page 13



ATA 25:

111. The captain and first officer seats are

a) Difference

b) Oppsite assemblies

c) Identical

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 6



112. The fight compartment seats are

a) Manually control

b) Electrically control

c) Manually and electrically control

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 6-7



113. How many observer seat can be installed?

a) One observer seat

b) Two observer seats

c) Three observer seats

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 9



114. The first and second observer seats are

a) Adjustable seats

b) Non-adjustable seats

c) Identical

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 9



115. In passenger cabin the service outlets provide

a) 115 Volt ac

b) 28 Volt dc power

c) 115 Volt ac and 28 Volt dc power

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 11



116. Where are the escape slides installed?

a) On the lower inboard face of each entry and service door

b) On the lower inboard face of each entry and emergency exit door

c) On the lower inboard face of each entry, service and emergency exit door

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 42



117. Put the slide warning pennant across the door window when

a) The slide is armed

b) The slide is dis-armed

c) The slide is Unserviceable

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 43



118. To ARM the escape slide

a) Move the ARM-DISARM handle to ARM position

b) Remove the girt bar from the stowage hooks on the door and install it in the floor brackets

c) Remove the girt bar from the floor brackets and install it in the stowage hooks

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 45



119. The lowered ceiling panels are installed in

a) Entry areas and lavatories

b) Entry areas and galleys

c) Entry areas, galleys and lavatories

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 14



120. Fiberglass insulation blankets are

a) Thermally insulates the passenger compartment

b) Acoustically insulates the passenger compartment

c) Thermally and acoustically insulates the passenger compartment

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 14-15



121. Emergency equipment typically includes

a) Overwing escape strap, Escape lanyards, Overwater survival equipment, Escape slides

b) Overwing escape strap, Escape lanyards, Detachable emergency equipment, Escape slides

c) Overwing escape strap, Escape lanyards, Overwater survival equipment, Detachable emergency equipment, Escape slides

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 35



122. Where are the overwing escape straps?

a) In stowage tubes above each emergency exit door

b) In stowage tubes above each entry door

c) In stowage tube above the flight compartment door

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 37



123. The escape lanyard kevlar cord rated at

a) 1000 pounds

b) 1500 pounds

c) 2000 pounds

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 39



124. Where are the escape lanyard located?

a) In the stowage bag behind doors in the flight compartment lining above the number 2 windows

b) In the stowage bag above the flight compartment door

c) In the stowage bag below the second observer seat

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 39



125. Where are the escape slides installed?

a) On the lower inboard face of each entry and service door

b) On the lower inboard face of each entry and emergency exit door

c) On the lower inboard face of each entry, service and emergency exit door

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 42



126. Put the slide warning pennant across the door window when

a) The slide is armed

b) The slide is dis-armed

c) The slide is Unserviceable

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 43



127. If the escape slide does not inflate automatically

a) Pull the inflation handle sharply to inflate the escape slide manually

b) Push the inflation handle to inflate the escape slide manually

c) Push and pull the inflation handle to inflate the escape slide manually

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 45



128. The escape slide will fully inflate in

a) Approximately 03 seconds

b) Approximately 06 seconds

c) Approximately 10 seconds

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 45



129. The inflation cylinder pressure relief valve opens at

a) 3500 PSIG

b) 4000 PSIG

c) 4500 PSIG

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 49



130. How do you check an escape slide cylinder pressure?

a) The pressure indicator

b) The pop out indicator on ACP

c) The bottle must be removed and weighted

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 49



131. How to deflate the slide after inflation test?

a) Open the pressure relief valve

b) Open the deflation valve

c) Hold the aspirator flapper valve open

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 49



132. The escape slide light system power by

a) The 28 Volts dc BAT BUS

b) The 28 Volts dc HOT BAT BUS

c) Its own battery

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 51



133. Which equipment protects the escape slide inflation cylinder from hight temperature?

a) The fusible plug

b) The pressure relief valve

c) The frangible disk

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 49



134. What precaution should be taken when removing a door escape slide?

a) Install the safety pin

b) Remove the safety pin

c) Remove the airplane power

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 49



135. The air return grilles

a) Let air move from the upper lobe to the lower lobe for normal conditioned air circulation

b) Let air move from the upper lobe to the lower lobe for air circulation during rapid decompression

c) Let air move from the upper lobe to the lower lobe for normal conditioned air circulation or air circulation during rapid decompression

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 19



136. The passenger service units provide

a) Emergency oxygen and advisory information

b) Emergency oxygen and call switches

c) Emergency oxygen, advisory information and call switches

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 21



137. How to open the passenger service units?

a) Insert a small allen wrench or other applicable tool into the latch release hole, then lower the service unit

b) Push the passenger service units up to release the latch, then lower the service unit

c) Remove the lanyard then lower the service unit

(A) ATA 25 Equipments and Furnishings system - B737 Training book - Page 21



ATA 26:

138. The fire protection systems monitor the airplane for these conditions:

a) Fire, Smoke, Overheat, Pneumatic duct leaks.

b) Fire, Smoke, Overheat.

c) Fire, Smoke, Pneumatic duct leaks.

(A) Reference: ATA 26 Fire protection system - B737 Training book - Page 6



139. The fire alarms provide visual and aural indication to the flight crew about a fire in any of

Engine, APU and

a) Avionic compartment, Forward cargo compartment, Aft cargo compartment and Main wheel well.

b) Forward cargo compartment, Aft cargo compartment and Main wheel well.

c) Forward cargo compartment, Aft cargo compartment and Avionic compartment.

(A) Reference: ATA 26 Fire protection system - B737 Training book - Page 8



140. How many engine fire detectors in each engine ?

a) Six detectors.

b) Fours detectors.

c) Eight detectors.

(A) Reference: ATA 26 Fire protection system - B737 Training book - Page 16



141. Which components monitor detectors for overheat and fire conditions on the engine and fire conditions on the APU.

a) The engine and APU fire detection module.

b) The engine and APU fire detection controller.

c) The engine fire detection unit and APU fire detection unit.

(A) Reference: ATA 26 Fire protection system - B737 Training book - Page 18



142. The FAULT/INOP test does

a) a check of the module overheat and fire detection circuitry and flight compartment indications.

b) a check of the module fault detection circuitry and related flight compartment indications.

c) a check of the module fault and fire detection circuitry and related flight compartment indications.

(A) Reference: ATA 26 Fire protection system - B737 Training book - Page 21



143. How many fire extinguisher bottles supply the halon to engine ?

a) Two fire extinguisher bottles supply the halon to each engine (04 bottles for 02 engines).

b) One fire extinguisher bottles supply the halon to one engine (02 bottles for 02 engines).

c) Two fire extinguisher bottles supply the halon to either engine (02 bottles for 02 engines).

(A) Reference: ATA 26 Fire protection system - B737 Training book - Page 24



144. How many APU fire detectors ?

a) Two detectors.

b) Three detectors.

c) Four detectors.

(A) Reference: ATA 26 Fire protection system - B737 Training book - Page 46



145. The APU fire extinguishing bottle is in

a) The horizontal stabilizer accessory compartment

b) The APU compartment foward bulkhead

c) Right hand side of aft cargo compartment

(A) Reference: ATA 26 Fire protection system - B737 Training book - Page 50, 54



146. When you pull the APU fire control handle on APU ground control panel (P28)

a) The APU system stops and APU fire extinguisher bottle discharges

b) The APU continute operates but isolates from other systems

c) The APU system stops and arm the fire extinguisher toggle switch

(A) Reference: ATA 26 Fire protection system - B737 Training book - Page 58



147. If the detector senses smoke or heat, a signal goes to

a) the cargo smoke detection module.

b) the cargo electronic unit.

c) the cargo smoke detection unit.

(A) Reference: ATA 26 Fire protection system - B737 Training book - Page 64



148. When smoke is detected in a lavatory,

a) the smoke detection system gives aural alarm.

b) the smoke detection system gives aural and visual alarm indications.

c) the smoke detection system gives visual alarm indications.

(A) Reference: ATA 26 Fire protection system - B737 Training book - Page 98



149. The lavatory fire extinguishing systems are

a) in the ceiling of each lavatory.

b) in the side wall panel of each lavatory.

c) in the lavatories below the wash basin.

(A) Reference: ATA 26 Fire protection system - B737 Training book - Page 106



150. The wheel well fire detection system uses

a) overheat sensing elements in the main wheel well.

b) fire detector in the main wheel well.

c) smoke detector in the main wheel well.

(A) Reference: ATA 26 Fire protection system - B737 Training book - Page 108



151. Which component monitors sensing elements for overheat and fire conditions in the wheel well and the wing and body areas ?

a) The wheel well and wing detection module.

b) The compartment overheat detection unit.

c) The compartment overheat detection controller.

(A) Reference: ATA 26 Fire protection system - B737 Training book - Page 114



ATA 27:

152. The primary flight control system has these components:

a) Ailerons, Elevators and Rudder.

b) Ailerons, Horizontal Stabiliser, Elevators and Rudder.

c) Ailerons, Spoilers, Elevators and Rudder.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 10



153. The secondary flight control system has these components:

a) Leading edge devices, Trailing edge flaps, Spoilers and speedbrakes.

b) Leading edge devices, Trailing edge flaps, Spoilers and speedbrakes and Horizontal stabilizer

c) Leading edge devices, Trailing edge flaps and Horizontal stabilizer

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 10



154. Which component controls manual operation of the ailerons and flight spoilers ?

a) The rudder pedals

b) The elevator control column

c) The aileron control wheel

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 17



155. Where is the stabilizer electric trim switch ?

a) It is on the outboard side of each control wheel.

b) It is on the top of the elevator control column.

c) It is on the P5 aft overhead panel

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 17



156. Where are the aileron trim switches ?

a) The switches are on the outboard side of each control wheel.

b) The switches are on the aileron/rudder trim panel on the aft electronic P8 panel.

c) The switches are on the top of the elevator control column.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 20



157. The flight crew uses two control wheels for

a) pitch control operation.

b) yaw control operation.

c) roll control operation.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 50



158. How many Spoiler on each wing ?

a) Six. There is one spoiler inboard of each engine strut and five spoilers outboard of each engine strut.

b) Five. There is two spoiler inboard of each engine strut and three spoilers outboard of each engine strut.

c) Six. There is two spoiler inboard of each engine strut and four spoilers outboard of each engine strut.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 78



159. How many ground spoiler on each wing ?

a) Four. The ground spoilers are two outboard and two inboard spoiler on each wing.

b) Two. The ground spoilers are the most outboard and the most inboard spoiler on each wing.

c) One. The ground spoilers are the most inboard spoiler on each wing.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 78



160. On manual operation, the flight spoiler control system receives inputs from

a) the control columns and the control wheels.

b) the pedal and the speedbrake lever.

c) the control wheels and the speedbrake lever.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 84



161. The Flight Spoiler actuators are powered by

a) The hydraulic system A.

b) The hydraulic system B.

c) The hydraulic systems A or B.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 102



162. Which module controls the automatic operation of the speedbrakes ?

a) Flight control computer

b) The auto speedbrake module

c) Antiskid/autobrake control unit

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 115



163. The SPEED BRAKE ARMED light shows when

a) the automatic operation of the speedbrake system arms correctly.

b) the speedbrake lever in ARMED position.

c) the SPEED BRAKE ARM function inoperatived.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 116



164. The Ground Spoiler actuators are powered by

a) Both hydraulic systems A and B.

b) The hydraulic system A.

c) The hydraulic system B.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 118



165. Which component lets the ground spoilers operate only when the airplane is on the ground ?

a) PSEU

b) The auto speedbrake module

c) The ground spoiler interlock valve

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 143



166. During stabilizer electric trim operation, if the pilot moves the control column in the opposite direction,

a) the column cutout switches stop the stabilizer electric trim.

b) the stabilizer electric trim will change to the opposite direction.

c) the stabilizer electric trim keeps priority and continues to operation.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 165



167. These are the elevator controls and indications in the flight compartment:

a) Elevator control wheel, FLIGHT CONTROL switches and Elevator FEEL DIFF PRESS light.

b) Elevator control columns, FLIGHT CONTROL switches and Elevator FEEL DIFF PRESS light.

c) Elevator control columns, Elevator trim switches and Elevator FEEL DIFF PRESS light.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 168



168. Where is the elevator feel computer ?

a) The elevator feel computer is in forward equipment compartment.

b) The elevator feel computer is in aft cargo compartment.

c) The elevator feel computer is on the aft right wall of the stabilizer compartment.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 186



169. The elevator feel computer receives hydraulic pressure, mechanical inputs and

a) pitot pressure.

b) data from ADIRU.

c) data form FCC.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 193



170. These are the stabilizer controls in the flight compartment:

a) Stabilizer trim wheels, Stabilizer trim cutout switches and Stabilizer trim override switch.

b) Stabilizer trim switches, Stabilizer trim wheels, Stabilizer trim cutout switches and Stabilizer trim override switch.

c) Stabilizer trim switches, Stabilizer trim wheels and Stabilizer trim override switch.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 216



171. How to control the rudder in manual operation ?

a) The pilot uses the rudder pedals to control the rudder.

b) The pilot uses the rudder pedals or control column to control the rudder.

c) The pilot uses the rudder pedals or the rudder trim control to control the rudder.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 241



172. Which components make the command to move the TE flaps ?

a) The flap lever for normal operation and the ALTERNATE FLAPS switches for alternate operation.

b) The FSEU for normal operation and the flap lever for alternate operation.

c) The FSEU for normal operation and the ALTERNATE fLAPS switches for alternate operation.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 283



173. Flap position indication is a function of

a) Flap Control Unit

b) FSEU

c) PSEU

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 296



174. During the normal operation, if two or more LE devices move away from their commanded position,

a) LE devices automatically switch to alternate operation.

b) the LE cruise depressurization function prevents extension of the LE flaps and slats.

c) the LE UCM detection function stops the LE normal operation.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 429



175. During the normal operation, if the airplane comes near a stall condition,

a) the autoslat function causes the LE slats to move from the extend position to the full extend position.

b) the LE UCM detection function stops the LE normal operation.

c) the LE cruise depressurization function prevents extension of the LE flaps and slats.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 429



176. During the alternate operation, what functions are not available.

a) the LE flaps extension function, LE UCM detection function and autoslat function

b) the LE cruise depressurization function, LE UCM detection function and autoslat function

c) the LE cruise depressurization function and autoslat function

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 429



177. How many positions can the LE flaps and slats move to ?

a) two positions.

b) The LE flaps move to two positions, and the LE slats move to three positions.

c) three positions.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 429



178. During normal operation, the LE flap and slat actuators use power from

a) hydraulic system A.

b) hydraulic system A or B.

c) hydraulic system B.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 433



179. Why does the LE devices annunciator panel have only the transit and extend lights for the LE flaps but has all three types of lights for the LE slats ?

a) Because the LE flaps have only two positions.

b) Because the LE flaps only need to indicate the transit and extend positions.

c) Because the LE devices annunciator panel doesn't have enough place to indicate more.

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 438



180. Which computers calculate the autoslat commands ?

a) FSEU

b) SMYD.

c) FCC

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 458



181. The takeoff warning function is in

a) PSEU

b) FCC

c) SMYD

(A) Reference: ATA 27 Flight controls - B737 Training book - Page 470



ATA 28:

182. A SHUT-OFF SYSTEM IS USED DURING REFUELLING TO

a) AUTOMATICALLY CLOSE THE MANUAL DEFUELLING VALVE WHEN THE WING TANKS ARE FULL.

b) AUTOMATICALLY CLOSE THE FUELLING VALVE IN EACH FUEL TANK WHEN THE TANK IS FULL.

c) PREVENT REFUELLING PRESSURES IN EXCESS OF 50 PSI.

(A) SDS-AMM 28-21-00 PAGE4/18



183. TO DEFUEL NO. 1 TANK

a) SELECT THE NO. 1 MAIN TANK FUEL PUMPS ON, THE CROSSFEED VALVE OPEN AND THE MANUAL DEFUELLING VALVE OPEN.

b) SELECT THE NO. 1 MAIN TANK FUEL PUMPS ON, THE CROSSFEED VALVE CLOSED AND THE MANUAL DEFUELLING VALVE OPEN.

c) SELECT THE NO. 1 AND NO. 2 MAIN TANK FUEL PUMPS ON, THE CROSSFEED VALVE OPEN AND THE MANUAL DEFUELLING VALVE OPEN.

(A) AMM TASK28-26-00



184. THE FUEL TEMPERATURE INDICATOR READS THE TEMPERATURE OF THE FUEL IN

a) THE CENTRE TANK

b) THE NO. 2 TANK.

c) THE NO. 1 TANK.

(A) SDS-AMM 28-00-00 PAGE4



185. THE MANUAL DE-FUELLING VALVE IS LOCATED

a) OUTBOARD OF THE NO. 2 ENGINE

b) OUTBOARD OF THE NO. 1 ENGINE.

c) INBOARD OF THE NO. 2 ENGINE

(A) SDS-AMM 28-26-00 PAGE6



186. DRIPSTICKS (OR FLOATSTICKS) ARE INSTALLED IN

a) 5 IN EACH MAIN TANK AND 2 IN THE CENTRE TANK

b) 7 IN EACH MAIN TANK AND 6 IN THE CENTRE TANK.

c) 6 IN EACH MAIN TANK AND 4 IN THE CENTRE TANK (A) SDS-AMM 28-44-00 PAGE2



187. THE FUELLING VALVE POSITION LIGHTS ON THE EXTERNAL FUELING PANEL ILLUMINATE (BLUE) WHEN

a) THE RESPECTIVE FUELLING VALVE IS IN TRANSIT

b) THE RESPECTIVE FUELLING VALVE IS OPEN AND FUEL IS BEING TRANSFERRED INTO THE TANK.

c) THERE IS POWER TO THE RESPECTIVE FUELLING VALVE SOLENOID

(A) SDS-AMM 28-21-00 PAGE12&22



188. WHEN THE APU IS INOPERATIVE AND NO EXTERNAL POWER IS AVAILABLE, REFUELLING CAN BE ACCOMPLISHED AS FOLLOWS

a) BATTERY SWITCH ON, STANDBY POWER SWITCH BAT, THE ENTIRE FUEL SYSTEM WILL OPERATE NORMALLY

b) BATTERY SWITCH OFF, STANDBY POWER SWITCH BAT, THE ENTIRE FUEL SYSTEM WILL OPERATE NORMALLY

c) BATTERY SWITCH ON,STANDBY POWER SWITCH BAT, THE ENTIRE FUEL SYSTEM WILL OPERATE NORMALLY, EXCEPT FOR THE FUEL SHUT-OFF SYSTEM.

(A) SDS-AMM 28-21-00 PAGE 22



189. TO DEFUEL NO. 2 TANK ONLY

a) SELECT THE NO. 1 AND NO. 2 MAIN TANK FUEL PUMPS ON, THE CROSSFEED VALVE OPEN AND THE MANUAL DEFUELING VALVE OPEN.

b) SELECT THE NO. 2 MAIN TANK FUEL PUMPS ON, THE CROSSFEED VALVE OPEN AND THE MANUAL DEFUELING VALVE OPEN.

c) SELECT THE NO. 2 MAIN TANK FUEL PUMPS ON AND THE MANUAL DEFUELLING VALVE OPEN

(A) SDS-AMM 28-26-00 PAGE 10



190. THE CROSSFEED VALVE WHEN OPEN

a) CLOSES THE BYPASS VALVE IN EACH WING TANK.

b) ALLOWS TRANSFER OF FUEL BETWEEN WING TANKS ONLY.

c) ALLOWS FUEL TRANSFER FROM ANY TANK TO EITHER ENGINE OR APU.

(A) SDS-AMM 28-22-00 PAGE 26



191. THE CROSSFEED SELECTOR IN THE OPEN POSITION

a) EXTINGUISHES THE BLUE VALVE OPEN LIGHT

b) CONNECTS THE ENGINE NO 1 AND NO. 2 FUEL FEED LINES BY OPENING THE FUEL CROSSFEED AND FUEL SHUT-OFF VALVES.

c) CONNECTS THE ENGINE NO 1 AND NO. 2 FUEL FEED LINES BY OPENING THE FUEL CROSSFEED VALVE.

(A) SDS-AMM 28-22-00 PAGE 26&28



192. THE CENTRE TANK FUELLING VALVE POSITION LIGHT ON THE EXTERNAL FUELLING PANEL IS

a) BLUE AND IS ILLUMINATED WHEN THE CENTRE TANK FUELLING VALVE IS CLOSED.

b) BLUE AND IS EXTINGUISHED WHEN THE CENTRE TANK FUELLING VALVE IS CLOSED.

c) RED AND IS EXTINGUISHED WHEN THE CENTRE TANK FUELLING VALVE IS CLOSED.

(A) SDS-AMM 28-21-00 PAGE12&22



193. THE EXTERNAL FUELLING PANEL IS LOCATED

a) ON THE OPPOSITE WING TO THE DE-FUELLING PANEL.

b) AT THE LEFT WING LEADING EDGE

c) AT THE RIGHT WING LEADING EDGE.

(A) SDS-AMM 28-00-00 PAGE4



194. EACH FUEL TANK CONTAINS

a) 1 AC POWERED FUEL PUMPS WHICH IS FUEL COOLED AND LUBRICATED, AND 1 DC FUEL PUMP.

b) 2 DC POWERED FUEL PUMPS.

c) 2 AC POWERED FUEL PUMPS WHICH ARE FUEL COOLED AND LUBRICATED.

(A) SDS-AMM 28-22-00 PAGE 14;20 & 22



195. WHICH VALVE CONNECTS THE FUEL (ENGINE 2) MANIFOLD TO THE FUELLING MANIFOLD

a) THE CROSSFEED VALVE

b) THE FUELLING VALVE

c) THE MANUAL DEFUELLING VALVE.

(A) SDS-AMM 28-26-00 PAGE 8



196. THE ENGINE FUEL SHUT OFF VALVES

a) ARE CABLE OPERATED TO CLOSE OR OPEN.

b) ARE HOT BATTERY BUS POWERED AND MAY BE CLOSED BY THE ENGINE START LEVER OR THE RESPECTIVE ENGINE FIRE SWITCH.

c) ARE AC OPERATED TO OPEN, AND MECHANICALLY CLOSED BY THE ENGINE START LEVER OR FIRE SWITCH.

(A) SDS-AMM 28-22-00 PAGE 32 & 33



ATA 29:

197. IF AN ELECTRIC HYDRAULIC PUMP OVERHEAT LIGHT COMES ON

a) THE PUMP WILL BE AUTOMATICALLY SWITCHED OFF AND THE OVERHEAT LIGHT EXTINGUISHED

b) TURN THE ASSOCIATED SYSTEM ELECTRIC AND ENGINE HYDRAULIC PUMPS OFF.

c) TURN THE ASSOCIATED SYSTEM ELECTRIC HYDRAULIC PUMP OFF.

(A) SDS-AMM 29-10-00 PAGE 6



198. THE STANDBY SYSTEM LOW PRESSURE LIGHT IS ARMED

a) ONLY WHEN THE STANDBY PUMP OPERATION HAS BEEN SELECTED OR AUTOMATIC STANDBY FUNCTION IS ACTIVATED.

b) AT ALL TIMES.

c) ONLY WHEN THE STANDBY PUMP OPERATION HAS BEEN SELECTED OR EITHER SPOILER SWITCH HAS BEEN SELECTED TO OFF.

(A) SDS-AMM 29-30-00 PAGE 28



199. THE STANDBY HYDRAULIC PUMP ONLY SUPPLIES PRESSURE TO THE

a) STANDBY RUDDER AND LEADING EDGE SLATS.

b) STANDBY RUDDER ACTUATOR, LEADING EDGE DEVICES AND THRUST REVERSERS.

c) STANDBY RUDDER, LEADING EDGE DEVICES AND BRAKES.

(A) SDS-AMM 29-22-00 PAGE 4



200. IF EITHER FLIGHT CONTROL SWITCH IS MOVED TO THE STBY RUD POSITION

a) THE STANDBY PUMP WILL BE ACTIVATED AND THE STANDBY HYDRAULIC LOW QUANTITY LIGHT WILL BE ARMED

b) THE STANDBY PUMP WILL BE DE-ACTIVATED ALLOWING SYSTEM A PRESSURE TO POWER THE RUDDER AND THE STANDBY HYDRAULIC LOW PRESSURE LIGHT WILL BE ARMED.

c) THE STANDBY PUMP WILL BE ACTIVATED AND THE STANDBY HYDRAULIC LOW PRESSURE LIGHT WILL BE ARMED.

(A) SDS-AMM 29-22-00 PAGE 21



201. LOW FLUID QUANTITY IN THE RESERVOIR OF SYSTEM A OR B CAN BE INDICATED BY ONE OF THE FOLLOWING

a) MECHANICAL INDICATION ON THE RESERVOIR

b) LOW QUANTITY LIGHT ON THE CENTRE INSTRUMENT PANEL

c) LOW QUANTITY LIGHT ON THE CENTRE INSTRUMENT PANEL ALONG WITH A MASTER CAUTION ENG ANNUNCIATOR LIGHT.

(A) SDS-AMM 29-10-00 PAGE 8



202. THE A AND B HYDRAULIC RESERVOIRS ARE PRESSURISED BY

a) AIR FROM THE 14TH STAGE ONLY.

b) AIR FROM THE PNEUMATIC MANIFOLD.

c) HYDRAULIC FLUID FROM THE STANDBY RESERVOIR.

(A) SDS-AMM 29-09-00 PAGE 2



203. SELECTING AN ENGINE DRIVEN HYDRAULIC PUMP SWITCH TO OFF WILL

a) ELECTRICALLY CLOSE THE FLUID SUPPLY VALVE AT THE RESERVOIR.

b) DE-ACTIVATE THE SOLENOID-HELD BLOCKING VALVE AND ISOLATE FLUID FROM THE USING UNIT.

c) ACTIVATE THE SOLENOID-HELD BLOCKING VALVE AND ISOLATE FLUID FROM THE USING UNIT.

(A) SDS-AMM 29-10-00 PAGE 6



204. THE NORMAL AND MAXIMUM READINGS ON THE HYDRAULIC SYSTEM PRESSURE INDICATOR ARE

a) 3000 : 3500PSI

b) 2500 : 3200PSI

c) 3000 : 3750PSI

(A) SDS-AMM 29-10-00 PAGE 1 & 21



205. THE STANDBY HYDRAULIC RESERVOIR IS KEPT TOPPED UP FROM

a) OIL CONTAINERS USED BY ENGINEERS BEFORE EACH FLIGHT.

b) THE SYSTEM A RESERVOIR c) THE SYSTEM B RESERVOIR.

(A) SDS-AMM 29-22-00 PAGE 8



206. HYDRAULIC SYSTEM A POWER SOURCES ARE

a) ONE ENGINE DRIVEN PUMP (ENG 1) AND ONE ELECTRICAL MOTOR PUMP (ELECT 1).

b) ONE ENGINE DRIVEN PUMP (ENG 1) AND ONE ELECTRICAL MOTOR PUMP (ELECT 2).

c) ONE ENGINE DRIVEN PUMP (ENG 1), ONE ELECTRICAL MOTOR PUMP (ELECT 1) AND ONE STANDBY ELECTRIC PUMP.

(A) SDS-AMM 29-10-00 PAGE 6



207. ILLUMINATION OF A HYDRAULIC ELECTRIC PUMP OVERHEAT LIGHT INDICATES

a) AN OVERHEAT CONDITION IN THE HYDRAULIC RESERVOIR.

b) AN OVERHEAT CONDITION OF THE PUMP HYDRAULIC SUPPLY LINE.

c) AN OVERHEAT CONDITION IN THE CASE DRAIN LINE OR THE PUMP HOUSING.

(A) SDS-AMM 29-30-00 PAGE 30



208. THE MAXIMUM HYDRAULIC SYSTEM A OR B PRESSURE IS

a) 3000PSI

b) 3250PSI

c) 3500PSI

(A) SDS-AMM 29-10-00 PAGE 21



209. THE STANDBY HYDRAULIC FLUID

a) IS COOLED BY A HEAT EXCHANGER LOCATED IN NO. 2 TANK.

b) IS COOLED BY A HEAT EXCHANGER LOCATED IN NO. 1 TANK.

c) IS NOT COOLED

(A) SDS-AMM 29-22-00 PAGE 10



210. THE ENGINE DRIVEN HYDRAULIC PUMP SWITCH

a) IN THE OFF POSITION WILL DE-ACTIVATE THE HYDRAULIC LOW PRESS LIGHT.

b) IS LEFT IN THE ON POSITION ON SHUTDOWN TO PROLONG THE LIFE OF THE BLOCKING VALVE SOLENOID.

c) SHOULD BE SWITCHED OFF IN THE EVENT OF THE ELECTRIC HYDRAULIC PUMP OVERHEAT LIGHT ILLUMINATING

(A) SDS-AMM 29-10-00 PAGE 6



ATA 30:

211. THERE ARE 8 ELECTRICALLY HEATED PITOT PRESSURE, ALPHA VANE AND TAT PROBES ON THE AIRPLANE. HOW MANY SWITCHES CONTROL THE SYSTEM?

a) 8

b) 2

c) 4

(A) STORMAVIATION-30-30 PAGE 40



212. WHICH SLATS HAVE ANTI-ICING PROTECTION?

a) ALL SLATS HAVE ANTI-ICING PROTECTION

b) THREE INBOARD LEADING EDGE SLATS OF THE WING

c) THREE OUTBOARD LEADING EDGE SLATS OF THE WING

(A) STORMAVIATION-30-11 PAGE 8



213. WHAT IS INDICATED BY FOUR AMBER WINDOW OVERHEAT LIGHTS ON THE WINDOWS ANTI-ICING PANEL?

a) THEY GIVE THE CREW VISUAL INDICATION OF APPLY CURRENT TO THE WINDOW HEAT SYSTEM WHEN NECESSARY

b) THEY GIVE INDICATION OF OVERHEAT CONDITION ON No1 AND No2 WINDOWS

c) THEY GIVE THE CREW VISUAL INDICATION OF OVERHEAT CONDITIONS FOR THE No1, 2, 3 AND 4 WINDOWS

(A) STORMAVIATION-30-41 PAGE 58



214. WHEN WILL THE WING THERMAL ANTI-ICE (WTAI) VALVES OPEN

a) WHEN THE THRUST LEVERS ARE LESS THAN 60 TRA

b) WHEN THE AIRPLANE IS ON THE GROUND AND OVERHEAT CONDITION OCCURS

c) ANY TIME WHEN THE WING ANTI-ICE SWITCH IS IN THE ON POSITION

(A) STORMAVIATION-30-11 PAGE 24



215. THE BLUE VALVE OPEN LIGHT ON THE ENGINE AND WING ANTI-ICE PANEL (P5) ILLUMINATES BRIGHT. WHAT DOES IT MEAN?

a) THE SWITCH POSITION AND VALVE POSITION DISAGREE, OR THE VALVE IS IN TRANSIT

b) THE SWITCH IS IN THE OFF POSITION, AND THE VALVE IS CLOSED

c) THE SWITCH IS IN THE ON POSITION, AND THE VALVE IS FULLY OPEN

(A) STORMAVIATION-30-11 PAGE 24



216. WHICH PROBES ARE CONTROLED BY THE PROBE HEAT B SWITCH?

a) FIRST OFFICER PITOT, RIGHT ELEVATOR PITOT, RIGHT ALPHA VANE, AUXILARY PITOT

b) COWL THERMAL ANTI-ICE, AIR DATA PROBE, TOTAL AIR TEMPERATURE (TAT) PROBE

c) CAPTAIN PITOT, LEFT ELEVATOR PITOT, LEFT ALPHA VANE, TOTAL AIR TEMPERATURE (TAT) PROBE

(A) STORMAVIATION-30-30 PAGE 40



217. WITH THE THRUST RESOLVER ANGLE GREATER THAN 60 DEGREES, WHAT IS THE EFFECT ON THE ANTI-ICE SYSTEM?

a) WING ANTI-ICE SOLENOID VALVE IS USED TO GIVE MAXIMUM COOLING

b) WING ANTI-ICE SHUTOFF VALVES ARE SIGNALLED FULLY CLOSED

c) ANTI-ICE BLEED AIR FLOW RATE IS REDUCED

(A) STORMAVIATION-30-11 PAGE 24



218. WHICH WINDOW(S) ARE HEATED WITH THE LEFT FWD WINDOW HEAT SWITCH ON?

a) L1, L2, L3

b) L2, L4, L5

c) L1 ONLY

(A) STORMAVIATION-30-41 PAGE 58



219. THE WINDOW HEAT ON LIGHT (GREEN) ILLUMINATES TO INDICATE

a) THE ASSOCIATED WINDOW HEAT SWITCH HAS BEEN SELECTED TO OVHT TEST.

b) THE WINDOW HEAT CONTROLLER IS APPLYING HEAT TO THE ASSOCIATED WINDOW

c) THE ASSOCIATED WINDOW HEAT SWITCH IS POSITIONED TO ON.

(A) STORMAVIATION-30-41 PAGE 58



220. THE COWL ANTI-ICE LIGHT IS

a) AMBER IN COLOUR, INDICATING OVER-TEMPERATURE ONLY.

b) AMBER IN COLOUR, INDICATING OVER-PRESSURE ONLY.

c) AMBER IN COLOUR, INDICATING OVER-TEMPERATURE OR OVER-PRESSURE.

(A) STORMAVIATION-30-20 PAGE 28



ATA 31:

221. AT POWER UP, EACH DISPLAY UNIT (DU) READS THE POSITION PINS (PIN PROGRAMING) AND CALCULATES ITS POSITION. IF A DU FAILS TO READ THE POSITION PINS, THEN:

a) IT WILL BE BLANK

b) THE MESSAGE "DU FAIL" WILL APPEAR ON THE DU

c) A WHITE DIAGONAL LINE WILL BE VISIBLE

(A) STORMAVIATION 31-62 PAGE 72



222. WITH WHICH UNIT DOES THE PRINTER HAVE AN INTERFACE?

a) ACARS MANAGEMENT UNIT AND FDAU (FLIGHT DATA ACQUISITION UNIT)

b) FDAU (FLIGHT DATA ACQUISITION UNIT) AND FMS

c) FDAU (FLIGHT DATA ACQUISITION UNIT) AND DEU (A) STORMAVIATION 31-62 PAGE 182



223. WHEN PERFORMING THE "DU LOOP TEST", A WHITE HIGHLIGHT BOX SHOWS AROUND ONE OF THE COAX CABLE INPUTS (e.g. Y[Y]YN) TO THE DISPLAY UNIT (DU). WHAT IS THE MEANING OF THIS INDICATION?

a) COAX CABLE INPUT ACTIVITY(THE SPECIFIC COAX CABLE THAT IS CURRENTLY BEING USED BY THE DU)

b) THIS COAX CABLE INPUT HAS A FAILURE

c) THIS COAX CABLE INPUT IS CURRENTLY INACTIVE

(A) STORMAVIATION 31-62 PAGE 124



224. WHAT IS THE PURPOSE OF THE 28VDC "HOLD UP" VOLTAGE?

a) ALL 6 DISPLAY UNIT (DU) USE THIS AS A BACK OF TRANSIENT CONDITION OF UP TO 10 SECONDS

b) THE DISPLAY ELECTRONICS UNIT (DEU) AND DUs USE THIS WHEN OPERATING ON STANDBY POWER

c) THE DEUs UES THIS FOR TRANSIENT CONDITIONS (POWER INTERRUPTIONS) OF UP TO 1 SECOND AND FOR ORDERLY SHUTDOWN OF THE PROCESSORS (UP TO 10 SECONDS)

(A) STORMAVIATION 31-62 PAGE 24



225. IF THE CONTROL PANEL SELECT SWITCH WAS SET TO BOTH ON 1 POSITION, WHICH OF THE FOLLOWING STATEMENTS IS TRUE?

a) CAPTAIN'S EFIS CONTROL PANEL CONTROLS THE CAPTAIN AND THE FIRST OFFICER'S PFD AND ND DISPLAYS

b) FIRST OFFICER'S EFIS CONTROL PANEL CONTROLS THE CAPTAIN AND THE FIRST OFFICER'S PFD AND ND DISPLAYS

c) CAPTAIN'S CONTROL & DISPLAY UNIT (CDU) CONTROLS THE CAPTAIN AND THE FIRST OFFICER'S PFD AND ND DISPLAYS

(A) STORMAVIATION 31-62 PAGE 95



226. IF THE DISPLAY ELECTRONICS UNIT (DEU) No2 FAIL THEN

a) COAX COUPLER No1 & 3, WILL SWITCH THEIR INPUT TO DEU NO1 AUTOMATICALLY

b) COAX COUPLERS No3 & 4 WILL LOSE THEIR INPUT

c) ONE INPUT IS LOST FOR EACH ONE OF THE FOUR COAX COUPLER UNIT

(A) STORMAVIATION 31-62 PAGE 26 & 27



227. WHEN THE AIRPLANE IS IN THE AIR, THE AURAL WARNING SYSTEM WILL PROVIDE A TAKE-OFF WARNING, IF

a) LEADING EDGE (LE) FLAPS AND SLATS ARE NOT EXTENDED AND TAKE-OFF INTERLOCK VALVE IS CLOSED

b) LEADING EDGE (LE) & TRAILING EDGE (TE) FLAPS AND SLATS ARE RETRACTED AND GROUND SPOILER INTERLOCK VALVE IS CLOSED

c) LEADING EDGE (LE) FLAPS ARE NOT EXTENDED AND GROUND SPOILER INTERLOCK VALVE IS OPENED

(A) STORMAVIATION 31-50 PAGE 248



228. THE IRS MASTER CAUTION UNIT PROVIDES DISCRETE INPUTS TO THE

a) MASTER CAUTION SYSTEM

b) MULTI MODE RECEIVERS

c) AUDIO WARNING UNIT

(A) STORMAVIATION 31-50 PAGE 218



229. WHAT IS THE SOURCE OF UTC DATE AND TIME FOR THE CLOCKS

a) DISPLAY ELECTRONICS UNIT (DEU)

b) FLIGHT MANEGEMENT COMPUTER (FMC)

c) MULTI MODE RECEIVER (MMR)

(A) STORMAVIATION 31-25 PAGE 196



230. FLIGHT DATA RECORDER (FDR) SYSTEM IS NORMAL NOT POWER ON THE GROUND. HOW IS IT POSSIBLE TO POWER IT ON GROUND FOR MAINTENANCE PURPOSES?

a) PLACING THE "TEST/NORMAL" SWITCH, ON THE FLIGHT RECORDER/MACH AIRSPEED WARNING TEST MODULE, TO THE "TEST" POSITION

b) PLACING THE "TEST/NORMAL" SWITCH, ON THE FLIGHT RECORDER/MACH AIRSPEED WARNING TEST MODULE, TO THE "NORMAL" POSITION, WHITE THE "AIR/GROUND WARN" CIRCUIT BREAKER ON THE P6 PANEL IS PULLED OUT

c) PLACING THE "TEST" SWITCH ON THE FDR'S FRONT FACE TO THE "ON" POSITION

(A) STORMAVIATION 31-62 PAGE 160



ATA 32:

231. VARIOUS AIRPLANE SYSTEMS USE COMMANDS AIR-GROUND RELAYS. WHICH COMPONENT GIVES DISCRETE SIGNAL TO THE AIR-GROUND RELAYS?

a) AIR-GROUND SENSORS

b) THE LANDING GEAR LOGIC SHELF

c) THE PROXIMITY SWITCH ELECTRONICS UNIT

(A) SDS-AMM 32-09-00 PAGE 16



232. THE AMBER PSEU LIGHT ON THE P5 PANEL COMES ON FOLLOWING BY THE MASTER CAUTION AND OVHD AMBER ANNUNCIATOR LIGHT AFTER LANDING AND EXTINGUISHES IMMEDIATELY AFTER PARKING BRAKE HAS BEEN SET. WHAT DOES IT MEAN?

a) NON-DISPATCHABLE FAULT HAS BEEN SENSED BY THE PSEU

b) DISPATCHABLE FAULT HAS BEEN SENSED BY THE PSEU

c) PSEU IS IN OVERRIDE CONDITION

(A) SDS-AMM 32-09-00 PAGE 40



233. THERE ARE THREE BITE TESTS YOU DO ON THE SUPPLEMENTAL PROXIMITY SWITCH ELECTRONICS UNIT (SPSEU) 1. THEY CAN BE DONE BY USING:

a) FRONT PANEL BITE ON THE PSEU

b) THE BITE CONTROLS AND INDICATION ON THE FRONT OF THE SPSEU

c) SPSEU GROUND TEST MENU THROUGH FMS CDU

(A) SDS-AMM 32=64-00 PAGE 10



234. THE GEAR WARNING HORN CAN ONLY BE CANCELLED IF

a) FLAPS ARE LESS THAN 10 AND RA ALT IS BETWEEN 200 AND 800 FEET

b) FLAPS ARE LESS THAN 15 AND THRUST LEVERS AT IDLE

c) FLAPS ARE GREATER THAN 25 BELOW 800 FEET

(A) SDS-AMM 32-61-00 PAGE 20



235. COMPLETE THE SENTENCE. HYDRAULIC PRESSURE FOR NOSE WHEEL STEERING TO THE STEERING METERING VALVE COMES:

a) DIRECTLY FROM HYDRAULIC SYSTEM A

b) FROM EXTEND PRESSURE LINE FROM THE LANDING GEAR EXTENSION AND RETRACTION SYSTEM

c) FROM B OR STANDBY HYDRAULIC SYSTEM, AS SELECTED BY LANDING GEAR TRANSFER VALVE

(A) SDS-AMM 32-51-00 PAGE 1



236. THE RUDDER PEDALS MOVEMENT DON'T INFLUENCE NOSE WHEEL STEERING, WHEN AIRCRAFT IS IN AIR. HOW IT IS ACHIEVED?

a) PSEU GIVES ELECTRIC SIGNAL TO STEERING SHUTOFF VALVE, IF AIR MODE IS DETECTED

b) THE ROTARY ACTUATOR DISENGAGES THE RUDDER PEDAL STEERING IN THE AIR

c) SWIVEL VALVE CUTS OFF HYDRAULIC PRESSURE, WHEN NOSE LANDING GEAR RETRACTS

(A) SDS-AMM 32-51-00 PAGE 2



237. WHAT HAPPENS IF STEERING WHEEL AND RUDDER PEDALS GIVE INPUT SIMULTANEOUSLY?

a) INPUTS WILL BE ADDED TOGETHER ALGEBRAICALLY

b) STEERING WHEEL INPUT WILL BE ACCOMPLISHED

c) RUDDER PEDAL INPUT WILL BE ACCOMPLISHED (A) SDS-AMM 32-51-00 PAGE 12



238. FROM WHERE DOES HYDRAULIC PRESSURE COME TO TAIL SKID ACTUATOR?

a) B OR STANDBY HYDRAULIC SYSTEM, AS SELECTED BY LANDING TRANSFER VALVE

b) EXTEND PRESSURE LINE FROM THE LANDING GEAR EXTENSION AND RETRACTION SYSTEM

c) THE SYSTEM A FLIGHT CONTROL HYDRAULIC MODULE PACKAGE

(A) SDS-AMM 32-71-01 PAGE 10



239. WHEN USING THE PSEU (PROXIMITY SENSING ELECTRONICS UNIT) BITE MENU, WHERE IS THE SENSOR RIGGING INFORMATION FOUND?

a) OTHER FUNCTIONS

b) INPUT/OUTPUT MONITORS

c) GROUND TEST

(A) SDS-AMM 32-09-00 PAGE 66



240. HOW MANY SENSORS ARE USED FOR THE AIR-GROUND SYSTEM?

a) 6

b) 3

c) 4

(A) SDS-AMM 32-09-00 PAGE 8



241. HOW IS THE PARKING BRAKE SHUTOFF VALVE POWERED?

a) HOT BATTERY BUS

b) DC BUS 1

c) 28V AC TRANSFER BUS

(A) SDS-AMM 32-44-00 PAGE 14



242. THE FUNCTION OF THE COMPENSATOR IN THE NOSE WHEEL STEERING SYSTEM IS TO:

a) ENSURE THE ACTUATORS STAY IN THEIR CURRENT POSITIONS WHEN THERE IS NO INPUT

b) ENHANCE SHIMMY DAMPING

c) PREVENT VIOLENT TURNING OF THE NOSE GEAR

(A) SDS-AMM 32-51-00 PAGE 14



243. IN THE GEAR AUDIO WARNING SYSTEM, RADIO ALTIMETER DATA IS SUPPLIED BY THE:

a) DISPLAY ELECTRONIC UNITS

b) FLIGHT CONTROL COMPUTERS

c) RADIO ALTIMETER RECEIVER (A) SDS-AMM 32-61-00 PAGE 23



244. WHEN THE LANDING GEAR LEVER IS OPERATED, WHICH OF THE FOLLOWING CORRECTLY DESCRIBES THE SYSTEM OPERATION?

a) AN ELECTRICAL SIGNAL IS SEND TO THE PSEU WHICH ELECTRICALLY RELEASES THE UPLOCKS IN THE PREDETERMINED SEQUENCE

b) A PUSH-PULL CABLE OPERATES THE LANDING GEAR SELECTOR AND THEN THE

TRANSFER VALVES

c) A RELEASE CABLE OPERATES THE UPLOCKS AND THE TRANSFER VALVE

(A) SDS-AMM 32-31-00 PAGE 6



245. IN AN UPLOCK SENSOR FAILED, WHICH POSITION WOULD IT FAIL IN?

a) NEAR OR FAR DEPENDING ON WHEN IT FAILED

b) ALWAYS FAIL FAR ELECTRICALLY

c) OPERATIONAL

(A) SDS-AMM 32-09-00 PAGE 10



246. THE LANDING WARNING HORN SOUND IF THE GEAR IS NOT DOWN AND LOCKED CAN BE CANCELLED PROVIDED THAT

a) FLAP POSITION IS FROM 0 TO 10 UNITS, RADIO ALT IS MORE THAN 200 FEET BUT LESS THAN 800 FEET

b) THRUST LEVERS ARE SET FOR LANDING, FLAP POSITION IS 15 UNITS

c) FLAP POSITION IS 30 UNITS

(A) SDS-AMM 32-61-00 PAGE 20



247. HOW IS NOSE LANDING GEAR DOORS MOVEMENT CONTROLLED DURING LG EXTENSION OR RETRACTION?

a) BY HYDRAULICALLY OPERATED ACTUATOR

b) BY ELECTRICALLY OPERATED ACTUATOR

c) MECHANICALLY BY RODS

(A) SDS-AMM 32-20-00 PAGE 8



248. COMPLETE THE SENTENCE. LANDING GEAR CONTROL LEVER POSITION IS CONTROLLED BY:

a) 2 CONTROL LEVER UP POSITION SWITCHES AND 2 CONTROL LEVER DOWN POSITION SWITCHES

b) 2 CONTROL LEVER UP POSITION SWITCHES ONLY

c) 2 LVDT (LINEAR VARIABLE DISPLACEMENT TRANSDUCER

(A) SDS-AMM 32-31-00 PAGE 4



249. IN WHICH OF THE FOLLOWING CONDITIONS WILL LANDING GEAR CONTROL LEVER LOCK SOLENOID BE ENERGIZED?

a) GROUND SPOILER INTERLOCK VALVE CLOSED, AIR/GROUND SYSTEM 1 IN AIR MODE

b) GROUND SPOILER INTERLOCK VALVE CLOSED, AIR/GROUND SYSTEM 1 IN GROUND MODE

c) GROUND SPOILER INTERLOCK VALVE OPEN, AIR/GROUND SYSTEM 1 OVERRIDDEN TO AIR MODE

(A) SDS-AMM 32-31-00 PAGE 13



250. A TIME DELAY, REQUIRED FOR THE MAIN LANDING GEAR DOWNLOCK OR UPLOCK ACTUATORS TO UNLOCK BEFORE THE MAIN GEAR ACTUATOR RECEIVES PRESSURE, DURING EXTENSION/RETRACTION OF MAIN LANDING GEAR (MLG) IS INITIATED BY:

a) TIMED OUT RELAY IN THE SELECTOR VALVE

b) TRANSFER CYLINDER LOCATED ON EACH REAR SPAR

c) RESTRICTOR/CHECK VALVE, LOCATED IN MAIN GEAR ACTUATOR

(A) SDS-AMM 32-32-00 PAGE 14



251. THE PSEU (PROXIMITY SENSING ELECTRONICS UNIT) SENDS A SIGNAL TO ENERGIZE THE LEVER LOCK SOLENOID WHEN

a) BOTH SYSTEM A AND B ARE PRESSURIZED

b) GROUND SPOILER INTERLOCK VALVE IS CLOSED

c) LEADING EDGE DEVICES CONTROL VALVE IS CLOSED

(A) SDS-AMM 32-31-00 PAGE 13



252. WHEN DOES THE TRANSFER CYLINDER GIVE A TIMER DELAY?

a) AIRCRAFT TOUCH DOWN

b) LG LOCKING

c) EXTENSION AND RETRACTION CYCLES

(A) SDS-AMM 32-32-00 PAGE 14



253. WHAT IS THE PURPOSE OF THE FRANGIBLE FITTING, INSTALLED ON THE INBOARD AND OUTBOARD SIDES OF BOTH WHEEL WELL RING IN THE MAIN LANDING GEAR WHEEL WELL

a) REMOVES UP PRESSURE FROM THE MAIN LANDING GEAR ACTUATOR WHEN A DAMAGED TIRE MOVE INTO THE MAIN LANDING GEAR WHEEL WELL

b) PREVENTS HYDRAULIC SYSTEM FLUID LOSS WHEN THE HYDRAULIC TUBE SYSTEM A IS BROKEN

c) INCREASES PRESSURE IN THE MAIN LANDING GEAR ACTUATOR WHEN THE MAIN LANDING GEAR DOES NOT EXTEND

(A) SDS-AMM 32-32-00 PAGE 16



254. WHAT IS THE MAXIMUM TURN ANGLE OF THE NOSE WHEEL THAT CAN BE COMMANDED BY THE RUDDER PEDALS?

a) 17 DEGREES

b) 7 DEGREES

c) 78 DEGREES

(A) SDS-AMM 32-51-00 PAGE 1



255. HYDRAULIC POWER FOR THE NORMAL BRAKES IS SUPPLIED BY

a) SYSTEM A TO OUTBOARD AND SYSTEM B TO THE INBOARD BRAKES

b) SYSTEM B

c) SYSTEM A

(A) SDS-AMM 32-41-00 PAGE 2



256. AFTER MANUAL EXTENSION OF THE LANDING GEAR, THE INDICATION ON THE FLIGHT DECK THAT THE CORRECT PROCEDURE HAS BEEN CARRIED OUT IS

a) 3 GREEN LIGHTS AND 3 RED LIGHTS

b) 3 GREEN LIGHTS

c) 3 RED LIGHTS

(A) SDS-AMM 32-61-00 PAGE 4



257. THE ALTERNATE BRAKE SYSTEM IS POWERED BY

a) SYSTEM B HYDRAULIC

b) ACCUMMULATOR PRESSURE

c) SYSTEM A HYDRAULIC

(A) SDS-AMM 32-41-00 PAGE 2



258. SELECTING THE NOSE WHEEL STEERING SWITCH ON THE CAPTAINS INSTRUMENT PANEL TO ALT PROVIDES THE

a) STANDBY HYDRAULIC SYSTEM PRESSURE FOR STEERING

b) B HYDRAULIC SYSTEM PRESSURE FOR STEERING

c) A HYDRAULIC SYSTEM PRESSURE FOR STEERING

(A) SDS-AMM 32-51-00 PAGE 1



259. THE NORMAL PRESSURE FOR THE HYDRAULIC BRAKE PRESSURE INDICATOR IS

a) 3000PSI

b) 1000PSI

c) 2800PSI

(A) SDS-AMM 32-41-00 PAGE 2



260. THE PRECHARGE PRESSURE IN THE BRAKE ACCUMULATOR IS

a) 3000PSI

b) 1500PSI

c) 1000PSI

(A) SDS-AMM 32-41-00 PAGE 16



261. THE 737 BRAKE SYSTEM HAS

a) TWO HYDRAULIC BRAKE ACCUMULATORS

b) ONE HYDRAULIC BRAKE ACCUMULATOR

c) NO HYDRAULIC BRAKE ACCUMULATORS (A) SDS-AMM 32-41-00 PAGE 2



262. THE NOSE WHEEL STEERING LOCKOUT PIN WHEN INSTALLED

a) LIMITS THE NOSE WHEEL STEERING TO +/- 7 DEGREES

b) ALLOWS PUSHBACK WITH HYDRAULIC SYSTEM A PRESSURISED

c) LOCKS THE NOSEWHEEL IN THE CENTRAL POSITION.

(A) SDS-AMM 32-51-00 PAGE 23



263. IF THE NOSE GEAR LOCKOUT PIN IS NOT INSTALLED

a) PUSHBACK MUST BE WITH BOTH SYSTEM A HYDRAULIC PUMPS OFF

b) PUSHBACK MUST BE WITH SYSTEM A ELEC. PUMP OFF

c) PUSHBACK MUST BE WITH BOTH SYSTEM A HYDRAULIC PUMPS ON

(A) SDS-AMM 32-51-00 PAGE 23



264. RUDDER PEDAL STEERING

a) CAN BE OVERRIDDEN BY THE NOSE WHEEL STEERING WHEEL

b) IS AVAILABLE UP TO +/- 7 DEGREES ON THE CAPTAIN'S RUDDER PEDALS ONLY.

c) IS ACTIVATED ANYTIME THE NOSE GEAR STRUT IS EXTENDED.

(A) SDS-AMM 32-51-00 PAGE 12



ATA 33:

265. MOST OF THE FLIGHT COMPARTMENT LIGHT USE

a) 28 VAC

b) 115 VAC

c) 28 VDC

(A) STORMAVIATION DOC ATA 33 PAGE 10



266. WHERE IS THE SPARE BULB STOWAGE

a) CABIN FWD PURSE PANEL

b) COCKPIT RIGHT HAND SIDE

c) E/E COMPARTMENT

(A) ( AMM 33-11-00 , page 201 )



267. HOW DO YOU TEST COCKPIT LIGHT

a) TEST SWITCH ON P1 PANEL

b) TEST SWITCH ON P6 PANEL

c) TEST SWITCH IN E/E PANEL (A) ( AMM 33-11-00 , page 202 )



268. FAILURE OF ONE MAIN A.C. BUS CAUSES

a) PARTIAL LOSS OF COCKPIT AND PASSENGER LIGHTING

b) ALL CABIN LIGHTS TO EXTINGUISH

c) A. NO EFFECT ON THE COCKPIT OR PASSENGER LIGHTING

(A) SDS-AMM 33-11-00 PAGE 2 & 33-22-00 PAGE 2



269. THE EMERGENCY EXIT LIGHTS AND SIGNS ARE POWERED

a) FROM SEPARATE EMERGENCY POWER SUPPLIES INSTALLED IN THE PASSENGER CABIN

b) FROM THE HOT BATTERY BUS

c) A. FROM THE BATTERY BUS

(A) SDS-AMM 33-51-00 PAGE 14



270. MOST OF THE FLIGHT COMPARTMENT LIGHTS USE

a) 28 VAC

b) 115 VAC

c) 28 VDC

(A) SDS-AMM 33-11-00 PAGE 2



271. WHEN ARMED, THE EMERGENCY EXIT LIGHTS WILL AUTOMATICALLY COME ON

a) WHEN THE AIRCRAFT REACHES A PRESET G-LOAD LIMIT

b) IF ELECTRICAL POWER TO DC BUS 1 FAILS OR AC POWER IS TURNED OFF

c) UPON CONTACT WITH WATER

(A) SDS-AMM 33-51-00 PAGE 16



272. THE NO SMOKING SIGNS WHEN SELECTED TO AUTO

a) A. ILLUMINATE WHEN THE LANDING GEAR IS EXTENDED.

b) ILLUMINATE WHEN THE FLAPS ARE EXTENDED AND THE LANDING GEAR IS RETRACTED

c) ILLUMINATE WHEN THE LANDING GEAR IS EXTENDED AND THE FLAPS ARE GREATER THAN 10 DEGREES

(A) SDS-AMM 33-25-00 PAGE 9



273. THE FASTEN BELTS SIGNS WHEN SELECTED TO AUTO WILL

a) EXTINGUISH WHEN THE FLAPS ARE EXTENDED AND THE LANDING GEAR IS UP

b) ILLUMINATE WHEN THE AUTO-PILOT IS NOT ENGAGED.

c) ILLUMINATE WHEN LANDING GEAR OR FLAPS ARE EXTENDED

(A) SDS-AMM 33-25-00 PAGE 9



274. IF THERE IS A COMPLETE ELECTRICAL POWER FAILURE

a) THE LEFT DOME LIGHT SUPPLIES EMERGENCY GENERAL LIGHTING

b) THE RIGHT DOME LIGHT SUPPLIES EMERGENCY GENERAL LIGHTING

c) THE MAP LIGHT SUPPLIES EMERGENCY GENERAL LIGHTING

(A) SDS-AMM 33-14-00 PAGE 8



275. IN EACH WHEEL WELL HAVE

a) A DOME LIGHT AND A FLOODLIGHT

b) A DOME LIGHT

c) A FLOODLIGHT

(A) SDS-AMM 33-32-00 PAGE 2



276. WITH THE NO SMOKING & FASTEN BELTS SWITCHES IN THE AUTO POSITION

a) THE NO SMOKING SIGNS WILL ILLUMINATE ANY TIME THE FLAPS ARE EXTENDED

b) THE NO SMOKING SIGNS WILL ILLUMINATE ANY TIME THE GEAR IS EXTENDED.

c) THE NO SMOKING SIGNS WILL ILLUMINATE ONLY WHEN GEAR AND FLAPS ARE EXTENDED

(A) SDS-AMM 33-25-00 PAGE 9



277. PLACING THE LIGHTS TEST SWITCH TO THE TEST POSITION

a) INHIBITS THE MASTER CAUTION RECALL SYSTEM

b) ILLUMINATES ALL AMBER CAUTION LIGHTS ONLY

c) ILLUMINATES ALL COCKPIT LIGHTING AND WARNING LIGHTS

(A) SDS-AMM 33-18-00 PAGE 2



278. THE P5 SWITCH IS IN THE ARM POSITION. WHEN DO THE EMERGENCY LIGHTS COME ON?

a) WHEN THE MAIN LIGHTING SYTEM HAS FAILED

b) WHEN THE 28VDC BUS 2 VOLTAGE DECREASES BELOW 12 VOLTS

c) WHEN THE 28VDC BUS 1 VOLTAGE DECREASES BELOW 12 VOLTS

(A) SDS-AMM 33-51-00 PAGE 16



279. WITH THE TAXI LIGHT SWITCH SET TO AUTO POSITION, WHEN THE TAXI LIGHT OFF?

a) AFTER THE FIRST ENGINE STOP

b) WHEN THE NOSE LANDING GEAR IS NOT IN THE DOWN AND LOCKED POSITION

c) WHEN THE MAIN LANDING GEAR IS NOT IN THE DOWN AND LOCKED POSION

(A) SDS-AMM 33-45-00 PAGE 6



ATA 34:

280. THE AIRPLANE PITOT SYSTEM CONSISTS OF

a) CAPTAIN'S, FIRST OFFICER'S, AUXILIARY NO. 1

b) CAPTAIN'S, FIRST OFFICER'S

c) CAPTAIN'S, FIRST OFFICER'S, AUXILIARY NO. 1 AND AUXILIARY NO. 2

(A) SDS-AMM 34-11-00 PAGE 14



281. 139. THE AIRPLANE STATIC SYSTEM CONSISTS OF

a) A. CAPTAIN'S, FIRST OFFICER'S, AUXILIARY NO. 1, AUXILIARY NO. 2 AND ALTERNATE

b) CAPTAIN'S, FIRST OFFICER'S, AUXILIARY NO. 1, AUXILIARY NO. 2

c) A. CAPTAIN'S, FIRST OFFICER'S

(A) SDS-AMM 34-11-00 PAGE 14



282. 139. THE ELECTRONIC HORIZONTAL SITUATION INDICATOR (EHSI) PROVIDES

a) A MULTICOLOR DISPLAY OF VARIOUS NAVIGATIONAL AND WEATHER RADAR DATA

b) A. A MULTICOLOR DISPLAY OF VARIOUS NAVIGATIONAL DATA

c) A. WEATHER RADAR DATA

(A) SDS-AMM 31-62-00 PAGE 98.140



283. HOW MANY NAVIGATION UNIT (VOR/ILS RECEIVERS) ARE INSTALLED ON AIRCRAFT

a) 02 UNIT

b) 01 UNIT

c) 03 UNIT

(A) SDS-AMM 34-51-00 PAGE 32



284. THE SUPP NAV DATA PAGES ARE ACCESSIBLE

a) IN FLIGHT ONLY

b) AT ANY TIME

c) ON THE GROUND ONLY

(A) SDS-AMM 34-61-00 PAGE 98.178



285. MARKER BEACON ANTENNA RECEIVERS THE 75 MHZ SIGNAL AND SENDS IT TO

a) VOR/MARKER BEACON (VOR/MB) RECEIVER 1

b) VOR/MB RECEIVER 2

c) VOR/MB RECEIVER 1 & VOR/MB RECEIVER 2

(A) SDS-AMM 34-32-00 PAGE 20



286. THE WEATHER RADAR WX/TURB MODE DISPLAYS DETECTED TURBULENCE WITHIN

a) 160 NM

b) 80 NM.

c) 40 NM.

(A) SDS-AMM 34-43-00 PAGE 41



287. WHAT HAPPENS IF AN ATTITUDE FAILURE OCCURS?

a) THE ATTITUDE SCALE GOES OUT OF THE VIEW ONLY

b) THE ATTITUDE SCALE GOES OUT OF THE VIEW AND ALT FLAG IS DISPLAYED

c) THE ALT FLAG IS DISPLAYED ONLY

(A) SDS-AMM 34-21-00 PAGE98.26



288. THE TCAS/ATC CONTROL PANEL CONTROLS

a) TCAS COMPUTER DIRECTLY AND ATC TRANSPONDERS THROUGH THE TCAS COMPUTER

b) ATC TRANSPONDERS AND THE TCAS COMPUTER DIRECTLY

c) ATC TRANSPONDERS DIRECTLY AND THE TCAS COMPUTER THROUGH THE ATC TRANSPONDERS

(A) SDS-AMM 34-45-00 PAGE56



289. IF THE ALTERNATE VMO/MMO SWITCH IS IN THE "ALTN" POSITION THEN THE

a) THE AIR DATA AND INERTIAL REFERENCE UNITS (ADIRU) ADJUST THE VMO/MMO CURVE TO COMPENSATE FOR A FLIGHT WITH THE LANDING GEAR DOWN

b) THE AIR DATA AND INERTIAL REFERENCE UNITS (ADIRU) USES THE ALTERNATE STATIC PORTS AS INPUT IN ORDER TO CALCULATE THE VMO/MMO CURVE, FOR NORMAL FLIGHT

c) THE AIR DATA AND INERTIAL REFERENCE UNITS (ADIRU) USES THE ALTERNATE PITOT PROBE AND STATIC PORTS AS INPUT IN ORDER TO CALCULATE THE VMO/MMO CURVE, FOR A FLIGHT WITH FLAPS/SLATS DOWN

(A) SDS-AMM 34-21-00 PAGE 6



290. COMPLETE THE SENTENCE. THE WHITE "ALIGN" ANNUCIATOR ON THE AIR DATA AND INERTIAL REFERENCE UNITS (ADIRU) MODE SELECT UNIT (MSU) WILL

a) FLASHING DURING THE ADIRU ALIGNMENT AND WILL COME ON STEADY, WHEN THE ADIRU NEEDS INFORMATION

b) COME ON STEADY DURING ADIRU ALIGNMENT AND WILL FLASH, WHEN THE ADIRU NEEDS INFORMATION

c) COME ON STEADY DURING ADIRU ALIGNMENT AND WILL FLASH, WHEN AN ADIRU FAULT IS DETECTED

(A) SDS-AMM 34-21-00 PAGE 64



291. WHICH OF THE FOLLOWING OCCURS WHEN "B/CRS" (BACK COURSE) IS SELECTED ON THE STANDBY ATTITUDE INDICATOR?

a) THE LOCALIZER AND GLIDESLOPE DEVIATION BAR GO OUT OF VIEW

b) THE LOCALIZER DEVIATION BAR GOES OUT OF VIEW AND THE GLIDESLOPE DEVIATION BAR REVERSES POLARITY

c) THE LOCALIZER DEVIATION BAR RESERVES POLARITY AND THE GLIDESLOPE DEVIATION BAR GOES OUT OF VIEW

(A) SDS-AMM 34-24-00 PAGE 12



292. WHAT IS THE PURPOSE OF THE ELEVATION AND SCAN DISABLE SWITCHES LOCATED ON THE ANTENNA PEDESTAL?

a) TO STOP THE RF TRANSMISSIONS FROM THE WXR R/T, DURING MAINTENCE

b) TO REMOVE POWER TO THE SCAN AND ELEVATION MOTORS IN ORDER TO PREVENT MOVEMENT OF THE ANTENNA DURING MAINTENCE

c) TO SET THE ANTENNA TO THE NEUTRAL POSITION, BEFORE REMOVAL

(A) SDS-AMM 34-43-00 PAGE 53



293. WHICH OF THE FOLLOWING STATEMENTS, IS THE CORRECT ONE ABOUT INSTRUMENT LANDING SYSTEM (ILS) No1 BITE?

a) IN ORDER TO BE PERFORMED, A TEST SET IS REQUIRED

b) IT MAY BE PERFORMED FROM THE CONTROL DISPLAY UNITS (CDS) IN THE FLIGHT DECK

c) IT IS PERFORMED FROM THE FRONT PANEL OF THE MULTI MODE RECEIVER (MMR) No1

(A) SDS-AMM 34-31-00 PAGE 27



294. WHICH IS THE PURPOSE, OF THE "TONE" SELECTOR ON THE AUTOMATIC DIRECTION FINDER (ADF) CONTROL PANEL?

a) TO TURN ON THE ANTENNA/TONE MODULATORS CIRCUIT IN THE ADF RECEIVER

b) TO TURN ON THE BEAT FREQUENCY OSCILLATOR (BFO) IN THE ADF RECEIVER

c) TO ADJUST THE TONE OF THE OUTPUT SIGNALS (STATION AUDIO TONE)

(A) SDS-AMM 34-57-00 PAGE 28



ATA 35:

295. THE PASSENGER OXYGEN SYSTEM IS ACTIVATED WHEN THE CABIN REACHES AN ALTITUDE OF

a) 14,000 FEET

b) 10,000 FEET

c) 9,500 FEET

(A) SDS-AMM 35-20-00 PAGE 26



296. THE OXYGEN SYSTEM ON BOARD THE AIRCRAFT HAS

a) TWO SEPARATE SYSTEMS, ONE FOR THE FLIGHT DECK AND ONE FOR THE CABIN

b) A. ONE SINGLE SYSTEM FOR ALL OXYGEN REQUIREMENTS

c) THREE SEPARATE SYSTEMS, ONE FOR THE FLIGHT DECK, ONE FOR THE CABIN AND ONE FOR THE AFT GALLEY CABIN ATTENDANTS

(A) SDS-AMM 35-00-00 PAGE 02



297. DURING A DECOMPRESSION, THE PASSENGER OXYGEN WILL AUTOMATICALLY DROP FROM ITS STOWAGE COMPARTMENT. OXYGEN WILL FLOW TO ALL MASKS

a) IMMEDIATELY

b) ONLY WHEN ANY ONE OF THE MASKS OF AN OXYGEN GENERATOR UNIT IS PULLED DOWN

c) WHEN THE PASSENGER BREATHES, - THE SYSTEM IS ON DEMAND

(A) SDS-AMM 35-20-00 PAGE 24



298. IN EACH LAVATORY THERE IS

a) A TWO MASK PASSENGER OXYGEN UNIT

b) A ONE MASK PASSENGER OXYGEN UNIT

c) NO PASSENGER OXYGEN UNIT

(A) SDS-AMM 35-20-00 PAGE 21



299. TO USE THE PASSENGER PORTABLE OXYGEN

a) TURN THE YELLOW KNOB IN AN ANTICLOCKWISE DIRECTION AND PLUG THE BOTTLE INTO THE OVERHEAD CONNECTION

b) TURN THE YELLOW KNOB IN A COUNTERCLOCKWISE DIRECTION AND PLUG THE MASK INTO THE DESIRED BOTTLE OUTLET

c) PLUG THE MASK INTO THE DESIRED OUTLET ONLY

(A) SDS-AMM 35-30-00 PAGE 4



300. EACH PASSENGER OXYGEN UNIT IN THE CABIN

a) A. CAN BE SHUT OFF ONCE THE FLOW OF OXYGEN HAS STARTED - BY CABIN STAFF ACTION ONLY.

b) CANNOT BE SHUT OFF ONCE THE FLOW OF OXYGEN HAS STARTED

c) CAN BE SHUT OFF BY PULLING ANY MASK DOWN A SECOND TIME (A) SDS-AMM 35-20-00 PAGE 15



301. THE PASSENGER OXYGEN SYSTEM

a) IS SUPPLIED FROM THE PASSENGER OXYGEN BOTTLE LOCATED IN THE FORWARD CARGO COMPARTMENT

b) IS SUPPLIED BY INDIVIDUAL CHEMICAL OXYGEN GENERATORS, ONE FOR EACH PASSENGER

c) IS SUPPLIED BY INDIVIDUAL CHEMICAL OXYGEN GENERATORS LOCATED AT EACH PASSENGER SERVICE UNIT

(A) SDS-AMM 35-20-00 PAGE 2



302. PASSENGER OXYGEN FLOWING TO A MASK IS VISUALLY CONFIRMED BY

a) AN AMBER IN-LINE FLOW INDICATOR

b) A GREEN IN-LINE FLOW INDICATOR

c) A. A WHITE IN-LINE FLOW INDICATOR

(A) SDS-AMM 35-20-00 PAGE 24



303. NORMAL PRESSURE OF THE FLIGHT CREW OXYGEN SYSTEM IS

a) 1850 P.S.I

b) 2000 P.S.I.

c) A. 1500 P.S.I.

(A) SDS-AMM 35-10-00 PAGE 12



304. CREW OXYGEN SYSTEM PRESSURE IS CORRECTLY INDICATED WHEN

a) THE BATTERY SWITCH IS ON

b) DOES NOT REQUIRE ELECTRICAL POWER

c) A. THE BATTERY SWITCH IS OFF ( HOT BATTERY BUS ).

(A) SDS-AMM 35-10-00 PAGE 12



305. EACH PASSENGER OXYGEN GENERATOR WHEN ACTIVATED

a) WILL PRODUCE OXYGEN FOR APPROXIMATELY 12 MINUTES

b) WILL PRODUCE OXYGEN FOR APPROXIMATELY 7 MINUTES

c) WILL ONLY PRODUCE OXYGEN ON DEMAND FOR APPROXIMATELY 20 MINUTES

(A) SDS-AMM 35-20-00 PAGE 15



306. THE PASSENGER OXYGEN MASK STOWAGE UNITS ARE ACTIVATED

a) A. AUTOMATICALLY BY A BAROMETRIC PRESSURE SWITCH WHEN THE CABIN ALTITUDE IS 14,000 FEET OR WHEN THE PASS OXYGEN SWITCH ON THE OVERHEAD PANEL IS POSITIONED TO NORMAL

b) AUTOMATICALLY BY A BAROMETRIC PRESSURE SWITCH WHEN THE CABIN ALTITUDE IS 10,000 FEET OR WHEN THE PASS OXYGEN SWITCH ON THE OVERHEAD PANEL IS POSITIONED TO ON

c) AUTOMATICALLY BY A BAROMETRIC PRESSURE SWITCH WHEN THE CABIN ALTITUDE IS 14,000 FEET, OR WHEN THE PASS OXYGEN SWITCH ON THE OVERHEAD PANEL IS POSITIONED TO ON

(A) SDS-AMM 35-20-00 PAGE 2



ATA 36:

307. THE AMOUNT OF FAN AIR THAT IS DUCTED THROUGH THE PRE-COOLER +C46:G51IS CONTROLLED BY THE

a) RAM AIR CONTROLLER

b) THERMOSTATIC PRE-COOLER VAVLE

c) MODULATING AND SHUT-OFF VAVLE

(A) DOCUMENT STORM AVIATION ATA 36 PAGE 44



308. THE DUAL BLEED LIGHT WILL BE ON

a) WITH No.1 AND No. 2 BLEED VAVLES CLOSED AND APU BLEED VAVLE OPEN

b) WITH No. 2 ENGINE BLEED VAVLE OPEN, THE ISOLATION VAVLE OPEN AND APU BLEED VAVLE OPEN

c) WITH THE AIR CONDITIONING PANEL SET FOR A BLEEDS-OFF TAKEOFF

(A) DOCUMENT STORM AVIATION ATA 36 PAGE 62



309. THE PNEUMATIC DUCT PRESSURE GAUGE

a) INDICATES PRESSURE IN LEFT AND RIGHT PNERMATIC DUCTS

b) INDICATES PRESSURE AVAILABLE FOR ENGINE ANTI-ICING

c) IS DC POWERED

(A) DOCUMENT STORM AVIATION ATA 36 PAGE 14



310. THE SOURCE OF ENGINE BLEED ARE

a) 5TH AND 9TH STAGES OF THE TURBINE SECTION

b) 5TH AND 9TH STAGES OF THE COMPRESSOR SECTION

c) 5TH AND 13TH STAGES OF THE FAN SECTION

(A) DOCUMENT STORM AVIATION ATA 36 PAGE 18



311. THE ENGINE BLEED VAVLE ARE

a) DC ACTIVATED AND PNEUMATICALLY OPERATED

b) PNEUMATICALLY ACTIVATED AMD OPERATED

c) AC ACTIVATED AND PNEUMATICALLY OPERATED.

(A) DOCUMENT STORM AVIATION ATA 36 PAGE 18



312. WATER TANK PRESSURISATION IN FLIGHT IS NORMALLY PROVIDED BY

a) 5TH AND 9TH STAGE AIR FROM ENGINE No. 2

b) 5TH AND 9TH STAGE AIR FROM ENGINE No. 1

c) BLEED AIR FROM THE APU

(A) DOCUMENT STORM AVIATION ATA 36 PAGE 4



313. BOTH HYDRAULIC RESERVOIRS ARE PRESSURISED BY

a) SEPARATE ENGINE BLEEDS DRICECTLY TO THE RESERVOIRS

b) 5TH AND 9TH STAGE AIR FROM ENGINE No. 2 ONLY

c) AIR FROM THE PNEUMATIC MANIFOLD

(A) DOCUMENT STORM AVIATION ATA 36 PAGE 4



314. THE SOURCE AIR DUCTED THROUGH THE PRE-COOLER IS

a) PrRESSUR CONTROLLED RAM AIR

b) 5TH STAGE BLEED AIR

c) FAN AIR

(A) DOCUMENT STORM AVIATION ATA 36 PAGE 12



315. THE PRE-COOLER CONTROL VAVLE IS

a) DC CONTROLLED AND PNEUMATICALLY OPERATED

b) PNEUMATICALLY CONTROLLED AND OPERATED

c) AC CONTROLLED AND PNEUMATICALLY OPERATED

(A) DOCUMENT STORM AVIATION ATA 36 PAGE 42



316. THE ISOLATION VAVLE IS

a) AC OPERATED

b) AC CONTROLLED AND PNEUMATICALLY OPERATED

c) DC OPERATED

(A) DOCUMENT STORM AVIATION ATA 36 PAGE 54



ATA 38:

317. HOW MANY SUBSYSTEMS OF WATER AND WASTE SYSTEM

a) 1

b) 2

c) 3

(A) AMM PART 1/ 38-00-00 PAGE 2



318. HOW MANY SUBSYSTEMS OF POTABLE WATER SYSTEM

a) 1

b) 2

c) 3

(A) AMM PART 1/ 38-10-00 PAGE 2



319. WHEN YOU DRAIN THE POTABLE WATER SYSTEM, YOU MUST DRAIN WATER FROM:

a) WATER SERVICE PANEL

b) FORWARD LAVATORY

c) WATER SERVICE PANEL and FORWARD LAVATORY

(A) AMM PART 1/ 38-11-00 PAGE 2



320. THE WATER SERVICE PANEL IS LOCATED:

a) THE AFT SECTION OF THE FUSELAGE, BOTTOM RIGHT SIDE

b) THE AFT SECTION OF THE FUSELAGE, BOTTOM LEFT SIDE

c) THE CENTER SECTION OF THE FUSELAGE

(A) AMM PART 1/ 38-11-00 PAGE 2



323. THE PRESSURE RELIEF VALVE PRESENTS AN OVER-PRESSURE CONDITION IN THE WATER TANK PRESSURE LINES, THE VALVE RESETS AT:

a) 50PSIG

b) 55PSIG

c) 60PSIG

(A) AMM PART 1/ 38-42-00 PAGE 7



324. THE AIR COMPRESSOR OF WATER SYSTEM IS ON

a) THE LEFT SIDE OF THE AFT CARGO COMPARTMENT

b) THE RIGHT SIDE OF AFT THE CARGO COMPARTMENT

c) THE LEFT SIDE OF THE FWD CARGO COMPARTMENT

(A) AMM PART 1/ 38-42-00 PAGE 10



325. WHAT TIME IS DUTY CIRCLE INHIBIT OF FLUSH CONTROL UNIT

a) 10 SECONDS

b) 15 SECONDS

c) 20 SECONDS

(A) AMM PART 1/38-32-00 PAGE 17



326. THE VACUUM BLOWER BAROMETRIC SWITCH OPENS WHEN THE ALTITUDE IS ABOVE

a) 15,000FT

b) 16,000FT

c) 17,000FT

(A) AMM PART 1/ 38-32-00 PAGE 36



327. WHAT TYPE OF THE VACUUM CHECK VALVE

a) FLAPPER TYPE VALVE

b) BYPASS TYPE VALVE

c) BALL TYPE VALVE

(A) AMM PART 1/ 38-32-00 PAGE 40



328. THE LOGIC CONTROL MODULE LCM OF WATER TANK SYSTEM IS LOCATED?

a) ON THE RIGHT SIDE OF THE CARGO COMPARTMENT

b) ON THE LEFT SIDE OF THE CARGO COMPARTMENT

c) ON THE AFT SIDE OF THE CARGO COMPARTMENT

(A) AMM PART 1/ 38-33-00 PAGE 14



330. THE VACUUM BLOWER OF WASTE TANK SYSTEM IS

a) THREE-PHASE, LOW-SPEED, MOTOR-OPERATED FAN

b) THREE-PHASE, HIGH-SPEED, MOTOR-OPERATED FAN

c) ONE-PHASE, LOW-SPEED, MOTOR-OPERATED FAN

(A) AMM PART 1/ 38-32-00 PAGE 31



ATA 47:

331. CHOOSE THE CORRECT STATEMENT REGARDING THE NGS SHUTOFF VALVE

a) AN ELECTRICALLY COMMANDED PNEUMATICALLY ACTUATED PRESSURE REGULATING AND SHUTOFF VALVE (SPRING LOADED CLOSED)

b) A PNEUMATICALLY COMMANDED AND ACTUATED PRESSURE REGULATING AND SHUTOFF VALVE (SPRING LOADED CLOSED)

c) AN ELECTRICALLY COMMANDED PNEUMATICALLY ACTUATED PRESSURE REGULATING AND SHUTOFF VALVE (SPRING LOADED OPENED)

(A) SDS- AMM 47-10-00 PAGE 6



332. WHICH OF THE FOLLOWING CORRECTLY DESCRIBES THE RAM AIR VALVE (RAV)

a) FULLY PNEUMATICALLY COMMANDED ACTUATED, SPRING LOADED OPENED

b) TORQUE MOTOR COMMANDED, PNEUMATICALLY ACTUATED, SPRING LOADED CLOSED

c) TORQUE MOTOR COMMANDED, PNEUMATICALLY ACTUATED, SPRING LOADED OPENED

(A) SDS-AMM 47-10-00 PAGE 16



333. WHAT IS REQUIRED TO DISPATCH THE AIRCRAFT IF THE AMBER INOPERATIVE LIGHT LOCATED ON OPERABILITY INDICATOR ILLUMINATES?

a) ITS REQUIRED TO MANUALLY OPEN AND LOCK THE NITROGEN GENERATION SYSTEM SHUTOFF VALVE BEFORE FLIGHT

b) ITS REQUIRED TO MANUALLY CLOSE AND LOCK THE NITROGEN GENERATION SYSTEM SHUTOFF VALVE BEFORE FLIGHT

c) NO MAINTENANCE IS NECCESSARY

(A) SDS=AMM 47-40-00 PAGE 2



334. WHAT IS REQUIRED TO DISPATCH THE AIRCRAFT IF THE BLUE DEGRADED LIGHT LOCATED ON OPERABILITY INDICATOR ILLUMINATES?

a) ITS REQUIRED TO MANUALLY OPEN AND LOCK THE NITROGEN GENERATION SYSTEM SHUTOFF VALVE BEFORE FLIGHT

b) ITS REQUIRED TO MANUALLY CLOSE AND LOCK THE NITROGEN GENERATION SYSTEM SHUTOFF VALVE BEFORE FLIGHT

c) NO MAINTENANCE IS NECCESSARY

(A) SDS=AMM 47-40-00 PAGE 2



335. THE OVERTEMPERATURE SHUTOFF VALVE IS

a) ELECTRICALLY CONTROLLED AND PNEUMATICALLY OPERATED, SPRING LOADED CLOSED

b) PNEUMATICALLY CONTROLLED AND OPERATED, SPRING LOADED CLOSED

c) ELECTRICALLY CONTROLLED AND PNEUMATICALLY OPERATED, SPRING LOADED OPENED

(A) SDS-AMM 47-10-00 PAGE 26



ATA 49:

336. THE APU MAY BE OPERATED WITH APU BLEED ONLY UP TO A MAXIMUM ALTITUDE OF

a) 35.000 FT

b) 17.000 FT

c) 10.000 FT

(A) AMM PART 1/ 49-00-00 PAGE 4



337. THE APU LOW OIL PRESSURE LIGHT IS

a) ALWAYS ILLUMINATED WHEN THE APU SWITCH IS IN OFF POSITION

b) DISARMED WHEN THE APU SWITCH IS IN THE OFF POSITION

c) INHIBITED DURING APU START

(A) AMM PART 1/ 49-00-00 PAGE 16



338. ON THE 737NG, THE APU WILL AUTOMATICALLY SHUT-DOWN WHEN

a) THE BATTERY SWITCH IS PLACED OFF AT ANY TIME

b) THE BATTERY SWITCH IS PLACED OFF IN FLIGHT ONLY

c) THE BATTERY SWITCH IS PLACED OFF ON THE GROUND ONLY

(A) AMM PART 1/ 49-00-00 PAGE 16



339. HOW LONG DOES APU COOLING DOWN CIRCLE?

a) 50 SECONDS

b) 60 SECONDS

c) 55 SECONDS

(A) AMM PART 1/ 49-00-00 PAGE 16



341. WHICH POWER SOURCE SUPPLY APU INDICATION LIGHT OPERATIVE?

a) 115V AC

b) 12V DC

c) 220 V AC

(A) AMM PART 1/ 49-00-00 PAGE 20



342. THE APU FIRE WARNING SYSTEM GIVES AURAL AND VISUAL WARNINGS

a) IN THE FLIGHT DECK AND MAIN WHEEL WELL

b) ONLY IN THE FLIGHT DECK

c) IN THE FLIGHT DECK AND THE APU COMPARTMENT

(A) AMM PART 1/ 49-60-00 PAGE 3



343. DURING A NORMAL APU START

a) THE AMBER LOW OIL PRESSURE LIGHT IS LLUMINATED UNTIL THE APU OIL PRESSURE IS NORMAL (APPROX. 30% RPM)

b) THE STARTER MOTOR IS ENGAGED AS SOON AS THE MASTER SWITCH IS RELEASED FROM START TO ON

c) THE BLUE APU GEN OFF BUS BUS LIGHT GOES OUT AT 95% RPM

(A) AMM PART 1/ 49-00-00 PAGE 14



344. WHEN DOES INLET DOOR CLOSE DURING SHITDOWN APU?

a) AT 25% SPEED b) AT 30% SPEED c) AT 35% SPEED

(A) AMM PART 1/ 49-00-00 PAGE 16



345. IF AN APU FIRE WARNING IS SENSED

a) THE APU WILL SHUT-DOWN AND THE EXTINGUISHER IS DISCHARGED AUTOMATICALLY

b) THE APU WILL SHUT-DOWN AUTOMATICALLY

c) THE APU MUST BE SHUT-DOWN BY PULLING UP THE FIRE SWITCH

(A) AMM PART 1/ 49-00-00 PAGE 18



346. THE ALLIED SIGNAL 131-9(B) APU GENERATOR IS RATED AT

a) 45 KVA IN-FLIGHT AND 55KVA ON THE GROUND

b) THE SAME RATING AS AN ENGINE DRIVEN GENERATOR

c) 90 KVA UP TO 32,000FT AND 66 KVA UP TO 41,000FT

(A) AMM PART 1/ 49-00-00 PAGE 4



347. HOW IS THE APU IS SWITCHED ONTO THE AC ELECTRICAL SYSTEM?

a) AUTOMATICALLY WHEN THE PREVIOUS POWER SOURCE IS DISCONNECTED

b) AUTOMATICALLY IF THE APU GENERATOR IS RUNNING

c) BY TWO APU SWITCHES INDIVIDUALLY OPERATED

(A) AMM PART 1/ 49-60-00 PAGE 3



348. WHAT TYPE OF BLEED AIR VALVE

a) BUTTERFLY TYPE VALVE

b) BALL TYPE VALVE

c) BYPASS TYPE VALVE

(A) AMM PART 1/ 49-50-00 PAGE 6



349. THE 737NG APU START CYCLE

a) MAY TAKE AS LONG AS 120 SECONDS

b) MAY TAKE AS LONG AS 180 SECONDS

c) MAY TAKE AS LONG AS 60 SECONDS (A) AMM PART 1/ 49-00-00 PAGE 15



350. THE MAXIMUM AIRCRAFT ALTITUDE FOR BOTH APU BLEED AND ELECTRICAL LOAD IS

a) 17,000FT

b) 35,000FT

c) 15,000FT

(A) AMM PART 1/ 49-00-00 PAGE 2



351. WHEN DOES THE APU FUEL SOLENOID VALVE OPEN?

a) WHEN OIL TEMPERATURE HAS REACHED A MINIMUM VALUE

b) WHEN OIL PRESSURE HAS REACHED 13PSI

c) WHEN START APU AT 7% SPEED

(A) AMM PART 1/ 49-00-00 PAGE 14



353. ILLUMINATION OF THE APU DET INOP LIGHT

a) DOES NOT ACTIVATE THE MASTER CAUTION SYSTEM

b) ACTIVATES MASTER CAUTION "OVHT/DET"

c) ACTIVATES MASTER CAUTION "APU"

(A) AMM PART 1/ 49-00-00 PAGE 13



ATA 52:

354. WHAT IS THE FUNCTION OF THE COUNTERBALANCE ASSEMBLY ON THE CARGO DOOR?

a) TO HOLD THE CARGO DOOR IN THE FULLY CLOSE POSITION

b) TO REDUCE THE FORCE REQUIRED TO LIFT THE CARGO DOOR

c) TO LIMIT THE SPEED OF DOOR MOTION DURING OPENING OR CLOSING

(A) AMM PART 1/ 52-30-00 PAGE 9



355. ON THE PASSENGER ENTRY DOOR, WHERE IS THE PROXIMITY SWITCH FOR THE DOOR WARNING SYSTEM?

a) ON THE INTERIOR CONTRONL HANDLE

b) ADJACENT TO THE LOWER HINGE

c) ADJACENT TO THE UPPER LATCH (A) AMM PART 1/ 52-10-00 PAGE 2



356. WHEN ARE THE EMERGENCY EXIT DOOR LOCKED (FLIGHT LOCK MECHANISM)?

a) DURING THE TAKE OFF ROLL

b) TWO OR MORE ENTRY/SERVICE DOORS CLOSED

c) ONE ENGINE IS MORE THAN 50% N2

(A) AMM PART 1/ 52-22-00 PAGE 14



357. WHAT IS THE FUNCTION OF THE FLIGHT LOCK MECHANISM ON THE EMERGENCY DOOR?

a) TO PREVENT OPERATION OF THE EMERGENCY DOOR ON GROUND

b) TO TURN THE EMERGENCY DOOR OUT OF THE FUSELAGE CUT-OUT

c) TO PREVENT OPERATION OF THE EMERGENCY IN FLIGHT

(A) AMM PART 1/ 52-22-00 PAGE 12



358. HOW IS THE CARGO DOOR HELD IN THE OPEN POSITION?

a) DOOR OPEN LOCK SOLENOID

b) HYDRAULIC ACTUATOR

c) COUNTERBALANCE ASSEMBLY

(A) AMM PART 1/ 52-30-00 PAGE 9



359. WHAT INDICATIONS WILL BE TRIGGERED IF AN OVERWING DOOR IS UNLOCKED WHEN IT SHOULD BE LOCKED?

a) THE PROXIMITY SWITCHING ELECTRONIC UNIT (PSEU) LIGHT ON THE P5AFT OVERHEAD PANEL WILL COME ON (NOT RESETTABLE)

b) THE RELATED OVERWING LIGHT ON THE P5-20 DOOR WARNING ANNUNCIATOR MODULE WILL COME ON

c) THE OVERWING DOOR LOCK MESSAGE WILL BE DISPLAYED ON FMS CDU

(A) AMM PART 1/ 52-71-00 PAGE 9



360. WHAT ARE THE DOOR SEALS CONSTRUCTED FROM?

a) SILICON RBBER

b) SILICON FABRIC

c) CARBON FIBRE

(A) AMM PART 1/ 52-09-00 PAGE 2



361. WHAT IS THE MAXIMUM SPEED THAT THE MAINTENANCE ENGINEER CAN OPEN AND CLOSE ENTRY, GALLEY SERVICE AND CARGO DOORS?

a) 40 KNOTS

b) 15 KNOTS

c) 65 KNOTS

(A) AMM PART 1/ 52-00-00 PAGE 2



362. THE EMERGENCY EXIT DOOR OPEN

a) FROM INSIDE OR OUTSIDE THE AIRPLANE

b) FROM OUTSIDE THE AIRPLANE

c) FROM INSIDE THE AIRPLANE (A) AMM PART 1/ 52-22-00 PAGE 2



363. HOW MANY TYPE OF DOORS ON THE AIRPLANE

a) 3

b) 4

c) 5

(A) AMM PART 1/ 52-00-00 PAGE 2



364. YOU CAN OPEN AND CLOSE FORWARD ENTRY, FORWARD GALLEY SERVICE AND CARGO DOORS IN WINDS UP TO

a) 35 KNOTS

b) 40 KNOTS

c) 45 KNOTS

(A) AMM PART 1/ 52-10-00 PAGE 28



365. HOW MANY TYPES OF DOOR SEAL SHAPES

a) 3

b) 4

c) 5

(A) AMM PART 1/ 52-09-00 PAGE 2



369. WHEN YOU OPEN CARGO DOOR, THE DOOR MOVES

a) UPWARD AND INWARD

b) DOWNWARD AND INWARD

c) UPWARD AND INWARD

(A) AMM PART 1/ 52-30-00 PAGE 10



370. HOW MANY LATCH OF APU ACCESS DOOR

a) 3

b) 4

c) 5

(A) AMM PART 1/ 52-40-00 PAGE 17



371. HOW MANY PUSH-BUTTON LATCHES OF REFUELING STATION ACCESS DOOR

a) 3

b) 4

c) 5

(A) AMM PART 1/ 52-40-00 PAGE 19



373. THE DOOR WARNING AMBER LIGHTS ARE ON

a) THE P3 FORWARD OVERHEAD PANEL

b) THE P4 FORWARD OVERHEAD PANEL

c) THE P5 FORWARD OVERHEAD PANEL (A) AMM PART 1/ 52-71-00 PAGE 2



ATA 51-57:

377. THE VERTICAL STABILIZER IS MADE FROM

a) ALUMINIUM

b) GRAPHITE COMPOSITE

c) TITANIUM

(A) STORMAVIATION DOC ATA 51-57 PAGE 282



378. WHICH WINDOWS CAN NOT BE OPENED?

a) 1 AND 2

b) 1 AND 3

c) 2 AND 3

(A) STORMAVIATION DOC ATA 51-57 PAGE 288



379. WHICH PANE OF THE CABIN WINDOW DOESN’T STRUCTURE?

a) OUTER PANE

b) INNER PANE

c) MIDDLE PANE

(A) STORMAVIATION DOC ATA 51-57 PAGE 6



380. WHAT IS THE MAIN MATERIAL IN THE WING?

a) ALUMINIUM

b) GRAPHITE COMPOSITE

c) TITANIUM

(A) STORMAVIATION DOC ATA 51-57 PAGE 282



382. HOW MANY LIGHTNING DIVERTER STRIPS ON RANDOME

a) 5

b) 6

c) 7

(A) AMM PART 1/ 53-00-00 PAGE 5



383. WHAT IS THE METERIAL OF RUDDER?

a) ALUMINIUM

b) GRAPHITE COMPOSITE

c) TITANIUM

(A) STORMAVIATION DOC ATA 51-57 PAGE 282



384. HOW IS OPEN THE FIRST OFFICERS SLIDING WINDOW?

a) OPENED FROM THE INSIDE ONLY

b) OPENED FROM THE OUTSIDE ONLY

c) OPENED FROM THE INSIDE AND OUTSIDE

(A) STORMAVIATION DOC ATA 51-57 PAGE 294



385. The length of the B737-700 airplane:

a. 33.6 M

b. 31.2 M

c. 39.5 M

(A) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 10



386. Use these dimensions to find components on the fuselage:

a. Body station line, Body buttock line, Water line

b. Body station line, Water line

c. Body station line, Water line

(A) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 12



387. The body buttock line (BL) is

a. is a horizontal dimension. It starts at station line zero

b. is a height dimension. Measure the water line from a horizontal reference plane below the airplane

c. a lateral dimension. Measure the buttock line to the left (LBL) or right (RBL) of the airplane center line

(A) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 12



388. The nose of the airplane is

a. station 140

b. station 130

c. station 150

(A) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 12



389. Measure the vertical stabilizer station

a. perpendicular to the rudder hinge centerline. Rudder station 0 starts at the body crown line.

b. perpendicular to the vertical stabilizer leading edge. Vertical stabilizer leading edge station 0 starts at the body crown line

c. Perpendicular to the vertical stabilizer rear spar. Vertical stabilizer station 0 starts at the body crown line

(A) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 16



390. Measure the vertical stabilizer waterline

a. Perpendicular to the vertical stabilizer rear spar b. perpendicular to the rudder hinge centerline

c. parallel to the body waterline

(A) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 16



391. Measure stabilizer stations

a. perpendicular to the horizontal stabilizer rear spar

b. Perpendicular to the horizontal stabilizer leading edge

c. perpendicular to the elevator hinge centerline

(A) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 18



392. What is not primary structure:

a. Doors

b. Radome

c. Landing Gear

(A) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 22



393. Most of the material in the radome is

a. steel

b. fiberglass

c. Aluminium

(A) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 32



394. The lightning diverter strips

a. increase lightning energy and transmit it to the airframe

b. decrease lightning energy and transmit it to the wing

c. decrease lightning energy and transmit it to the airframe

(A) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 32



395. The winglets are made of

a. graphite spars, aluminum ribs and aluminum skins

b. graphite spars, aluminum ribs and graphite skins

c. aluminum spars, aluminum ribs and aluminum skins

(A) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 46



396. Flight compartment windows can be opened?

a. windows 1 and 3

b. windows 2

c. windows 2 and 3

(A) Ref: Reference: ATA 56 WINDOWS (Book 1) - B737 Training book - Page 5



397. Which windows get heat from the window anti-ice system?

a. Flight compartment windows 1, 2 and 3

b. Flight compartment windows 1 and 3

c. Flight compartment windows 1 and 2

(A) Ref: Reference: ATA 56 WINDOWS (Book 1) - B737 Training book - Page 5



398. Which windows have a small hole in the upper forward corner of the inner pane?

a. Flight compartment window 3

b. Flight compartment window 1

c. Flight compartment window 2

(A) Ref: Reference: ATA 56 WINDOWS (Book 1) - B737 Training book - Page 9



399. The passenger compartment, which pane is not structural?

a. Outer pane

b. Inner pane

c. Middle pane

(A) Ref: Reference: ATA 56 WINDOWS (Book 1) - B737 Training book - Page 15



400. Control cabin sliding windows can be opened from

a. inside and outside

b. only inside

c. only outside

(A) Ref: Reference: ATA 56 WINDOWS (Book 1) - B737 Training book - Page 12



B. QUESTION BANK FOR B737NG CAT B1 (AIRFRAME)



ATA 0:

1. How to ground the airplane?

a. There is no spectial sequence.

b. Always attach the grouding cable to the airplane first

c. Always attach the grouding cable to the ground connection first

(B1) Ref: Reference: ATA 00 Introduction - B737 Training book - Page 169



2. When are the pitot probe covers and static port covers recommended to install?

a. When the airplane is parked for more than a standard turnaround or conditions such as insect activity, dust stoms or volcanic ash

b. When conditions such as insect activity, dust stoms or volcanic ash

c. When the airplane is parked for more than a standard turnaround

(B1) Ref: Reference: ATA 00 Introduction - B737 Training book - Page 167



3. Where can you find the turning limits when airplane is towed or pushed for dispatch?

a. The painted stripes are on the lower fuselage below left pax door

b. The painted stripes are on the nose gear doors

c. The painted stripes are on the lower fuselage below right pax door

(B1) Ref: Reference: ATA 00 Introduction - B737 Training book - Page 185, 191



ATA 5:

4. In which chapter would you find the Fuselage Bird Strike Inspection

a. Chapter 5

b. Chapter 3

c. MEL Maintenance procedures

(B1) Ref: Reference: AMM Part PP Task 05-51-18-210-801



5. Overweight Landing Inspection

a. ATA 32

b. ATA 5

c. Flight Operating Manual

(B1) Ref: Reference: AMM Part PP Task 05-51-35



6. In what chapter is the pressure leak rate chart for fuselage leakage rates.

a. ATA 21

b. MEL, limitations

c. Chapter 5

(B1) Ref: Reference: AMM Part PP Task 05-51-91



7. During a pressurisation test what is max. pressure during a normal test.

a. 6.0 p.s.i.

b. 32 p.s.i.

c. 4.0 p.s.i.

(B1) Ref: Reference: AMM Part PP Task 05-51-91-790-801



ATA 6:

8. The body station line (STA) is a:

a. Lateral dimension.

b. Horizontal dimension.

c. Height dimension.

(B1) Ref: Reference: AMM Part PP Task 06-10-00-800-801



9. The body buttock line (BL) is a

a. Lateral dimension.

b. Height dimension.

c. Horizontal dimension.

(B1) Ref: Reference: AMM Part PP Task 06-10-00-800-801



10. The water line (WL) is a

a. Lateral dimension.

b. Horizontal dimension.

c. Height dimension.

(B1) Ref: Reference: AMM Part PP Task 06-10-00-800-801



11. The airplane has

a. Eight major zones

b. Six major zones

c. Seven major zones

(B1) Ref: Reference: AMM Part PP Task 06-30-00-800-801



12. The general left wing section base number is:

a. 500

b. 600

c. 700

(B1) Ref: Reference: AMM Part PP Task 06-24-00-800-801



13. The airplane is divided into

a. Stations, waterlines, and buttock lines.

b. Stations, waterlines lines.

c. Waterlines, and buttock lines.

(B1) Ref: Reference: AMM Part PP Task 06-10-00-800-801



ATA 7:

15. The airplane has

a. Three main jack points and four auxiliary jack points.

b. Four main jack points and three auxiliary jack points.

c. Three main jack points and three auxiliary jack points. (B1) Ref: Reference: AMM Part PP Task 07-11-01-580-815



16. On each wing has:

a. 02 jack points

b. 03 jack points

c. 01 jack point

(B1) Ref: Reference: AMM Part PP Task 07-11-01-580-815



17. In which document you will find the detail instruction for shoring the aircraft?

a. Airplane Recovery Document.

b. Structure Repair Manual.

c. Aircraft Maintenance Manual.

(B1) Ref: Reference: AMM Part PP Task 07-20-00-580-801



18. When Lifting the aircraft

a. No requirement.

b. All the doors must be closed

c. The passenger/crew doors, the emergency exits and the cargo doors are closed and locked or fully open and locked.

(B1) Ref: Reference: AMM Part PP Task 07-11-01-580-815



ATA 8:

19. The main purpose of weighing aircraft is:

a. Calculate of aircraft weight

b. Know the aircraft weight for passenger loading

c. Calculate the position of the center of gravit.

(B1) Ref: Reference: Weight and Balance Manual



ATA 9:

20. The design of the airplane will permit you to tow the airplane from

a. The nose landing gear

b. The main landing gear

c. The nose landing gear or main landing gear

(B1) Ref: Reference: AMM Part PP Task 09-11-00-580-801



21. The maximum normal towing turning limits are indicated by the painted stripes on

a. The lower fuselage below left pax door

b. The nose gear doors.

c. The lower fuselage below right pax door

(B1) Ref: Reference: AMM Part PP Task 09-11-00-580-801



22. What is the correct sequence?

a. Install the tow bar on the tow fitting then install the tow lever safety pin

b. Install the tow lever safety pin then install the tow bar on the tow fitting.

c. There is no specific sequence.

(B1) Ref: Reference: AMM Part PP Task 09-11-00-580-801



23. When tow the aircraft, maximum normal turning angle is:

a. 68 degrees

b. 78 degrees

c. 88 degrees

(B1) Ref: Reference: AMM Part PP Task 09-11-00-580-801



ATA 10:

24. When aircraft stop overnight:

a. Pitot probe and static port are covered.

b. Static port are covered.

c. Pitot port are covered.

(B1) Ref: Reference: AMM Part PP Task 10-11-01-580-801



25. The aircraft is usually parked for a small quantity of time as follows:

a. Chocks in front of and behind a minimum of one of the main gear wheels

b. Chocks in front of and behind a minimum of one of the main gear wheels

c. No need chocks

(B1) Ref: Reference: AMM Part PP Task 10-11-01-580-801



ATA 11:

26. Letters of marking or placard EXIT and EMERGENCY EXIT are in

a. red color

b. orange color

c. blue color

(B1) Ref: Reference: AMM Part PP Task 11-32-01



28. Red strip markings on nose gear doors are

a. used during airplane towing

b. used for airplane nose jacking

c. used to indicated hazard area during nose landing gear retraction and extension

(B1) Ref: Reference: AMM Part PP Task 09-11-00-580-801



29. Marking SMOKE DETECTOR - DO NOT BLOCK is used for

a. lavatory smoke detector

b. engine fire detection system

c. cargo fire detection system

(B1) Ref: Reference: AMM Part PP Task 11-37-01-2-2



ATA 12:



32. When doing the Hydraulic Fluid Reservoir Filling

a. The reservoirs air pressurize system must be depressurized

b. Do not depressurize the system reservoirs

c. The hydraulic system operating normally

(B1) Ref: Reference: AMM Part PP Task 12-12-00-610-801



ATA 20:

33. When you do the Aircraft Grounding for the Refuel/Defuel Operations

a. Connect the ground cable to parking ground point before you connect it to the aircraft

b. Attach the cable to aircraft first then connect to parking ground point

c. Grounding is not necessary

(B1) Ref: Reference: AMM Part PP Task 20-40-11-910-801



ATA 21:

34. Pack overheat condition cause the PACK/ PACK TRIP OFF light to turn on. To reset the system,

a. Push the TRIP RESET switch when PACK/ PACK TRIP OFF turn on.

b. Let the overheat condition to be cooled and then push the TRIP RESET.

c. Do nothing.

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 36



35. The PACK/ PACK TRIP OFF light turns on, possible switches that could cause this

a. Duct overheat switch

b. Cabin overheat switch

c. Compressor discharge overheat switch, turbine inlet overheat switch or pack discharge overheat switch.

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 36



36. B737-800/900, the LEFT recirculating fan operates with the switch in the AUTO position in the AIR, except:

a. When both packs are on and one or both pack switches are selected to HIGH

b. When one pack is off.

c. When both pack switches are selected to AUTO

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 149



37. B737-800/900, the LEFT recirculating fan operates with the switch in the AUTO position on the GROUND, except:

a. When both packs are on and one pack switches are selected to HIGH

b. When one pack is off.

c. When both pack switches are selected to HIGH

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 149



38. The RIGHT recirculating fan operates with the switch in the AUTO position, except:

a. When both pack switches are selected to HIGH

b. When both packs are on and one pack switches are selected to HIGH

c. When one pack is off.

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 149



39. Water separator coalescer (bag) condition indicator will be observed

a. While the pack operates in high flow and the air mix valve is in full cold position.

b. While the pack operates in low flow and the air mix valve is in AUTO position.

c. While the pack operates in low flow and the air mix valve is in full warm position.

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 68



40. The coalescer bag must be changed if the indicator disk is

a. in the blue range

b. In the red range

c. In the amber range.

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 68



41. During flight cruise mode, the RAM DOOR FULL OPEN light is ON

a. This is a normal condition.

b. There is a problem in bleed air system

c. The ram air system has a blockage

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 58



42. During flight cruise mode, the RAM DOOR FULL OPEN light

a. is OFF

b. is ON

c. is ON or OFF depend on the PACK schedules.

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 62



43. Mode(s) of control for the ram air system is(are)

a. Only one mode for all phases.

b. Two modes: On ground and in flight.

c. Three modes: Ground, flight (flaps not up) and flight (flaps up)

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 61



44. When you install a recirculation fan:

a. Make sure the flow arrow on the fan is in the correct direction and shoud point to the distribution manifold.

b. The flow arrow on the fan shoud point out of the distribution manifold.

c. There is not any arrow on the recirculation fan

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 140



45. The recirculation fan is

a. DC powered

b. AC powered

c. Pneumatically powered from APU or engine bleed air

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 144



46. The air supply for the recirculation fans is

a. From the distribution compartment

b. From the collector shroud in the aft cargo compartment

c. From the collector shroud in the forward cargo compartment and the distribution compartment

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 206



47. The E & E compartment is cooled by?

a. The equipment cooling system.

b. The ram air system.

c. The AUTO or STANDBY pressurisation systems

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 244



48. The aft cargo compartment is heated by

a. The exhaust air from the control cabin

b. The air from the passenger compartment through the foot level grilles

c. The exhaust air from the equipment cooling system

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 274



49. The forward cargo compartment is heated by

a. The air from the passenger compartment.

b. The exhaust air from the equipment cooling system

c. The exhaust air from the equipment cooling system and the air from the passenger compartment.

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 274



50. The cabin altitude warning alarm will sound

a. When the cabin altitude increases to more than 10000 feet.

b. When the cabin altitude increases to more than 12000 feet.

c. When the cabin altitude increases to more than 14000 feet.

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 5



51. When the cabin altitude warning alarm sound

a. You can not deactivate the alarm.

b. You can push the ALT HORN CUTOUT switch to deactivate the alarm.

c. You can push the BELL CUTOUT switch to deactivate the alarm.

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 5



52. The maximum cabin altitude for most flight is

a. 10000 feet.

b. 6000 feet

c. 8000 feet

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 5



53. The negative pressure relief valve opens when pressure external to the airplane is X psi more than the pressure in the airplane.

a. X=1.5

b. X=1.0

c. X=2.0

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 58



54. The negative pressure relief valve is

a. Controlled by a switch in the flight compartment.

b. Controlled by a CPC in pressurization system.

c. A mechanical device and operates independently.

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 58



55. If the amber AUTO FAIL light and the green ALTN light come on

a. Positioning the pressurization mode selector to ALTN will extinguish the AUTO FAIL light.

b. It will automatically extinguish when the pressurisation controller reverts to the ALTN mode

c. Positioning the Pressurisation Mode Selector to ALTN will have no effect on the AUTO FAIL light.

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 45, 46



56. The maximum cabin differential pressure for take-off and landing is

a. 0.10psi

b. 0.25psi

c. 0.125psi

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 17



57. The AUTO FAIL light will illuminate when there is

a. A loss of power, or an excessive rate of cabin altitude change (>2000 sea level feet/minute), or a high cabin altitude (>15800 feet).

b. A loss of power, or an excessive rate of cabin altitude change (>1500 sea level feet/minute), or a high cabin altitude (>9800 feet).

c. A loss of power, or an excessive rate of cabin altitude change (>1000 sea level feet/minute), or a high cabin altitude (>14000 feet).

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 45



58. The Aft outflow valve has

a. 2 automatic mode motors and 1 manual mode motor with 2 electronic actuators

b. 1 automatic mode motor and 1 manual mode motor with 1 electronic actuators

c. 2 automatic mode motors and 1 manual mode motor with 1 electronic actuators

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 38



59. The OFF SCHED DESCENT light illuminates if

a. The aircraft has temporarily levelled off before reaching the selected flight altitude (as set on the cabin pressure selector panel)

b. The airplane begin a descent before reaching the selected flight altitude (as set on the cabin pressure selector panel)

c. The aircraft has climbed above the selected flight altitude (as set on the cabin pressure selector panel)

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 50



60. The maximum differential pressure (positive pressure relief valve operation) is

a. 8.95 psi

b. 7.95 psi

c. 8.40 psi

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 56



61. The positive pressure relief valves are

a. Controlled by a switch in the flight compartment.

b. Controlled by a CPC in pressurization system.

c. mechanical devices and operate independently.

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 56



62. What could cause a RAM AIR DOOR Light to come on in cruise

a. Ram air system has a blockage, heat exchangers are dirty, Electrical failure.

b. Compressor outlet overheat c. Missing Ram Air Door

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 62



63. What sensor controls the Ram Air Inlet Doors

a. ACM Compressor Inlet temperature

b. ACM Compressor Oulet - 110°C

c. Pack discharge temperature

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 62



64. What commands the Ram Air Door Actuator

a. Ram Air Controller

b. Ram Air Switch

c. Pack/Zone Temperature Controller

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 62



65. To use the APU for air conditioning, on the ground/engines shut down, you should select

a. Isolation Valve Switch AUTO/ON; APU Bleed Air Switch ON; Left or Right Air Conditioning

Pack Switch AUTO or HIGH

b. Isolation Valve Switch CLOSE; APU Bleed Air Switch ON; Left and Right Air Conditioning Pack Switch AUTO or HIGH

c. Isolation Valve Switch CLOSE; APU Bleed Air Switch ON; Left or Right Air Conditioning Pack Switch AUTO or HIGH

(B1) Ref: Reference: AMM Part PP Task 21-00-00-800-803



66. What is the location of and reason for the Pressure Equalisation Valves?

a. Aft cargo compartment, allow temperature to be regulated

b. Aft of each cargo compartment, keeps the cargo compartment pressure as the same level as cabin pressure

c. Fwd and Aft of FWD cargo compartment, allow equalisation of cargo pressure

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 62



67. A differential pressure of X psid will push the cargo compartment blowout panel out of the frame.

a. X=1.5

b. X=1.0

c. X=2.0

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 60



68. During a cabin pressure leak test what is maximum differential pressure for a normal test?

a. 6 psi

b. 8 psi

c. 4 psi

(B1) Ref: Reference: AMM Part PP Task 05-51-91-790-801



69. B737-600/700, the bleed air from the pneumatic manifold will go through these PACK component in sequence?

a. FCSOV-Primary HX- ACM compressor-Secondary HX-ACM Turbine-Water separator-Conditioned Air Check Valve

b. FCSOV-Primary HX- ACM compressor-Secondary HX-Reheater-Condenser-Water extractors- Reheater-ACM Turbine-Condenser-Conditioned Air Check Valve

c. FCSOV-Secondary HX- ACM compressor-Primary HX-ACM Turbine-Water extractors- Conditioned Air Check Valve

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 33



70. B737-800/900, the bleed air from the pneumatic manifold will go through these PACK component in sequence?

a. FCSOV-Primary HX- ACM compressor-Secondary HX-ACM Turbine-Water separator-Conditioned Air Check Valve

b. FCSOV-Primary HX- ACM compressor-Secondary HX-Reheater-Condenser-Water extractors- Reheater-ACM Turbine-Condenser-Conditioned Air Check Valve

c. FCSOV-Secondary HX- ACM compressor-Primary HX-Reheater-Condenser-Water separator- Reheater-ACM Turbine-Condenser-Conditioned Air Check Valve

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 33



71. B737-600/700, in EE compartment, there are

a. 01 air conditioning accessory unit (ACAU and 02 cabin temperature controller (CTCs)

b. 02 air conditioning accessory units (ACAUs) and 02 pack/zone controllers (PZCs)

c. 01 air conditioning accessory unit (ACAU and 01 cabin temperature controller (CTC)

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 30



72. B737-800/900, in EE compartment, there are

a. 01 air conditioning accessory unit (ACAU and 02 cabin temperature controllers (CTCs)

b. 02 air conditioning accessory units (ACAUs) and 02 pack/zone controllers (PZCs)

c. 01 air conditioning accessory unit (ACAU and 01 pack/zone controller (PZC)

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 30



73. B737-600/700, when the PACK switch is in AUTO position (normal flow), the flow rate of the air is

a. 55 ppm

b. 65 ppm

c. 80 ppm

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 42



74. B737-600/700, when the PACK switch is in HIGH position (high flow), the flow rate of the air is

a. 60 ppm

b. 80 ppm

c. 100 ppm

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 42



75. B737-600/700, when the PACK switch is in HIGH position, the airplane is on ground with APU supplying bleed air (APU high flow), the flow rate of the air is

a. 80 ppm

b. 100 ppm

c. 120 ppm

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 42



76. B737-800/900, when the PACK switch is in AUTO position (normal flow), the flow rate of the air is

a. 65 ppm

b. 75 ppm

c. 80 ppm

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 42



77. B737-800/900, when the PACK switch is in HIGH position (high flow), the flow rate of the air is

a. 90 ppm

b. 105 ppm

c. 115 ppm

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 42



78. B737-800/900, when the PACK switch is in HIGH position, the airplane is on ground with APU supplying bleed air (APU high flow), the flow rate of the air is

a. 115 ppm

b. 131 ppm

c. 140 ppm

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 42



79. The PACK flow is in the APU high flow mode when

a. The airplan is on the ground, the pack switch is in the HIGH position, the APU operates above 95%

b. The pack switch is in the HIGH position, the APU bleed switch is in the ON position, the APU operates above 95%, the airplan is on the ground.

c. The APU bleed switch is in the ON position, the APU operates above 95%, the airplan is on the ground

(B1) Ref: Reference: ATA 21 Air Conditioning (1) - B737 Training book - Page 44



80. The pressurization control is in the AUTO mode, if single channel failure occures, there are these indications

a. Amber AUTO FAIL light comes on, MASTER CAUTION and AIR COND annuciator lights come on, green ALTN light come on.

b. Amber ALTN and AUTO FAIL light come on, MASTER CAUTION and AIR COND annuciator lights come on.

c. Amber AUTO FAIL light comes on, the FLT ALT display shows five dashes.

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 45, 46



81. In the pressurization control system, if dual channel failure occures, there are these indications

a. The AUTO FAIL and MASTER CAUTION lights come on, the FLT ALT and LAND ALT displays show five dashes.

b. Amber ALTN and AUTO FAIL light come on, MASTER CAUTION and AIR COND annuciator lights come on.

c. Amber AUTO FAIL light comes on, the FLT ALT display shows five dashes.

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 45



82. The green ALTN light comes on when

a. Two CPC controllers fail and the backup system is active.

b. One CPC controller fails and the backup system is active.

c. One CPC controller fails and the manual system is active.

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 45,46



83. In the pressurization control system, there are two digital cabin pressure controllers (CPCs). Choose the correct state?

a. Two CPCs controll the system at the same time.

b. One CPC controlls the system at a time, the other is a backup. The system changes active control from one CPC to the other with each flight.

c. Only one CPC controls the system for the whole flight. There is no backup. The system changes active control from one CPC to the other with each flight.

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 41



84. The cabin pressure controllers use data from these system:

a. 2 ADIRUs, 2 SMYDs and PSEU

b. 1 ADIRUs, 1 SMYDs

c. 1 ADIRUs, PSEU

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 41



85. The MANUAL light comes on when

a. Both CPCs are not active.

b. The selector switch is in the MANUAL position.

c. The selector switch is in the ALTN position.

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 48



86. Which one is correct for the pressure equalization valve?

a. The pressure equaliztion valve has two swing check valve and spring-loaded to close position.

b. The pressure equaliztion valve has butterfly plate and is control from flight compartment.

c. he pressure equaliztion valve has two swing check valve and is controlled by CPC.

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 62



87. The aft outflow valve goes to full closed if the cabin pressure altitude gets to 14.650 feet. This is the function of:

a. A fail-safe aneroid switch on each electronic actuator of the valve in normal automatic control only.

b. A switch on the flight compartment.

c. A fail-safe aneroid switch on each electronic actuator of the valve in any mode of cabin pressurization system.

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 38



88. To move the aft outflow valve to a desired position, you have to

a. Move the mode selector AUTO position and use outflow valve toggle switch.

b. Move the mode selector ALTN position and use outflow valve toggle switch.

c. Move the mode selector MANUAL position and use outflow valve toggle switch.

(B1) Ref: Reference: ATA 21 Air Conditioning (2) - B737 Training book - Page 15



ATA 22:

89. Choose the correct state: when doing the stall warning system (SWS) test,

a. Use only one switch to do the test of both system

b. Switch No.1 is for SWS 1 with operation of control column shaker on captain control column, Switch No.2 is for SWS 2 with operation of control column shaker on first officer control column.

c. Switch No.1 is for SWS 1 and Switch No.2 is for SWS 2 with operation of both control column shakers when pushing each switch.

(B1) Ref: Reference: ATA 22 Auto Flight - B737 Training book - Page 39



90. How can you know the SWS has faults?

a. Pushing the SWS test switch and the fault light coms on.

b. Pushing the SWS test switch and the on side control column shaker operates

c. Pushing the SWS test switch and the on side control column shaker does not operate.

(B1) Ref: Reference: ATA 22 Auto Flight - B737 Training book - Page 39



91. For primary yaw damping, what is correct for rudder movement?

a. Rudder movement is limited to 2 degrees with flaps up and 3 degrees with flaps not up.

b. Rudder movement is limited to 2 degrees.

c. Rudder movement is limited to 3 degrees.

(B1) Ref: Reference: ATA 22 Auto Flight - B737 Training book - Page 47



92. To put the WTRIS and standby yaw damper on, do these steps

a. Put the FLT CONT A and B switches to OFF position; Put the yaw damper switch to ON.

b. Put the FLT CONT A and B switches to positions other than the ON position; Put at least one of these switches to STBY RUD; Put the yaw damper switch to ON.

c. Put the FLT CONT A and B switches to positions other than the ON position; Put the yaw damper switch to OFF.

(B1) Ref: Reference: ATA 22 Auto Flight - B737 Training book - Page 61



93. What is the function of the mach trim system?

a. The mach trim system moves the elevators to prevent a nose down maneuver at high speeds.

b. The mach trim system moves the ailerons to prevent a nose down maneuver at high speeds

c. The mach trim system moves the stabilizers to prevent a nose up maneuver at high speeds (B1) Ref: Reference: ATA 22 Auto Flight - B737 Training book - Page 204



94. The autothrottle function is in

a. Flight control computer B (FCC B)

b. Flight control computer A (FCC A)

c. Flight control computer A and B (FCC A+FCC B)

(B1) Ref: Reference: ATA 22 Auto Flight - B737 Training book - Page 326



95. During an autoland, the alert messages do not show when the airplane

a. Less than 200 feet above the runway.

b. Less than 300 feet above the runway.

c. Less than 400 feet above the runway.

(B1) Ref: Reference: ATA 22 Auto Flight - B737 Training book - Page 219



96. You push either master caution recall switch, the mach trim fail light comes on. You then push the master caution reset switch, the light goes off.

a. The mach trim funcion is normal.

b. There is only one function failure in the FCC system.

c. There are two function failures in the FCC system.

(B1) Ref: Reference: ATA 22 Auto Flight - B737 Training book - Page 208



97. To do the A/T BITE test, you use

a. A/T computer BITE module

b. FCC BITE module

c. The CDU

(B1) Ref: Reference: ATA 22 Auto Flight - B737 Training book - Page 383



98. When does the red A/P annunciator flash? a. When an A/P changes from CMD to CWS.

b. When an A/P disconnects.

c. When the power up test fails on the ground

(B1) Ref: Reference: ATA 22 Auto Flight - B737 Training book - Page 164



99. The autopilot has these actuators:

a. Four autopilot actuators:two actuators control the ailerons and two actuators control the elevators

b. Four autopilot actuators: one actuator controls the ailerons, one actuator controls rudder and two actuators control the elevators

c. our autopilot actuators: one actuator controls the ailerons, two actuators controls rudder and one actuator control the elevators

(B1) Ref: Reference: ATA 22 Auto Flight - B737 Training book - Page 144



100. How to disengage autopilot (A/P)?

a. By the A/P disengage switch on captain control wheel.

b. By the A/P disengage switch on captain/first officer control wheel or A/P disengage bar

c. By the A/P disengage switch on the thrust levers.

(B1) Ref: Reference: ATA 22 Auto Flight - B737 Training book - Page 157, 161



101. How to cancel the autothrottle (A/T) disengage warning?

a. Push the red ASA A/T light or one of the A/T disconnect switches on the thrust levers.

b. Push the red ASA A/T light or one of the A/T disconnect switches on control wheels.

c. Push the A/T Warning Cancel Switch on overhead panel

(B1) Ref: Reference: ATA 22 Auto Flight - B737 Training book - Page 331



102. What is not the A/T mode showing on FMA?

a. THR HLD

b. ADVANCED

c. RETARD

(B1) Ref: Reference: ATA 22 Auto Flight - B737 Training book - Page 356



103. What happens when you push the A/T disconnect switch?

a. The autothrottle system disengage and the MCP A/T arm switch goes to OFF.

b. The autothrottle system disengages, the ASA A/T amber warning light goes on and off.

c. The autothrottle system disengages, the ASA A/T red warning light goes on and off and the MCP A/T arm switch goes to OFF.

(B1) Ref: Reference: ATA 22 Auto Flight - B737 Training book - Page 345



104. Both master flight director indicator (MA) lights on the MCP panel are illuminated during Takeoff Roll indicate?

a. Approach mode is armed.

b. Independent Flight Director operation.

c. Flight Director malfunction.

(B1) Ref: Reference: ATA 22 Auto Flight - B737 Training book - Page 144



ATA 23:

105. When the ACP ALT/NORM is in ALT, the flight interphone system operates in the emergency mode for that station. How can the pilot use the ACP?

a. The BOOM-MASK switch and the R/T or RADIO position of the PTT switch are the only ACP switches that operate.

b. The BOOM-MASK switch and the hand-mic operate.

c. The R/T or RADIO position of the PTT switch and the hand-mic operate.

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 47



106. A microphone (mic) on these components lets the flight crew speak on the flight interphone system.

a. Oxygen mask and headset boom mic.

b. Oxygen mask, headset boom mic and hand mic

c. Headset boom mic and hand mic

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 32



107. The VHF communications system operates in the frequency range of

a. 2.000 MHz to 29.999 MHz

b. 99.100 MHz - 120.00 MHz

c. 118.000 MHz to 136.975 MHz

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 153



108. To do a test of the 121.5/243.0 MHz ELT transmitter:

a. Use a VHF transceiver to listen to the ELT transmission

b. Use special test equipment

c. Use a HF transceiver to listen to the ELT transmission

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 247



109. Pushing the ATTEND switch on the forward overhead panel in the flight compartment, what will happen?

a. A blue light on all the cabin exit locator signs comes on.

b. The passenger address system sends a HI/LO chime to the cabin speakers two times.

c. A pink light on all the cabin exit locator signs comes on and the passenger address system sends a HI/LO chime to the cabin speakers

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 59



110. The cockpit CALL (blue) light will illuminate along with an associated chime whenever the cockpit is being called

a. By the flight attendants only

b. By the flight attendants or the ground crew

c. By the ground crew only

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 59 and 91



111. Is it possible for the cabin attendants to communicate with the ground personnel from their respective stations

a. Yes, using the flight interphone system with the Service Interphone switch selected OFF

b. No

c. Yes, using the service interphone system.

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 73



112. Pushing the GRD CALL switch in the flight compartment to call the ground crew, what will happen?

a. A blue light on the external power panel comes on.

b. A horn in the nose wheel well makes a sound.

c. A blue light on the external power panel comes on and a horn in the nose wheel well makes a sound.

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 90



113. VHF communication system has

a. Three antennas. One antenna is on the top of the fuselage and two antennas are on the bottom of the fuselage

b. Three antennas. Two antennas are on the top of the fuselage and one antenna is on the bottom of the fuselage

c. Two antennas. One antenna is on the top of the fuselage and one antenna is on the bottom of the fuselage

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 141,142



114. In PA system, audio output has this order of priority

a. Flight compartment announcements, flight attendant announcements, pre-recorded announcements, boarding music

b. Flight compartment announcements, pre-recorded announcements, flight attendant announcements, boarding music.

c. There is no priority in the system.

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 120



115. The HF communications system operates in the frequency range of

a. 2.000 MHz to 29.999 MHz

b. 99.100 MHz - 120.00 MHz

c. 118.000 MHz to 136.975 MHz

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 176



116. To do a test of the 406 MHz ELT transmitter:

a. Use a VHF transceiver to listen to the ELT transmission

b. Use special test equipment

c. Use a HF transceiver to listen to the ELT transmission

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 247



117. How long can the voice recorder unit keep communication data in memory?

a. The last 90 minutes

b. The last 100 minutes

c. The last 120 minutes

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 358



118. Where can you find a service interphone jack?

a. At all flight attendance stations.

b. P19 external power panel, electronic equipment compartment, fueling station, left/right wheel well, Aft cabin on the ceiling, APU service area.

c. External power panel only

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 81



119. How can you erase the audio that the voice recorder keeps?

a. You can not erase the audio of the voice recorder.

b. Use the erase switch when the airplane is in the air.

c. Use the erase switch when the airplane is on the ground, and the parking brake is set.

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 359



120. When the captain ALT/NORM switch is in the ALT position,

a. Only VHF-1 is set as the communication system on captain side.

b. Only VHF-2 is set as the communication system on captain side.

c. VHF-1 and VHF-2 are set as the communication system on captain side.

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 47



121. When the F/O ALT/NORM switch is in the ALT position,

a. Only VHF-1 is set as the communication system on F/O side.

b. Only VHF-2 is set as the communication system on F/O side.

c. VHF-1 and VHF-2 are set as the communication system on F/O side.

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 47



122. When the voice recorder switch is in AUTO position,

a. The voice recorder gets power when when DC bus 1 is powered.

b. The voice recorder gets power when when DC bus 2 is powered.

c. The voice recorder always gets from the engine start until 5 minutes after engine stop.

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 358



123. The emergency locator transmitter (ELT) system automatically sends emergency signals

a. On the VHF channel only.

b. On the UHF channel only.

c. On the VHF and UHF channels

(B1) Ref: Reference: ATA 23 Communications - B737 Training book - Page 231



ATA 24:

124. The STANDBY PWR OFF light (amber) illuminated means

a. The AC standby bus is inactive.

b. The Hot Battery Bus is inactive

c. The DC 1 bus is inactive.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 29



125. The AC transfer bus 1 does not have power, the stanby buses and battery bus have power when

a. The standby power switch is in the AUTO position, the BAT switch is in the ON position.

b. The standby power switch is in the AUTO position, the BAT switch is in the OFF position.

c. The standby power switch is in the OFF position, the BAT switch is in the ON position.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 29



126. Choose the INCORRECT statement about BPCU:

a. The BPCU gives the protection logic for overvoltage faults.

b. The BPCU gives the protection logic for undervoltage faults.

c. The BPCU does not give the protection logic for overcurrent faults.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 59



127. The TR UNIT light will illuminate to indicate a TRU fail condition in flight if

a. TRU 2 and TRU 3 fail.

b. TRU 3 fails

c. TRU 2 fails

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 25



128. The ELEC light will illuminate in flight with

a. The DC system failure

b. The stanby system failure

c. The amber ELEC light comes on only when the airplane is on the ground.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 25



129. The ELEC light gives a failure indication of

a. The normal power system

b. The DC system

c. The AC system

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 25



130. To connect the external Ground power to the transfer busses

a. The Battery switch must be OFF

b. The Battery switch must be ON

c. The Bus Transfer switch must be in the AUTO position.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 59



131. In flight, the left SOURCE OFF light comes on,

a. The AC transfer bus 1 is de-energized

b. The AC transfer bus 1 is powered from AC standby bus.

c. IDG 2 power AC transfer bus 1

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 33



132. The amber DRIVE light comes on and a manual disconnect is done. Can the IDG be reset?

a. Yes, in flight with the drive disconnect switch.

b. No, IDG must be replaced.

c. Yes, on ground at the IDG.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 81



133. The IDG is automatically disconnected when the IDG oil temperature gets too hot. Can the IDG be reset on-wing?

a. Yes, IDG is automatically reset when oil temperature decreases.

b. Yes, on ground at the IDG.

c. No, you must remove and disassemble the IDG to reset a thermal disconnect.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 81



134. Which is the power source for the AC standby bus

a. Transfer bus 1 under normal conditions

b. Transfer bus 2

c. AC main bus 1

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 13



135. Which is the power source for the DC standby bus

a. DC bus 1 under normal conditions

b. DC bus 2

c. TRU 3

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 13



136. The IDGs are the normal power sources for

a. The main buses

b. The AC transfer buses

c. The ground service buses

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 13



137. Which is the power source for the the battery bus

a. TRU 3 under normal conditions

b. DC bus 1

c. DC bus 2

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 13



138. On the ground, with the battery switch OFF and STANBY POWER Switch in AUTO, the Battery Bus is

a. Powered by TRU 3

b. Not powered

c. Powered by the Hot Battery Bus

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 29, 30



139. An illuminated TR UNIT light while on the ground indicates that at least two TRUs have failed.

a. True

b. False

c. Not given.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 25



140. The DC bus tie relay opens when

a. Airplane is in cruise mode, bus transfer switch is in the AUTO position and AC transfer bus 1 has power

b. Airplane is in cruise mode, bus transfer switch is in the AUTO position and AC transfer bus 2 has power

c. Autopilot system is in the approach mode with glideslope capture, bus transfer switch is in the AUTO position and AC transfer buses have power

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 147



141. The battery charger takes 3 phase, 115v ac power and converts it to DC power with

a. Constant voltage output in the transformer rectifier mode.

b. Constant voltage output in the charge mode.

c. Variable voltage output in the transformer rectifier mode.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 155



142. The amber BAT DISCHARGE light comes on when

a. Current draw is more than 100 amps for 10 seconds. b. Current draw is more than 100 amps for 12 seconds.

c. Current draw is more than 100 amps for 1.2 seconds.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 158



143. The electrical system incorporates an automatic load shedding feature in case of overcurrent load shed. What is (are) the bus(es) that is normally shed first?

a. Galley and main buses on transfer bus 1 are shed first.

b. Galley and main buses on transfer bus 2 are shed first.

c. The AC standby bus is shed first

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 191



144. On the external power receptacle, the NOT IN USE light comes on, it means

a. External power is available, the EPC open, both ground service transfer relays are de-energized

b. External power is available, the EPC close, both ground service transfer relays are de-energized

c. External power is available, the EPC close, both ground service transfer relays are energized (B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 49



145. The external power receptacle has these six pins:

a. Three pins for each AC power phase, two pin for ground, one short pins for BPCU interlock logic.

b. Three pins for each AC power phase, one pin for ground, two short pins for BPCU interlock logic.

c. Three pins for each AC power phase, one pin for ground, one short pins for BPCU interlock logic, one short pins for back up.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 50



146. The electrical system design makes sure that

a. Two AC power sources can not supply power to the same transfer bus at the same time

b. one AC power source can not supply power to both transfer buses

c. Two AC power sources can supply power to the same transfer bus at the same time

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 12



147. To replace the Integrated Drive Generator, you will access to?

a. The forward face of the engine main gearbox

b. The aft face of the engine accessory gearbox

c. The forward face of the engine accessory gearbox

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 17



148. The amber DRIVE light comes on if

a. The IDG oil pressure is more than the minimum operation limit or there is an underfrequency with the engine running.

b. The IDG oil pressure is less than the minimum operation limit and there is an overfrequency with the engine running.

c. The IDG oil pressure is less than the minimum operation limit or there is an underfrequency with the engine running.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 29



149. When an amber TRANSFER BUS OFF light is on,

a. The GCB and BTB are open

b. The GCB close and the BTB are open

c. The GCB or the BTB are open

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 15,33



150. Configuration load shed occurs when the APU is the only source of AC power in flight. To reset the galley and main buses relays,

a. Anytime, move the cabin utility switch to OFF and back to the ON position.

b. After landing, move the cabin utility switch to OFF and back to the ON position.

c. After landing, move the cabin utility switch to OFF position

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 190



151. The overcurrent limits for a generator or external power source to cause load shed:

a. 340 amps (nominal) for 274 seconds

b. 274 amps (nominal) for 340 seconds

c. 340 amps (nominal) for 5 seconds

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 186



152. The GCU closes the breaker only when power is good and no other power source is on the bus.

a. True

b. False

c. Not given.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 10



153. The ground service switch at forward attendant panel is used to

a. Supply power to ground service bus 1 and 2 from transfer buses.

b. Supply external power to ground service bus 1 and 2 with external power connected.

c. Supply power to ground service bus 1 and 2 from main buses.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 22



154. The blue GRD POWER AVAILABLE light comes on when

a. The external power is connected and the power quality is good.

b. The external power supplies to transfer buses

c. The external power supplies to ground service buses

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 33



155. The CSD section turns the generator at a constant speed of

a. 12,000 RPM.

b. 24,000 RPM.

c. 40,000 RPM.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 81



156. Thermal IDG automatically disconnect occurs at

a. 182 C

b. 363 C

c. 633 C

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 82



157. In the IDG oil cooling system, which cooler that the oil goes through first?

a. AIR/OIL COOLER

b. IDG OIL COOLER

c. IDG OIL and AIR/OIL COOLERS ath the sam time.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 82



158. At the IDG OIL COOLER, the IDG oil is cooled by

a. Engine bypass air

b. Engine fuel

c. Engine hydraulic.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 82



159. The amber DRIVE light comes on if the IDG oil pressure decreases to less than the minimum operating limit of

a. 105 psi

b. 115 psi

c. 165 psi

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 82



160. When doing the IDG oil servicing, you must

a. Mix different oil types together.

b. Push the push-to-vent-valve 30 seconds and then pump the oil as fast as possible.

c. Push the push-to-vent-valve 15 seconds and then add oil slowly.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 85, 87



161. The APU is supplying power to the airplane, GRD POWER AVAILABLE light is on, you turn the GRD PWR to ON position.

a. APU power disconnects, ground power connects to airplane.

b. You can not connect the ground power.

c. APU power and ground power connect to airplane at the same time.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 128



162. On the external power receptacle, the CONN light comes on, it means

a. External power is connected and power quality is good.

b. External power is connected.

c. The ground power quality is good.

(B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 60



163. These breakers are in power distribution panel 1 (P91)

a. Bus tie breaker 1 (BTB 1), Auxiliary power breaker (APB), Generator control breaker 1 (GCB 1)

b. Bus tie breaker 2 (BTB 2), External power contactor (EPC), Generator control breaker 1 (GCB 1)

c. Bus tie breaker 1 (BTB 1), External power contactor (EPC), Generator control breaker 1 (GCB 1) (B1) Ref: Reference: ATA 24 Electrical Power System - B737 Training book - Page 112



ATA 25:

164. How to put the escape slide to arm mode?

a. Remove the girt bar from the stowage hooks on the door and install it in the floor brackets

b. Move the arm/ disarm level to the arm position.

c. Move the door mode switch to ARM position.

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 45



165. In case the escape slide does not inflate automatically,

a. Push and pull the inflation handle 20 times to inflate the escape slide manually

b. Pull the inflation handle sharply to inflate the escape slide manually

c. Push the inflation switch on the inflation cylinder

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 45



166. How to open the passenger service units (PSUs)?

a. Remove four screws and the lanyard then lower the PSU.

b. Push the PSU up to release the latch, then lower the PSU

c. Insert a small allen wrench or other applicable tool into the latch release hole then lower the PSU.

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 21



167. How to deflate the slide after inflation test?

a. Open the relief valve

b. Hold the aspirator flapper valve open

c. Open the deflation valve

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 49



168. What precaution should be taken when removing a door escape slide?

a. You must install the safety pin to lock the inflation valve.

b. You must remove the safety pin to lock the inflation valve

c. You must remove the airplane power.

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 49



169. Where does the escape slide incandescent light get power from?

a. The 28v dc HOT BAT BUS

b. A battery in a battery pocket which attaches to the inflation cylinder bag

c. The 28v dc STBY BUS

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 51



170. How to remove the flight crew seats?

a. First remove stops on the inboard seat tracks. Then slide the seats forward off the tracks.

b. First remove stops on the outboard seat tracks, then slide the seats aftward off the tracks

c. First remove stops on the outboard seat tracks, then slide the seats forward off the tracks

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 7



171. A fusible plug protects the inflation cylinder of the scape slide from high temperatures. The plug opens at

a. A temperature of 200F

b. A temperature of 174F

c. A temperature of 120F

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 49



172. How to check an escape slide inflation cylinder pressure?

a. Through the pressure indicator window.

b. Pop out indicator

c. The cylinder must be removed and weighted

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 49,50



173. A pressure relief valve protects the cylinder of the scape slide from too much pressure. The relief valve opens at

a. 4.500 psig

b. 3.000 psig

c. 5.000 psig

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 49



174. To prevent overpressurization, the relief valve opens when the escape slide is at the correct operating pressure of

a. 7.5 psig

b. 5 psig

c. 2.75 psig

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 49



175. How to activate the incandescent lighting system of the escape slide?

a. By moving the activation switch to ON.

b. By pressing the activation switch.

c. It is automatic during inflation of the slide.

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 45



176. How to access to the overwing escape straps?

a. Open the cabin over bin near the the emergency exit door to access to stowage box.

b. Remove the emergency exit door and the escape strap is in a stowage tube in the ceiling of the passenger compartment

c. Remove the emergency exit door and the escape strap is in a stowage box on the door frame.

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 37,38



177. Where can you find the flight crew escape lanyards?

a. The rope and stowage bag are behind doors in the flight compartment lining above the number 2 windows

b. The rope and stowage bag are behind doors in the flight compartment lining above the number 1 windows

c. The rope and stowage bag are under flight crew seats.

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 39



178. Choose the correct statement about the flight crew escape lanyards

a. The lanyard core is a carbon cord rated at 2000 pounds

b. The lanyard core is a nylon cord rated at 1000 pounds

c. The lanyard core is a kevlar cord rated at 1500 pounds.

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 39



179. The windscreens are crushed-core composite panels. They are attached to airplane structure by

a. Floor mounts, tie rod and quick-disconnect fitting.

b. Fasteners and rivets.

c. Quick-disconnect fittings.

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 25



180. The air return grilles let air move from the upper lobe to the lower lobe for

a. Normal conditioned air circulation.

b. Normal conditioned air circulation and air circulation during rapid decompression

c. Air circulation during rapid decompression

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 19

181. Insulation blankets are between the linings and fuselage skin throughout the passenger compartment. They are made of

a. Fiberglass

b. Titanium

c. Carbon fiber.

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 14



182. How are the passenger compartment insulation blanket secured to the fuselage and other blankets?

a. By snaps, tape, and fasteners

b. By snaps, fasteners and stitching

c. By snaps, tape, and stitching.

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 15



183. In passenger compartment, The service outlets can provide

a. Only 115v ac power

b. 115v ac and 28v dc power

c. Only 28v dc power

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 11



184. How many observers seats can be installed in flight compartment?

a. One observers seat.

b. Two observers seats

c. Three observers seats.

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 9



185. The inner pane of inner window is between the reveal and trim ring. It is made of

a. Plastic

b. Glass

c. Two layer: plastic and glass

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 17



186. These are typical emergency equipment:

a. Overwing escape straps, detachable emergency equipment and escape slides.

b. Escape lanyards, overwater survival equipment and detachable emergency equipment.

c. Overwing escape straps, escape lanyards, overwater survival equipment, detachable emergency equipment and escape slides.

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 35



187. Why are you careful not to damage the insulation blanket surfaces?

a. Damage will be propagted to the whole insulation blanket.

b. The water can go into the fiber center and will reduce the blanket efficiency, increase weight, and can cause mold problems.

c. The air can go into the fiber center and will reduce the blanket efficiency.

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 15,33



188. The main purpose of the passenger compartment insulation blankets are to

a. Thermally and acoustically insulate the passenger compartment

b. Keep the passenger compartment warmer.

c. Acoustically insulate the passenger compartment

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 14



189. The main purpose of the cargo compartment insulation blankets are to

a. Keep the contents of the cargo compartments warmer when the airplane is on ground

b. Keep the contents of the cargo compartments warmer when the airplane is in flight

c. Acoustically insulate the cargo compartments when the airplane is in flight

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 32



190. How are the cargo compartment insulation blanket fastened to the structure and together?

a. By plastic studs and clips, nylon lacing and Hook-and-loop tape.

b. By metal fasteners, nylon lacing and Hook-and-loop tape

c. By plastic studs and clips, metal fasteners and Hook-and-loop tape

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 32



191. Passenger service units (PSUs) provide these functions for passengers

a. Emergency oxygen and call switches

b. Advisory information and call switches

c. Emergency oxygen, advisory information and call switches

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 21



192. Attendant service units (ASUs) and lavatory service units (LSUs) provide the function(s)

a. Emergency oxygen and call switches for attendants or passengers

b. Emergency oxygen, advisory information for attendants or passengers

c. Emergency oxygen for attendants or passengers

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 23



193. How long will the escape slide fully inflate?

a. In approximately six seconds

b. In approximately eight seconds

c. In approximately ten seconds

(B1) Ref: Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 45



ATA 26:

194. Except at the mounting clips, what is the minimum clearance between the overheat detector element and the structure?

a. 0.50 inch.

b. One inch.

c. Three inches.

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 112, 122



195. It is recommened that do not bend the overheat detector element in a radius less than

a. Two inches (5 cm)

b. Three inches (8 cm)

c. One inch (2.5 cm)

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page112,122



196. How to do the test of the wing and body overheat detection system?

a. Push and releas the P5 OVHT TEST switch.

b. Push and hold the P5 OVHT TEST switch for 2 seconds.

c. Push and hold the P5 OVHT TEST switch for 5 seconds.

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 126

197. What does the fire protection systems monitor?

a. Fire, smoke and overheat conditions

b. Fire, smoke, overheat and pneumatic duct leaks contions.

c. Fire, overheat and pneumatic duct leaks

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 6



198. Each engine fire detection system has

a. Two fire detection loops, A and B, with four fire detectors in each loop.

b. One fire detection loop with four fire detectors.

c. Two fire detection loops, A and B, with two fire detectors in each loop.

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 13



199. During engine fire/ overheat test, finding left engine fire/ detector loop A inoperative, how to configure the system for dispatch?

a. Move the left engine OVHT DET switch to A position.

b. Move the left engine OVHT DET switch to B position.

c. Move the left engine and right engine OVHT DET switches to B position.

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 14



200. The OVHT DET switches are in the NORMAL position, the FAULT light on Engine and

APU fire control panel comes on without any test.

a. Two loops on one engine have a fault condition.

b. One loop on one engine has a fault condition.

c. One loop on each engine has a fault condition.

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 22



201. The filter drier removes moisture, filters debris, and meters the flow of halon during release

a. from cargo fire extinguishing bottle 1

b. from cargo fire extinguishing bottle 1 and bottle 2

c. from cargo fire extinguishing bottle 2

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 88



202. The filter drier meters the halon gas so that the halon level in the cargo compartment stays above 3%.

a. For 120 minutes

b. For 195 minutes

c. For 160minutes

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 88



203. When does the BOTTLE DISCHARGED or DISCH amber light on control panel come on?

a. When the related extinguisher bottle pressure is less than 250 psi.

b. When the related extinguisher bottle pressure is less than 300 psi.

c. When the related extinguisher bottle pressure is less than 350 psi.

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 36, 60, 90



204. The airplane lands within 60 minutes of discharging the first extinguishing into the cargo compartment, what is recommended?

a. Electrical power must be kept to reset 60-minute timer count down.

b. All electrical power must be removed from the airplane or all fire detection/suppression circuit breakers must be pulled and reset

c. There are not any recommendations

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 92



205. When the test switch is in the FAULT/ INOP position, what indications in the flight compartment shows that the system is good?

a. Amber FAULT and amber APU DET INOP light come on

b. MASTER CAUTION light, amber FAULT and amber APU DET INOP light come on

c. MASTER CAUTION light, OVHT/DET annunicator light, amber FAULT and amber APU DET INOP light come on

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 21



206. What statement is correct?

a. The APU fire detection has one loop with three detectors.

b. The APU fire detection has two loops with six detectors. c. The APU fire detection has one loop with two detectors.

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 46



207. What is the function of the compartment overheat detection controller?

a. Monitor sensing elements for overheat and fire conditions in the wing and body areas

b. Monitor sensing elements for overheat and fire conditions in the wheel well.

c. Monitor sensing elements for overheat and fire conditions in the wheel well and the wing and body areas

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 124



208. The cargo compartment smoke detector gives an alarm signal if

a. It senses smoke or it senses air temperature more than 230F (110C)

b. It senses smoke.

c. it senses air temperature more than 230F (110C).

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 68



209. The wheel well fire detection system uses overheat sensing elements to monitor for high temperature conditions in

a. The main wheel well.

b. The nose wheel well

c. The nose and main wheel well

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 108,112



210. Doing the test of the lavatory smoke detector, how to know the the detector is operating normally?

a. The green LED and external indications will be on.

b. The horn will operate and the green LED and external indications will be on.

c. The horn will operate and the red LED and external indications will be on (B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 102



211. What function does not include in engine and APU fire protection system?

a. Engine overheat

b. APU overheat

c. Engine fire

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 33



212. The engine and APU fire extinguisher bottles are spherical. Each bottle contains

a. Halon and nitrogen at a pressure of 800 psi at a temperature of 70F (21C)

b. Halon and nitrogen at a pressure of 1800 psi at a temperature of 70F (21C)

c. Carbon powder and nitrogen at a pressure of 800 psi at a temperature of 70F (21C)

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 28, 54



213. How to to discharge the APU fire extinguisher bottle to the APU compartment by using APU ground control panel?

a. Pull down the APU fire control handle and then turn the handle to the left.

b. Pull down the APU fire control handle and then use the fire extinguisher toggle switch.

c. Pull down the APU fire control handle and then turn the handle to the right.

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 58



214. What type of sensing/ detector element is used in the main wheel well , wing and body overheat detections?

a. Photoelectric

b. Thermistor

c. Gas pressure

(B1) Ref: Reference: ATA 26 Fire Protection - B737 Training book - Page 112, 122



ATA 27:

215. The primary flight controls consist of rudder, ailerons and

a. Spoilers

b. Flaps

c. Elevators

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 10



216. Roll control is provided by the ailerons, assisted by the

a. Flight spoilers

b. Ground spoilers

c. Flight spoilers & ground spoilers

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 13



217. To operate the Feel system, the Elevator Feel Computer uses

a. Hydraulics system A

b. Hydraulics system B

c. Hydraulics system A and Hydraulics system B

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 34



218. The Power Transfer Unit provides an alternate source of power for the Autoslat System if:

a. A loss of Hydraulic System A pressure is sensed

b. The Alternate Flaps Position Switch is momentarily held down

c. A loss of pressure from the Hydraulic System B engine pump is sensed .

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 434



219. What is the number of ground spoilers located on each wing?

a. 1

b. 2

c. 3

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 79



220. What is the number of flight spoilers located on each wing?

a. 2

b. 3

c. 4

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 79



221. The FEEL DIFF PRESS light indicates:

a. A loss of pressure in the elvator feel computer

b. An excessive differential pressure in the elevator feel computer.

c. A failure of an FCC channel

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 26



222. The LE FLAPS TRANSIT amber light on the centre instrument panel

a. Is inhibited during flap load relief operation.

b. Is not inhibited during autoslat operation in flight.

c. when an LE flap or slat is not in the correct position or when an LE uncommanded motion occurs.

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 453



223. The SPEED BRAKE DO NOT ARM light shows if

a. there are automatic speedbrake system inputs that are not valid.

b. there are automatic speedbrake system inputs that are valid

c. there is a fault with the ground spoiler system in the air or on the ground.

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 18



224. A green SPEED BRAKE ARMED light shows if

a. there are valid automatic speedbrake system inputs.

b. there are not valid automatic speedbrake system inputs.

c. there is a fault with the ground spoiler system in the air or on the ground.

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 18



226. During roll control the aileron on one wing moves up, and the aileron on the other wing

a. moves up

b. moves down

c. moves anyway

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 34



227. Where is the aileron trim indicator placard ?

a. on top of the control wheel

b. on the P8 aft electronic panel

c. on the P7 aft electronic panel

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 44



228. How many flight controls hydraulic modular packages ?

a. 1

b. 2

c. 3

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 28



229. Are the system A and system B flight controls hydraulic modular package interchangeable ?

a. Yes,they are interchangeable

b. No, they are not interchangeable

c. Not given

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 28



230. The aileron balance panels and tabs use                to help decrease the force necessary to move the ailerons in flight.

a. hydraulic forces

b. aerodynamic forces

c. electric forces

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 42



231. The two aileron PCUs are identical and interchangeable with the .

a. elevator PCUs

b. rudder PCUs

c. spoiler PCUs

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 64



232. Flight spoiler actuators receive hydraulic power from system .

a. system A

b. system B

c. system A and system B

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 102



233. Do the flight spoilers operate ?

a. in the air

b. on the ground

c. in the air and on the ground

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 106



234. To do a check of the transmitter adjustment of the spoiler position transmitters

a. you must use a test unit

b. you must use a tool

c. you don't use any thing

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 104



235. In the event of total hydraulic power failure, rotation of the pilots' control wheels mechanically positions the

a. Ailerons

b. Aileron tabs

c. Flight Spoilers.

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 13



236. The SPEED BRAKE ARMED light

a. A. Is amber and should be illuminated when the Speed Brake is moved to the ARMED position indicating valid automatic Speed Brake system inputs.

b. B. Is green and should be illuminated when the Speed Brake is moved to the ARMED position indicating valid automatic Speed Brake system inputs.

c. Is de-activated when the Speed Brake Lever is in the UP position.

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 18



237. The Speed Brake Test switches (if installed)

a. Are used as a cockpit pre-flight check of the auto spoiler system

b. Are used as a cockpit pre-flight check of the auto brake system.

c. Are used for maintenance test purposes only

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 138



238. The Alternate Flaps Position switch when selected to the UP position will

a. Electrically retract the trailing edge flaps.

b. Hydraulically retract the trailing edge flaps.

c. Electrically retract the leading and trailing

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 285



239. The LE FLAPS EXT light shows when

a. all of the LE flaps and slats are in an extend or full extend position.

b. some of the LE flaps and slats are in an extend or full extend position.

c. some of the LE flaps and slats are in an extend position.

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 453



240. If the airplane gets near a stall condition,what is the LE slats position?

a. move to the full extend position.

b. move to the midle extend position.

c. stay retracted position

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 434



241. When you move the flap lever to the 30 or 40 position,what is the LE slats position?

a. move to the full extend position.

b. stay retracted position

c. move to the midle extend position.

(B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 433



244. The rudder power control units (PCUs) are powered by

a. System A and system B for the main rudder PCU and standby pump for the standby rudder PCU.

b. System A and standby pump for the main rudder PCU and system B for the standby rudder PCU

c. System B and standby pump for the main rudder PCU and system A for the standby rudder PCU. (B1) Ref: Reference: ATA 27 FLIGHT CONTROL (1) - B737 Training book - Page 267



245. Which components control the pitch attitude ?

a. The aileron control the pitch attitude of the airplane about the lateral axis.

b. The elevators control the roll attitude of the airplane about the lateral axis.

c. The elevators control the pitch attitude of the airplane about the lateral axis.

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 158



246. The elevator feel computer control hydraulic pressure to the dual feel actuator (changes the control column forces) by using:

a. Pitot pressure and stabilizer input.

b. Data from ADIRU.

c. Data from FCC.

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 162



247. If a jam occurs in one control column

a. The pilot can not manual control the elevator

b. The breakout mechanism permits elevator input by the other column

c. The breakout mechanism permits elevator to be controlled by this control column as normal.

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 165



248. Which component changes the control column forces as the airspeed changes and the horizontal stabilizer moves ?

a. The elevator feel computer.

b. The elevator PCU.

c. The elevator feel and centering unit.

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 186



249. What is the indication when the elevator feel shift module (EFSM) is armed or operating during a stall

a. The FEEL DIFF PRESS light on the P5 panel comes on.

b. There is no flight deck annunciation.

c. The YAW DAMPER Light on the P5 panel comes on.

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 190



250. How does the pilot control the horizontal stabilizer manually and electrically ?

a. The pilots control the horizontal stabilizer manually with the stabilizer trim switches. They control them electrically by the stabilizer trim override switch.

b. The pilots control the horizontal stabilizer manually with the stabilizer trim switches. They control them electrically by the stabilizer trim wheels.

c. The pilots control the horizontal stabilizer manually with the stabilizer trim wheels. They control them electrically by the stabilizer trim switches.

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 209



251. What is the stabilizer trim cutout switches on the control stand used for ?

a. Stop the main electrical and autopilot trim inputs to the stabilizer trim actuator.

b. Bypass the column cutout switches if it fail.

c. Stop the stabilizer trim wheels.

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 210



252. During yaw damper operation,

a. Feel and centering unit gives a backdrive of the rudder pedals through the rudder control system.

b. There is no feedback to the rudder pedals.

c. Rudder PCU gives a backdrive of the rudder pedals through the rudder control system.

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 238



253. During electric trim operation, the pilots move the rudder trim control on the aisle stand

a. It does not cause a backdrive of the rudder pedals to the new commanded position.

b. There is no feedback to the rudder pedals.

c. It causes a backdrive of the rudder pedals to the new commanded position.

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 245



254. During landing the TE flaps fully extend

a. To increase lift and increase drag to permit slower speeds

b. To decrease lift and decrease drag to permit slower speeds

c. To increase lift and decrease drag to permit slower speeds

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 280



255. During the alternate operation, the TE flaps are

a. Mechanically controlled and electrically operated

b. Electrically controlled and electrically operated

c. Electrically controlled and hydraulically operated

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 280



256. Flap load relief operates

a. Only during normal operation of the TE flaps.

b. Only during alternate operation of the TE flaps.

c. During normal operation of the LE flaps and TE flaps.

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 345



257. When the alternate flaps control switch is in the UP position

a. Hydraulically retract the trailing edge flaps.

b. Electrically retract the leading and trailing edge flaps.

c. Electrically retract the trailing edge flaps.

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 350



258. How to extend the TE flaps with the LE devices retracted and disabled

a. Manually operate the LE cruise depressurization valve and extend the TE flaps in the normal operation.

b. TE flaps can not be extended when LE devices retracted.

c. Manually operate the LE flap and slat control valve and extend the TE flaps in the normal operation.

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 356



259. The LE devices include

a. One Krueger flaps and four slats on the leading edge of each wing

b. Two Krueger flaps and three slats on the leading edge of each wing

c. Two Krueger flaps and four slats on the leading edge of each wing

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 377



260. If two or more LE devices move away from their commanded position

a. The LE UCM detection function changes the operation mode from normal to alternate.

b. The LE UCM detection function gives command to retract all LE devices for re-operation. c. The LE UCM detection function stops the LE normal operation.

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 429



261. You can do tests of the LE flaps and slats with builtin test equipment (BITE) in

a. FCC

b. FSEU

c. SMYD

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 438



262. The leading edge flaps and slats position indicating system controls

a. The LE devices annunciator panel.

b. The LE FLAPS TRANSIT light and the LE FLAPS EXT light.

c. The LE devices annunciator panel, the LE FLAPS TRANSIT light and the LE FLAPS EXT light.

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 438



263. If the autoslat function is not available

a. The autoslat fail light shows on the flight controls panel on the P5 overhead panel.

b. A warning massage shows on ECAM

c. A cautiion message shows on ECAM

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 458



264. Which computers calculate the autoslat commands ?

a. FSEU

b. SMYD.

c. FCC

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 458



265. The two red TAKEOFF CONFIG lights come on

a. When the airplane is in a dangerous condition during takeoff or the ground spoiler interlock valve stays open after takeoff

b. Only when the airplane is in a dangerous condition during takeoff

c. The airplane is in takeoff config

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 468



266. The takeoff warning function is in

a. PSEU

b. FCC

c. SMYD

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 470



267. Which components control manual operation of the primary flight controls

a. The aileron control wheels, the elevator control column and the rudder pedals

b. The aileron control wheels, the elevator control column, the rudder pedals and the flap control lever

c. The aileron control wheels, the elevator control column, the rudder pedals and the stabilizer trim wheels

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 17



268. Which module controls the automatic operation of the speedbrakes ?

a. Flight control computer

b. The auto speedbrake module

c. Antiskid/autobrake control unit

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 115



269. The Ground Spoilers are powered by

a. Both A and B hydraulic systems.

b. The A hydraulic system.

c. The B hydraulic system.

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 118



270. These flight controls are on the control stand

a. Speedbrake lever, Stabilizer trim wheel, Flap lever, Aileron trim switches

b. Speedbrake lever, Stabilizer trim wheel, Stabilizer electric trim switch, Flap lever, Aileron trim switches

c. Aileron control wheel, Stabilizer trim wheel, Flap lever, Aileron trim switches

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 20



271. When the control wheel moves, which component sends signals to the stall management yaw damper (SMYD) and flight data acquisition unit (FDAU) for control wheel position

a. The roll control wheel steering (CWS) force transducer.

b. The control wheel position sensor.

c. The power control unit (PCU).

(B1) Ref: Reference: ATA 27 Flight controls - B737 Training book - Page 37



ATA 28:

272. The auxiliary fuel tank system provides additional fuel storage to increase the range of the airplane. Fuel from the auxiliary fuel tanks transfers to

a. the left main tank by cabin air differential pressure.

b. the center tank by cabin air differential pressure or bleed air of pneumatic system.

c. the right main tank by cabin air differential pressure.

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 40



273. To transfer fuel out of a wing tank to another wing tank

a. Not possible on ground

b. Defuel valve open, pumps On

c. Defuel valve open, cross-feed valve open, pump ON on the fuel removal tank and open the refueling valve on the fuel receiving tank.

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 87



274. The emergency fuel shutoff battery makes sure that the fuel system always has power to close

a. Engine fuel spar valve

b. APU fuel shutoff valve

c. Engine fuel spar valve and APU fuel shutoff valve

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 115



275. The water scavenge ejector pumps remove water from the low points in each tank to prevent corrosion. There are

a. one water scavenge ejector pump for each fuel tank.

b. two water scavenge ejector pumps in each main tank and one water scavenge ejector pump in center tank.

c. one water scavenge ejector pump in each main tank and two water scavenge ejector pumps in center tank.

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 117



276. How to check the fuel leak from the APU fuel feed line?

a. Open the panels to get access to the APU fuel line.

b. Check the drain mast of the APU fuel feed line shroud drain line.

c. Can not carry out.

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 121



277. The IMBAL message shows when

a. the airplane is in the air, there is a difference of 1000 lb (453 kg) between main tank 1 and main tank 2 for 60 seconds.

b. the airplane is in the air after the the LOW message shows

c. the airplane is on the ground, there is a difference of 1000 lb (453 kg) between main tank 1 and main tank 2 for 60 seconds.

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 145



278. The LOW message shows when

a. main tank 1 or main tank 2 has less than 1000 lb (453 kg) of fuel for 30 seconds

b. main tank 1 or main tank 2 has less than 2000 lb (907 kg) of fuel for 30 seconds

c. main tank 1 or main tank 2 has less than 2500 lb (1133 kg) of fuel for 30 seconds

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 145



279. You can do the FQIS ground test while refueling the airplane.

a. True

b. False

c. Not given

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 153



280. To manually measure fuel quantity on the airplane, you have to use

a. Chapter 12 of the AMM Part II or the 737 Fuel Measuring Stick Manual

b. Chapter 28 of the AMM Part II

c. Chapter 20 of the AMM Part II or the 737 Fuel Measuring Stick Manual

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 163



281. The fuel temperature indicating system shows

a. fuel temperature in center tank

b. fuel temperature in main tank No.1

c. fuel temperature in main tank No.2

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 161



282. The fuel measuring sticks are used to manually measure fuel quantity. There are

a. eight measuring sticks in each main tank, two measuring sticks in the center tank.

b. 12 measuring sticks in each main tank, 8 measuring sticks in the center tank

c. six measuring sticks in each main tank, four measuring sticks in the center tank

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 163



283. The CONFIG message shows when one or the other engine is in operation and

a. 1600 lb (725 kg) or more of fuel in the center tank, 2 center tank boost pumps are off.

b. 1000 lb (453 kg) or more of fuel in the center tank, 2 center tank boost pumps are off.

c. 1600 lb (725 kg) or more of fuel in the center tank, 1 center tank boost pump is off. (B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 145



284. The tank units measure fuel volume. There are

a. 6 tank units in each main tank, 4 tank units in the center tank.

b. 12 tank units in each main tank, 8 tank units in the center tank.

c. 8 tank units in each main tank, 2 tank units in the center tank.

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 137



285. The water and fuel that comes out of the water scavenge ejector pump goes to

a. the boost pump inlets.

b. the boost pump outlets. c. Engine fuel feed line.

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 117



286. The blue SPAR VALVE CLOSED light is bright. It indicates

a. the engine fuel spar valve is close.

b. the engine fuel spar valve is open

c. the engine fuel spar valve position and engine start lever positions disagree

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 113



287. The crossfeed VALVE OPEN light is dim. It indicates

a. the fuel crossfeed valve is open

b. the fuel crossfeed valve is close

c. the fuel crossfeed valve position and fuel crossfeed valve switch position disagree.

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 109



288. The fuel spar valve actuator is interchangeable with the crossfeed valve actuator.

a. True

b. False

c. Not given

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 111



289. For a FUEL annunciator and the MASTER CAUTION lights to illuminate, two fuel LOW PRESSURE lights must be illuminated for the

a. AFT pump in each main tank

b. FWD pump in each main tank

c. Same tank.

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 105



290. The LOW PRESSURE light comes on when the boost pump pressure for the main tank is

a. 8 psig or less

b. 4 psig or less

c. 2 psig or less

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 105



291. The LOW PRESSURE light comes on for the center boost pump when

a. the boost pump pressure is 18 psig or less

b. the boost pump switch is in the ON position and the boost pump pressure is 4 psig or less c. the boost pump switch is in the ON position and the boost pump pressure is 18 psig or less (B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 100



292. For suction defuel, you can carry out defuel on the main tank No.1 first, then carry out defuel on the main tank No.2.

a. True

b. False

c. Not given

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 87



293. The defueling valve connects the right engine fuel feed manifold with the defuel manifold. Operate the valve by

a. The switch on the FWD overhead panel.

b. The handle on the refueling station

c. The handle on the front spar, inboard of the refueling station.

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 84, 85, 86



294. The refueling hose does not connect to refueling receptacle, refueling valve switch set to ON, the refueling valve open light comes on. It indicates that

a. there is power to the refueling valve solenoid

b. the refueling valve is open.

c. the refueling valve is in transit.

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 77



295. The pressure relief valve opens to prevents damage to the wing structure when

a. there is too much negative pressure difference between the tanks and the ambient air.

b. there is too much positive or negative pressure difference between the tanks and the ambient air.

c. there is too much positive difference between the tanks and the ambient air.

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 18



296. How to reset the pressure relief valve after a large pressure difference between the tanks and the ambient air?

a. pull the reset handle to move the pressure relief valve to the closed position

b. push the reset handle to move the pressure relief valve to the opened position

c. The pressure relief valve automatically move to closed position after the pressure of the tanks and the ambient air equalize.

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 19



297. Wing rib 8 in each main tank has baffle check valves.

a. The check valves let fuel flow outboard but do not let fuel flow inboard.

b. The check valves let fuel flow inboard but do not let fuel flow outboard.

c. The check valves let fuel flow inboard or outboard depending on the wing going up or down.

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 13



298. Fuel that satisfies ASTM D1655, Jet B or MIL-T-5624, JP-4 is certified for use on the Boeing 737-600/700/800/900/BBJ model of the airplane.

a. True

b. False

c. Not given

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 79, 80



299. The main tank boost pumps supply fuel at

a. a minimum pressure of 10 psi.

b. a minimum pressure of 18 psi

c. a minimum pressure of 23 psi.

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 103



300. The main tank boost pumps are interchangeable with the center tank boost pumps

a. True

b. False

c. Not given

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 103



301. The crossfeed valve lets fuel flow between the left and right engine fuel feed manifolds. The valve body has an operating shaft and

a. a butterfly valve

b. a ball valve

c. a gate valve

(B1) Ref: Reference: ATA 28 Fuel System - B737 Training book - Page 107



ATA 29:

302. The PTU system is a hydraulic motor-pump assembly that supplies alternative pressure to

a. leading edge flaps and slats and thrust reversers system

b. leading edge flaps and slats and autoslat system.

c. leading edge flaps and slats and autoslat system, thrust reversers.

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 10



303. When the engine driven pump (EDP) has a high temperature condition, the amber OVERHEAT light comes on.

a. True

b. False

c. Not given

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 13



304. A pressure relief valve for each main reservoir opens for protection of reservoir when the air pressure in reservoir increases to

a. 60-65 psi.

b. 70-75 psi

c. 80-85 psi

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 36



305. Pulling No.2 engine fire handle will

a. Stop the fluid to the No.2 EDP and EMDP by closing the hydraulic shutoff valve and disarm the associated amber LOW PRESSURE light.

b. Stop the fluid to the No.2 EDP by closing the hydraulic shutoff valve and disarm the related amber LOW PRESSURE light.

c. Only stop the fluid to the No.2 EDP by closing the hydraulic shutoff valve.

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 27, 162



306. The system B standpipe supplies hydraulic fluid to

a. the EDP

b. the EMDP

c. the EDP and the EMDP

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 43



307. The amber STANDBY HYD LOW QUANTITY light comes on when the hydraulic fluid in the standby reservoir decreases to

a. less than 50 precent

b. less than 40 precent

c. less than 35 precent

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 96



308. How can you manually operate the standby hydraulic pump?

a. FLT CONTROL A switch to STBY RUD or FLT CONTROL B switch to STBY RUD

b. ALTERNATE FLAPS arm switch to ARM

c. FLT CONTROL A switch to STBY RUD or FLT CONTROL B switch to STBY RUD or ALTERNATE FLAPS arm switch to ARM

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 115



309. The hydraulic power transfer unit (PTU) system supplies alternate hydraulic pressure to the leading edge flaps and slats

a. when hydraulic system B engine-driven pump (EDP) pressure is below normal

b. when hydraulic system B electric motor-driven pump (EMDP) pressure is below normal

c. when standby hydraulic pressure is below normal.

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 124



310. The PTU control valve opens when

a. the EMDP pump pressure is less than 2350 psi for more than 0.5 seconds.

b. the EDP pump pressure is less than 2350 psi for more than 0.5 seconds.

c. the EDP and EMDP pump pressures are less than 2350 psi for more than 0.5 seconds.

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 138



311. The alternate nose wheel steering is inhibited when

a. The system B hydraulic fluid quantity is less than 21%

b. The system A hydraulic fluid quantity is less than 21%

c. The system B hydraulic fluid quantity is less than 11%

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 147



312. The LOW PRESSURE amber lights come on when the hydraulic pump pressure is

a. less than 1600 psi

b. less than 1400 psi

c. less than 1300 psi

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 160



313. The LOW PRESSURE amber lights go off when the hydraulic pump pressure is

a. more than 1600 psi

b. more than 1400 psi

c. more than 1300 psi

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 160



314. The HYD PUMP OVERHEAT amber light comes on when

a. the hydraulic fluid temperature in the case drain line from the EDP increases to 225F or more

b. the hydraulic fluid temperature in the case drain line from the EMDP increases to 225F or more

c. the hydraulic fluid temperature in the case drain line from the EMDP increases to 185F or more (B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 168



315. The hydraulic power for ground spoilers is from

a. Hydraulic system A

b. Hydraulic system B

c. Both hydraulic system A and B

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 24, 175



316. If either Flight Control switch is moved to the STBY RUD position

a. The standby pump will be activated and the STANDBY HYD LOW QUANTITY light will be armed.

b. The standby pump will be de-activated allowing system A pressure to power the rudder and the STANDBY HYD LOW PRESSURE light will be armed

c. The standby pump will be activated and the STANDBY HYD LOW PRESSURE light will be armed

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 164



317. Illumination of a EMDP OVERHEAT light will

a. Not shut down the associated pump

b. Automatically shut down the associated pump

c. Automatically arm the LOW PRESSURE light for the associated pump

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 168



318. If a total failure of both pumps supplying system B pressure occurs, which of the primary flight controls will be totally inoperative

a. Aileron and elevator

b. Rudder only

c. None

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 24



319. Loss of the A hydraulic system will result in the complete loss of the following

a. Ground spoilers. Flight spoilers 2,4,9,11. Alternate brakes. Autopilot A

b. Ground spoilers. Flight spoilers 2,4,9,11. Normal brakes. Nose wheel steering.

c. Ground spoilers. Flight spoilers 2,4,9,11. Elevator feel system. Alternate brakes. Autoslat system.

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 24



320. The standby hydraulic pump is automatically operated if

a. FLT CONTROL A or B switch to ON. ALTERNATE FLAPS arm switch to OFF. Trailing edge flaps not up. Airplane in the air or wheel speed more than 60 kts. Low flight control system A or B pressure.

b. FLT CONTROL A or B switch to ON. ALTERNATE FLAPS arm switch to OFF. Trailing edge flaps up. Airplane in the air or wheel speed less than 60 kts.

c. FLT CONTROL A or B switch to ON. ALTERNATE FLAPS arm switch to ARM. Airplane in the air or wheel speed more than 90 kts. Low flight control system A or B pressure.

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 115



321. The pressure relief valve prevents high pressure in the standby hydraulic system. The valve opens at …. and closes at ….

a. 3500 psi and 3300 psi

b. 3400 psi and 3300 psi

c. 3500 psi and 3400 psi

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 108



322. The engine-driven pumps (EDPs) supply hydraulic pressure for the hydraulic systems A and B. The EDP is

a. Centrifugal pump, single-stage, variable-displacement, pressure-compensated hydraulic pump.

b. an axial-piston, variable-displacement, yoke- actuated, pressure compensated hydraulic pump.

c. Centrifugal pump, single-stage, constant-displacement, pressure-compensated hydraulic pump. (B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 49



323. The electric motor-driven pumps (EMDPs) supply hydraulic pressure for hydraulic systems A and B. The EMDP is

a. A centrifugal pump, single-stage, variable-displacement, three-phase, 115v ac motor, pressure-compensated hydraulic pump.

b. an axial-piston, variable-displacement, three-phase, 115v ac motor, pressure compensated hydraulic pump.

c. A centrifugal pump, single-stage, constant-displacement, three-phase, 115v ac motor, pressure- compensated hydraulic pump.

(B1) Ref: Reference: ATA 29 Hydraulic Power - B737 Training book - Page 52



ATA 30:

324. The wing thermal anti-ice (WTAI) system uses hot air from the pneumatic system to heat

a. All leading edge slats of the wing.

b. The three inboard leading edge slats of the wing.

c. The three outboard leading edge slats of the wing.

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 8



325. How to reset the flight deck window heat system after an overheat condition or an overheat protection confidence test?

a. The system is automatically reset after 30 seconds.

b. The system is automatically reset after windows cool.

c. Let the windows cool, move the window heat switch to the OFF position, and then back to ON position.

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 74



326. How to do the confidence test of the WHCU overheat protection circuitry during system operation by the OVHT/PWR TEST switch ?

a. Hold the switch to the OVHT position for one second then release

b. Hold the switch to the OVHT position for ten seconds then release.

c. Hold the switch to the PWR TEST position for one seconds then release

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 74



327. The WINDOW HEAT switch in the ON position, when are the flight compartment windows heated?

a. The window temperature is less than 27 C.

b. The window temperature is less than 37 C.

c. The window temperature is less than 47 C.

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 73



328. How many temperature sensors are there in each window (No.1 and No.2)?

a. Only one temperature sensor

b. Two sensors: primary and spare

c. Three sensors: primary, secondary and backup.

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 64,78



329. The waste tank drain (ball) valve is heated by

a. The blanket heater

b. The air from pneumatic system

c. The line tape heater

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 100



330. The drain masts have integral electric heater elements.

a. True

b. False

c. Not given

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 98



331. The water and toilet drain anti-icing systems use

a. Electric power for heat.

b. Air from pneumatic system for heat

c. Electric power and air from pneumatic system for heat

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 94



332. Hydrophobic windshield coatings are on the outside surface of

a. All flight compartment windows

b. the left and right number 1 flight compartment windows.

c. the left and right number 2 flight compartment windows.

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 92



333. The portable water, gray water and vacuum waste systems use these electric heater elements

a. Blanket heater, line tape heater and built-in heater

b. line tape and built -in heater

c. Blanket heater and line tape heater

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 96, 98, 99



334. The blue VALVE OPEN light on the anit-ice panel is bright. It indicates:

a. The switch is in the ON position and the valve is open

b. The switch is in the OFF position and the valve is closed

c. The switch position and valve position disagree or the valve is in transit.

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 12



335. The wing thermal anti-ice shutoff valve is

a. a pneumatically-operated butterfly-type valve

b. a motor-operated butterfly-type valve

c. a pneumatically-operated ball-type valve

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 14



336. How can you know the flight compartment window heater is supplied power?

a. The green ON light come on

b. The WINDOW HEAT switch is in ON positon.

c. The amber ON light come on

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 61



337. The flight compartment window No.3 has two temperature sensors: primary and spare.

a. True

b. False

c. Not given

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 64



338. An amber light of probe system on the window and pitot heat panel comes on. It indicates

a. The related air data probe does not have heat. b. The related air data probe has heat

c. The related air data probe has heat but there is an internal fault.

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 56



339. The WINDOW HEAT switches control the window heat systems

a. The FWD switch turns on and off window heat No.1.

b. The SIDE switch turns on and off window heat No.1.

c. The FWD switch turns on and off window heat No.2, No.3.

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 61



340. The inlet cowl thermal anti-ice (TAI) valve controls the flow of air to the engine inlet cowl. The valve is

a. a pneumatically-operated ball-type valve

b. a motor-operated butterfly-type valve

c. a pneumatically-operated butterfly valve

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 32



341. The TAI message is amber when the switch and the valve position do not agree for

a. more than 8 seconds.

b. more than 10 seconds.

c. more than 18 seconds.

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 38



342. The source of inlet cowl thermal anti-icing air is

a. from the pneumatic system

b. from the engine bleed air interstage duct, upstream of the pressure regulator and shutoff valve.

c. from the engine bleed air stage 9th.

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 28



343. To decrease engine bleed loads and to give more thrust for climb, the WTAI valves close when the thrust levers are

a. more than 60 TRA

b. more than 65 TRA

c. more than70 TRA

(B1) Ref: Reference: ATA 30 Ice and Rain Protection - B737 Training book - Page 25



ATA 31:

344. The aural warning module gives these sounds in the flight compartment:

a. Intermittent horn, continuous horn, fire bell, wailer, and chimes.

b. Intermittent horn, continuous horn, wailer, overspeed clacker, and chimes.

c. Intermittent horn, continuous horn, fire bell, wailer, overspeed clacker, and chimes.

(B1) Ref: Reference: ATA 31 Indicating/ Recording System (1) - B737 Training book - Page 19



345. The aural warning module gives the sound of a wailer for an airplane overspeed warning.

a. True

b. False

c. Not given

(B1) Ref: Reference: ATA 31 Indicating/ Recording System (1) - B737 Training book - Page 41



346. The aural warning system test checks the aural warning module for correct operation. For a good test, you will hear

a. The intermittent horn and the clacker sounds

b. The intermittent horn

c. The clacker sounds

(B1) Ref: Reference: ATA 31 Indicating/ Recording System (1) - B737 Training book - Page 45



347. The components on the P5 aft overhead panel:

a. IRS mode select unit, Engine panel, Flight recorder/Mach airspeed warning panel.

b. IRS mode select unit, Flight control panel, Flight recorder/Mach airspeed warning panel.

c. IRS mode select unit, Fuel control panel, Flight recorder/Mach airspeed warning panel.

(B1) Ref: Reference: ATA 31 Indicating/ Recording System (1) - B737 Training book - Page 11



348. The weather radar data can show in these modes on ND

a. Expanded approach, entered VOR, expanded map and centered map

b. Centered approach, expanded VOR, expanded map and centered map

c. Expanded approach, expanded VOR, expanded map and centered map

(B1) Ref: Reference: ATA 31 Indicating/ Recording System (2) - B737 Training book - Page 54



349. How does the true airspeed shows if airspeed is 95.5 kts in plan mode display?

a. TAS096

b. TAS95.5

c. TAS --- (3 dashes)

(B1) Ref: Reference: ATA 31 Indicating/ Recording System (2) - B737 Training book - Page 76



350. The secondary engine display shows these indications

a. N2 indication, oil pressure, oil temperature, and oil quantity and engine vibration (VIB).

b. N1 indication, fuel flow (FF), oil pressure, oil temperature, and oil quantity and engine vibration (VIB).

c. N2 indication, fuel flow (FF), oil pressure, oil temperature, and oil quantity and engine vibration (VIB).

(B1) Ref: Reference: ATA 31 Indicating/ Recording System (2) - B737 Training book - Page 78



351. The ATC COMM messages and ACARS COMM messages show on

a. The primary engine display

b. The secondary engine display

c. Navigation display

(B1) Ref: Reference: ATA 31 Indicating/ Recording System (2) - B737 Training book - Page 78



352. With the switches on the display select panel set to OUTBD PFD,

a. the primary flight display shows on the outboard display unit. The inboard display unit does not show data.

b. the primary flight display shows on the outboard display unit. The compacted EFIS display shows on the inboard display unit.

c. the navigation display shows on the outboard display unit. The primary flight display shows on the inboard display unit.

(B1) Ref: Reference: ATA 31 Indicating/ Recording System (2) - B737 Training book - Page 88



353. When the display source selector is in the AUTO position with no system failures, DEU 2 controls

a. the left outboard, right inboard, and center upper display units

b. the right outboard, right inboard, and center lower display units.

c. the right outboard, left inboard, and center lower display units.

(B1) Ref: Reference: ATA 31 Indicating/ Recording System (2) - B737 Training book - Page 106



354. The flight data recorder system (FDRS) records airplane parameters and system data for

a. the last 15 hours of operation.

b. the last 20 hours of operation.

c. the last 25 hours of operation.

(B1) Ref: Reference: ATA 31 Indicating/ Recording System (3) - B737 Training book - Page 4



355. The first officer clock sends date and time data to

a. the FMC 2, the FDAU, and the voice recorder

b. the FMC 2, the FDAU

c. the FMC 2

(B1) Ref: Reference: ATA 31 Indicating/ Recording System (3) - B737 Training book - Page 80

356. Where do the clocks get the 28v dc power?

a. from hot battery bus

b. from battery bus

c. from DC 1 bus

(B1) Ref: Reference: ATA 31 Indicating/ Recording System (3) - B737 Training book - Page 80



357. How to print a test pattern of the printer?

a. Push and hold the TEST switch.

b. Push and hold the RESET switch.

c. Push and hold both the TEST and RESET switches at the same time

(B1) Ref: Reference: ATA 31 Indicating/ Recording System (3) - B737 Training book - Page 70



358. The underwater locator beacon (ULB) sends out an acoustic pulse tone of 37.5 khz at a rate of

a. one pulse-per-second

b. two pulse-per-second

c. three pulse-per-second

(B1) Ref: Reference: ATA 31 Indicating/ Recording System (3) - B737 Training book - Page 26



359. The flight data acquisition unit (FDAU) collects data from airplane systems and changes this data into a standard digital format.

a. True

b. False

c. Not given

(B1) Ref: Reference: ATA 31 Indicating/ Recording System (3) - B737 Training book - Page 28



ATA 32:

360. Air/ground system supplies air mode and ground mode signals to airplane systems, has these components. Choose the wrong answer

a. 02 nose landing gear compressed sensors, 01 Left main landing gear compressed sensor, 01 Right main landing gear compressed sensor

b. Proximity switch electronics unit (PSEU)

c. Air/ground relays

(B1) Ref: Reference: AMM Part SDS 32-09-00 p08



361. How many air/ground system:

a. 2 system : 1 and 2

b. 2 system: A and B

c. Only 1 system

(B1) Ref: Reference: AMM Part SDS 32-09-00 p08



362. Location of PSEU:

a. EE compartment

b. Forwad equipment compartment

c. MLG compartmen

(B1) Ref: Reference: AMM Part SDS 32-09-00 p17



363. Choose the right answer:

a. Hydraulic system A normally supplies pressure to extend and retract the main landing gear. Hydraulic system B supplies alternate pressure for retraction only

b. Hydraulic system B normally supplies pressure to extend and retract the main landing gear. Hydraulic system A supplies alternate pressure for retraction only

c. Hydraulic system A normally supplies pressure to extend and retract the main landing gear. Hydraulic system B supplies alternate pressure for extend only

(B1) Ref: Reference: AMM Part SDS 32-32-00 p01



364. Which valve supplies up or down pressure to retract or extend the main landing gear:

a. LG transfer valve

b. LG selector valve

c. LG control valve

(B1) Ref: Reference: AMM Part SDS 32-32-00 p01



365. Which valve controls the pressure source (hydraulic system A or hydraulic system B) to supply the main landing gear:

a. LG transfer valve

b. LG selector valve

c. LG control valve

(B1) Ref: Reference: AMM Part SDS 32-32-00 p01



366. Choose the wrong answer about transfer cylinder:

a. During the extension and retraction sequences, the transfer cylinder gives a time delay. This lets the main landing gear downlock or uplock actuators unlock before the main gear actuator receives pressure

b. The transfer cylinder is in the MLG bay compartment

c. The transfer cylinder has a piston that moves freely in the cylinder. One side of the piston connects to the down pressure. The other side connects to the up pressure

(B1) Ref: Reference: AMM Part SDS 32-32-00 p14



367. Which equipment removes up pressure from the main landing gear actuator if a damaged, spinning tire moves into the main landing gear wheel well:

a. Volumn fuse

b. Frangible fitting

c. Flow limiter

(B1) Ref: Reference: AMM Part SDS 32-32-00 p19



368. Choose wrong answer about the brakes:

a. The normal brake metering valve uses hydraulic system B or accumulator pressure for the normal brake system.

b. The alternate brake metering valve uses hydraulic system A pressure for the alternate brake system when hydraulic system B does not supply pressure

c. The normal brake metering valve uses pressure from the landing gear retract line to stop the main gear wheel rotation during retraction

(B1) Ref: Reference: AMM Part SDS 32-41-00 p10



369. Choose the wrong answer:

a. When hydraulic system B does not supply pressure, the alternate brake selector valve moves, lets hydraulic system A pressure supply pressure to the alternate brake system

b. When hydraulic system A and B pressures are the same, hydraulic system B pressure on the alternate brake selector valve does not let hydraulic system A supply pressure to the alternate brake system.

c. When hydraulic system A does not supply pressure, alternate brake system pressure from the alternate brake selector valve moves the accumulator isolation valve. This isolates brake accumulator pressure from the normal brake system.

(B1) Ref: Reference: AMM Part SDS 32-41-00 p14



370. The brake accumulator location:

a. right aft wing-to-body fairing

b. left aft wing-to-body fairing

c. right fwd wing-to-body fairing

(B1) Ref: Reference: AMM Part SDS 32-41-00 p16



371. When the accumulator is fully charged, it supplies enough pressure for

a. least six full brake applications

b. keep the parking brake pressurized for eight hours

c. A and B

(B1) Ref: Reference: AMM Part SDS 32-41-00 p16



372. Brake hydraulic fuses prevent hydraulic fluid loss if there is an external leak downstream of the fuses. How many fuses on hydraulic lines

a. 4 in the normal brake lines, 2 in the alternate brake lines

b. 4 in the normal brake lines, 4 in the alternate brake lines

c. 2 in the normal brake lines, 4 in the alternate brake lines

(B1) Ref: Reference: AMM Part SDS 32-41-00 p18



373. The antiskid system has

a. 4 antiskid valves in the normal hydraulic brake system, 2 antiskid valves in the alternate hydraulic brake system

b. 2 antiskid valves in the normal hydraulic brake system, 2 antiskid valves in the alternate hydraulic brake system

c. 4 antiskid valves in the normal hydraulic brake system, 4 antiskid valves in the alternate hydraulic brake system

(B1) Ref: Reference: AMM Part SDS 32-42-00 p05



374. Antiskid/autobrake control unit (AACU) receives signals, choose the wrong answer:

a. wheel speed data from the transducers

b. air/ground signals from system 1 and system 2 of PSEU

c. ground speed data from left ADIRU

(B1) Ref: Reference: AMM Part SDS 32-42-00 p07



375. AUTO BRAKE DISARM amber light comes on when

a. Malfunction in the autobrake system/antiskid system

b. Autobrake system is manually disarmed

c. A and B

(B1) Ref: Reference: AMM Part SDS 32-42-00 p09



376. Positions of AUTO BRAKES select switch

a. OFF, 1,2,3,MAX, RTO

b. 0,1,2,3, MAX, RTO

c. OFF,1,2,3,MAX

(B1) Ref: Reference: AMM Part SDS 32-42-00 p27



377. The AACU sends signals to the auto speedbrake module when each wheel speed is more than

a. 50 knots

b. 60 knots

c. 55 knots

(B1) Ref: Reference: AMM Part SDS 32-42-00 p10



378. If we don’t insert a pin into the pin hole in the towing lever to hold the lever in the towing position

a. Can use towbarless equipment to push or pull the airplane

b. Cannot pushback/towing

c. Can pushback/towing if depressurize hydraulic system A

(B1) Ref: Reference: AMM Part SDS 32-51-00 p29



379. If you tow the airplane and turn the nose wheels more than 78 degrees, you must:

a. Insert a pin in towing lever

b. Disconnect the torsion links

c. deressurize hydraulic system A

(B1) Ref: Reference: AMM Part SDS 32-51-00 p29



380. Which hydraulic system supplies pressure for brake accumulator

a. System A

b. System B

c. System A and B

(B1) Ref: Reference: AMM Part SDS 32-41-00 p16



381. Rudder pedal steering is

a. deactivated when airplane go in to air

b. Active at all times

c. Deactivated whenever the gear is up and locked

(B1) Ref: Reference: AMM Part SDS 32-51-00 p12



382. Rudder pedal steering

a. activated anytime the nose gear strut is extended

b. Can be use in the air mode

c. Can be overridden by the nose wheel steering wheel

(B1) Ref: Reference: AMM Part SDS 32-51-00 p12



383. What is required for the Park Brake to operate

a. Battery Switch ON

b. Battery Switch OFF

c. Hydraulic power must be switched ON

(B1) Ref:



384. The autobrake system arms for landing when, choose wrong answer

a. move the AUTO BRAKE select switch to a deceleration position

b. One air/ground systems in air mode, or two thrust levers at idle, or one or both air/ground systems in the ground mode for less than or equal to three seconds

c. Valid input from one ADIRU

(B1) Ref: Reference: AMM Part SDS 32-42-00 p39



385. If one or more of the arm conditions are not true while the autobrakes apply the brakes

a. AUTO BRAKE select switch stays in the selected position and the AUTO BRAKE DISARM light comes on

b. AUTO BRAKE select switch return to OFF position and the AUTO BRAKE DISARM light comes on

c. AUTO BRAKE select switch return to MAX position and the AUTO BRAKE DISARM light comes on

(B1) Ref: Reference: AMM Part SDS32-42-00 p39



386. Autobrake function applies the brakes when these conditions occur:

a. Landing autobrake is armed, Both thrust levers at idle, One air/ground system in the ground mode for 0.2 seconds or more, Wheel spin-up detection occurs or the spin-up latch sets

b. Landing autobrake is armed, Both thrust levers at idle, One air/ground system in the ground mode for 2 seconds or more, Wheel spin-up detection occurs or the spin-up latch sets.

c. Landing autobrake is armed, Both thrust levers at idle, One air/ground system in the ground mode for 2 seconds or more, Wheel spin-up detection occurs or the spin-up latch sets.

(B1) Ref: Reference: AMM Part SDS 32-42-00 p39



387. The autobrake system arms for the RTO autobrake function when these turn-on self check conditions occur. Select the wrong one:

a. AUTO BRAKE select switch to the RTO position

b. One air ground systems in the ground mode

c. Average of all wheel speeds less than 60 knots

(B1) Ref: Reference: AMM Part SDS 32-42-00 p44



388. The autobrake system releases the RTO autobrakes (if they were applied) and disarms the autobrake system (the AUTO BRAKE DISARM light does not come on) when:

a. AUTO BRAKE select switch to the OFF position

b. One air/ground systems are in the air mode

c. One or both normal metered pressure less than 750 psi

(B1) Ref: Reference: AMM Part SDS 32-42-00 p46



389. When there is a fault in the antiskid system, choose the wrong answer

a. ANTISKID INOP light comes on

b. the autobrake system is still operative

c. AUTO BRAKE DISARM light comes on

(B1) Ref: Reference: AMM Part SDS 32-42-00 p39



390. Over pressure relief valve is in the inner wheel half releases all of the pressure in the tire when pressure increases more than:

a. 375-450 psi

b. 275-350 psi

c. 350-450 psi

(B1) Ref: Reference: AMM Part SDS 32-45-00 p04



391. How many thermal fuse plugs on each MLG wheel:

a. 2

b. 3

c. 4

(B1) Ref: Reference: AMM Part SDS 32-45-00 p04



392. If the tire pressure is between 5% - 10% below the selected nominal service tire pressure:

a. inflate the tire to the necessary pressure

b. inflate the tire and check it again after 24 hours. If the tire pressure is more than 5% below the selected nominal service pressure again, replace the tire.

c. remove and replace the wheel and tire assembly

(B1) Ref: Reference: AMM Part SDS 32-45-00 p05



393. If the measured tire pressure is more than 20% below the selected nominal service tire pressure

a. remove and replace the wheel and tire assembly

b. remove and replace the wheel and tire assembly and the wheel and tire assembly installed on the opposite side of that axle

c. inflate the tire and check it again after 24 hours

(B1) Ref: Reference: AMM Part SDS 32-45-00 p05



394. Two red landing gear position lights, one for each MLG, come on for one of these conditions, choose the wrong one:

a. Control lever/landing gear position disagree: lever not down and gear not up and locked (gear retraction)

b. Control lever/landing gear position disagree: lever down and gear not down and locked (gear extension)

c. Gear down warning

(B1) Ref: Reference: AMM Part SDS 32-61-00 p16



396. Aural warning module gives the continuous horn sound for landing warning, the pilot can stop the horn when:

a. Flap position is from 0 to 10 units

b. Flap position is from 15 to 25 units

c. Radio altitude is less than 200 feet

(B1) Ref: Reference: AMM Part SDS 32-61-00 p24



397. When the gear is not down and locked and the flap position is more than 25 units, choose the wrong answer

a. the system gives the landing warning horn during a go-around.

b. The system inhibits the warning for 12 seconds after the pilot puts the gear lever in the up position.

c. The pilot can not stop the horn

(B1) Ref: Reference: AMM Part SDS 32-61-00 p24



398. If the PSEU senses a non-dispatchable fault, choose the wrong answer

a. The amber PSEU light on the P5 panel comes on 30 seconds after landing and both thrust levers are less than 53 degrees

b. The amber PSEU light on the P5 panel comes on 30 seconds after landing and both thrust levers are less than 53 degrees and either amber MASTER CAUTION annunciator light is pushed

c. The amber PSEU fault light goes off when the fault is corrected

(B1) Ref: Reference: AMM Part SDS 32-09-00 p42



399. The pressure supply of nose wheel steering from hydraulic system A change to hydraulic system B when:

a. Alternate nose wheel steering switch to the Alternate position

b. Alternate nose wheel steering switch to the Normal position

c. Cannot change, only system A supply hydraulic pressure for nose wheel steering.

(B1) Ref: Reference: AMM Part SDS 32-51-00 p01

400. Amber PSEU light in dispatchable fault:

a. goes off when the fault is corrected

b. still on when amber MASTER CAUTION light is pushed again to reset the latch relay

c. goes on after 60 seconds after landing, both thrust levers are less than 53 degrees, and either amber MASTER CAUTION annunciator light is pushed.

(B1) Ref: Reference: AMM Part SDS 32-09-00 p42



401. When you move the rudder pedals full travel on the ground, the nose wheels turn a maximum:

a. 10 degrees

b. 7 degrees

c. 15 degrees

(B1) Ref: Reference: AMM Part SDS 32-51-00 p01



402. When you move the steering wheel full travel, the nose wheels turn a maximum:

a. 78 degrees

b. 70 degrees

c. 88 degrees

(B1) Ref: Reference: AMM Part SDS 32-51-00 p01



403. Nose wheel steering from hydraulic system A to hydraulic system B is manually controlled by:

a. landing gear transfer valve through alternate nose wheel steering switch

b. landing gear selector valve through alternate nose wheel steering switch

c. steering metering valve through alternate nose wheel steering switch

(B1) Ref: Reference: AMM Part SDS 32-51-00 p01



404. When you open the access door to the manual extension control mechanism, choose the wrong answer:

a. An access door position switch sends a signal to the bypass valve on the landing gear selector valve

b. The bypass valve moves to the close position

c. Landing gear hydraulic components are connected to the hydraulic system return line

(B1) Ref: Reference: AMM Part SDS 32-34-00 p04



405. Brake temperature for each main landing gear wheel is shown by a two-digit number, with a range between 0.0 (100F) and 9.9 (1200F). amber BRAKE TEMP light comes on when brake temperature is more than

a. 4.0 (540F)

b. 4.5 (595F)

c. 5.0 (645F)

(B1) Ref: Reference: AMM Part SDS 32-46-00 p13



406. After override the output of the air/ground systems in PSEU

a. PSEU amber light in the flight compartment comes on

b. The air/ground override send a signal to operate the landing gear lever latch solenoid

c. PSEU amber light in the flight compartment still off

(B1) Ref: Reference: AMM Part SDS 32-09-00 p70



407. LGTV REPORT function in PSEU BITE

a. lets you see which conditions caused the most recent movement of the landing gear transfer valve to the bypass position

b. lets you see which conditions caused the most recent takeoff warning

c. lets you see which conditions caused the most recent movement of the landing gear transfer valve to the alternate position

(B1) Ref: Reference: AMM Part SDS 32-09-00 p72



408. The antiskid touchdown protection releases brake pressure from wheels:

a. 2 and 4 while the airplane is in the air and remains active until 0.7 seconds after the corresponding wheel spins up to 70 knots

b. 1 and 3 while the airplane is in the air and remains active until 0.7 seconds after the corresponding wheel spins up to 70 knots

c. when the ground mode has been sense continuously for 10 seconds

(B1) Ref: Reference: AMM Part SDS 32-42-00 p31



409. Antiskid locked wheel protection, choose the wrong answer

a. compares the wheel speeds of the two outboard or the two inboard pair of wheels

b. If the slower wheel speed decreases to less than 30 percent of the faster wheel speed, the locked wheel protection releases brake pressure from the slower wheel

c. Locked wheel protection does not operate at a speed less than 40 knots.

(B1) Ref: Reference: AMM Part SDS 32-42-00 p31



410. The touchdown/hydroplane protection, choose the wrong answer:

a. compares wheel speed data to ADIRU ground speed data

b. The hydroplane function supplies protection to wheels 2 and 4 only.

c. When the wheel speed decreases to 50 knots less than ground speed, the touchdown/hydroplane protection releases pressure to the brake

(B1) Ref: Reference: AMM Part SDS 32-42-00 p31



411. Which component used to decreases vibration between the inner and outer cylinders during high speed taxi and heavy brake use:

a. landing gear shock strut

b. torsion link

c. main gear shimmy damper

(B1) Ref: Reference: AMM Part SDS 32-10-00 p21



ATA 33:

413. Where is the location of replacement lamps for the lights?

a. Above the right number three window in flight compartment

b. EE compartment

c. Above the left number three window in flight compartment

(B1) Ref: Reference: AMM Part SDS 33-11-00 p02



414. The flight crew lights include:

a. Reading lights, Map lights, Chart lights, Dome lights

b. Reading lights, Map lights, Flight kit lights, Chart lights

c. Reading lights, Map lights, Chart lights, Dome lights

(B1) Ref: Reference: AMM Part SDS 33-11-00 p02



415. A master dim and test switch (TEST/BRT/DIM) is on:

a. P1 panel

b. P2 panel

c. P5 panel

(B1) Ref: Reference: AMM Part SDS 33-18-00 p02



416. Choose the right answer about Master Dim and Test switch position:

a. When the MD&T switch is in the bright (BRT) position, relays R33 and R34 are energized. When the MD&T switch is in the DIM position, relay R34 energizes. In the TEST position, relay R33

energizes.

b. When the MD&T switch is in the bright (BRT) position, relays R33 and R34 are de-energized. When the MD&T switch is in the DIM position, relay R34 energizes. In the TEST position, relay R33 energizes

c. When the MD&T switch is in the bright (BRT) position, relays R33 and R34 are energized. When the MD&T switch is in the DIM position, relay R34 de-energizes. In the TEST position, relay R33 de-energizes.

(B1) Ref: Reference: AMM Part SDS 33-18-00 p04



417. Choose the right answer about dome light:

a. The dome light on the P18 panel is a dual lamp assembly. One lamp is an emergency light for the flight compartment. It comes on with the emergency light system.

b. The dome light on FO side is a dual lamp assembly. One lamp is an emergency light for the flight compartment. It comes on with the emergency light system

c. Both dome lights are dual lamp assembly. One lamp is an emergency light for the flight compartment. It comes on with the emergency light system.

(B1) Ref: Reference: AMM Part SDS 33-14-00 p08



418. In which mode, you can adjust the intensity from the floodlight?

a. Standby mode

b. Normal mode

c. Both normal and standby mode

(B1) Ref: Reference: AMM Part SDS 33-14-00 p12



419. Choose the wrong answer about map light:

a. The light comes on when you pull the switch up.

b. The light comes on when you push the control switch

c. You turn the bezel to adjust the area of the light

(B1) Ref: Reference: AMM Part SDS 33-17-00 p8



420. When you open the flight compartment door:

a. the forward entry light goes dim, the forward galley light still bright

b. the forward entry light and the forward galley light still bright

c. the forward entry light goes dim, the forward galley light goes dim

(B1) Ref: Reference: AMM Part SDS 33-26-00 p08; 33-29-00 p04



421. To replace retractable landing light lamp:

a. You must extend the retractable landing light

b. Pull and collar the circuit breaker to prevent accidental operation of retraction mechanism or electric shock.

c. A AND B CORRECT

(B1) Ref: Reference: AMM Part SDS 33-42-00 p06



422. When the retractable landings light come on?

a. The switch is in the ON position, the light is within 5 degrees of full extension

b. The switch is in the ON position, the light is within 10 degrees of full extension

c. The switch is in the ON position, the light is within 6 degrees of full extension (B1) Ref: Reference: AMM Part SDS 33-42-00 p08



423. Choose the right answer about position light

a. The left forward position light is red. The right forward light is white. The tail position lights are green

b. The left forward position light is green. The right forward light is red. The tail position lights are white.

c. The left forward position light is red. The right forward light is green. The tail position lights are white.

(B1) Ref: Reference: AMM Part SDS 33-43-00 p02



424. Location of power supplies for cabin emergency exit lights:

a. Behind the ceiling panels at the forward and aft entry area

b. On the side structure, near the floor

c. A and B

(B1) Ref: Reference: AMM Part SDS 33-51-00 p16



425. How to switch on emergency lights

a. Use the emergency exit light switch on the P5 forward overhead panel

b. emergency exit switch on P14 aft attendant panel.

c. A and B

(B1) Ref: Reference: AMM Part SDS 33-50-00 p02



426. Choose the right statement of the lavatory mirror lights

a. Control by ON/OFF switch on fwd or aft attendant panel

b. Come on bright when the lavatory door closes and locks

c. Working with DIM and BRIGHT mode of ceiling lights

(B1) Ref: Reference: ATA 33 Lights system - B737 Training book - Page 98



427. How can you turn the position lights on?

a. Move the POSITION switch to the STEADY or STROBE & STEADY position

b. Move the POSITION switch to the ON position

c. Move the POSITION switch in the STEADY & ON position

(B1) Ref: Reference: ATA 33 Lights system - B737 Training book - Page 144



428. In the flight compartment, the dome light has an emergency light.

a. At P6 panel

b. At P18 panel

c. At P5 panel

(B1) Ref: Reference: ATA 33 Lights system - B737 Training book - Page 42



429. When you remove all power from the airplane, to prevents the emergency lights operation so the batteries do not discharge:

a. The P5 emergency exit light switch must be in the ARM position and the attendant switch in the NORM position

b. The P5 emergency exit light switch must be in the OFF position and the attendant switch in the OFF position

c. The P5 emergency exit light switch must be in the OFF position and the attendant switch in the NORM position.

(B1) Ref: Reference: AMM Part SDS 33-51-00 p20



ATA 34:

430. The multi-mode receiver (MMR) contains these functions

a. An instrument landing system (ILS) receiver function and a global positioning system (GPS) function

b. A global positioning system (GPS) function, a GNSS landing system (GLS) function.

c. An instrument landing system (ILS) receiver function, a global positioning system (GPS) function and a GNSS landing system (GLS) function.

(B1) Ref: Reference: ATA 34 Navigation (1) - B737 Training book - Page 349



431. What is the color of WXR data on the ND to show heavy weather?

a. Yellow

b. Red

c. Magenta

(B1) Ref: Reference: ATA 34 Navigation (1) - B737 Training book - Page 230



432. The static ports have anti-icing heaters by

a. Do not have anti-icing heaters.

b. Air from pneumatic system

c. Electrical heaters

(B1) Ref: Reference: ATA 34 Navigation (1) - B737 Training book - Page 23



433. The alternate static ports connect to

a. Left static ADM

b. Left static ADM

c. The ISFD and the cabin differential pressure indicator.

(B1) Ref: Reference: ATA 34 Navigation (1) - B737 Training book - Page 13



434. On the MSU, the white ALIGN annunciator flashes after ADIRU alignment completion, it means

a. The ADIRU needs information.

b. The ADIRU has failure.

c. The ADIRU is ready to use.

(B1) Ref: Reference: ATA 34 Navigation (1) - B737 Training book - Page 60



435. True airspeed does not show on the ND until TAS is more than

a. 80 kts

b. 100 kts

c. 120 kts

(B1) Ref: Reference: ATA 34 Navigation (1) - B737 Training book - Page 77



436. When the airplane is at or below an altitude of 25,968 ft, the airplane maximum operating limit speed (VMO) is

a. 300 kts

b. 340 kts

c. 380 kts

(B1) Ref: Reference: ATA 34 Navigation (1) - B737 Training book - Page 159



437. The maximum operating mach (MMO) is

a. 0.82

b. 0.87

c. 0.92

(B1) Ref: Reference: ATA 34 Navigation (1) - B737 Training book - Page 159



438. The RA system has a operation range:

a. approximately -12 to 2500 feet.

b. approximately 12 to 2500 feet.

c. above 2500 feet.

(B1) Ref: Reference: ATA 34 Navigation (1) - B737 Training book - Page 188



439. How far can the WXR system calculate and show turbulence?

a. only to 20 nm.

b. only to 40 nm.

c. only to 60 nm.

(B1) Ref: Reference: ATA 34 Navigation (1) - B737 Training book - Page 230



440. To carry out the weather radar system test, on the EFIS control panel:

a. Set the range selector to 40 nm and set the mode selector to the correct ND mode

b. Set the range selector to 40 nm and set the mode selector to any ND mode

c. Set the range selector to 60 nm and set the mode selector to the correct ND mode

(B1) Ref: Reference: ATA 34 Navigation (1) - B737 Training book - Page 259



441. The marker beacon function operates in

a. the VOR/MB receiver 1 and receiver 2 positions

b. the VOR/MB receiver 2 position only.

c. the VOR/MB receiver 1 position only.

(B1) Ref: Reference: ATA 34 Navigation (1) - B737 Training book - Page 415



442. For DME stations with VHF omnidirectional ranging (VOR) or instrument landing system (ILS), DME tuning frequencies are

a. 108.00 to 117.95 MHz

b. 133.30 to 135.95 MHz c. 108.0 to 112.0 Mhz

(B1) Ref: Reference: ATA 34 Navigation (1) - B737 Training book - Page 447



443. The automatic direction finder (ADF) receiver calculates bearing to a station that transmits in the frequency range of

a. 190 Mhz to 1750 Mhz

b. 19 Khz to 190 Khz

c. 190 Khz to 1750 Khz

(B1) Ref: Reference: ATA 34 Navigation (1) - B737 Training book - Page 477



444. The GPS fail light on the IRS mode select unit comes on

a. only when 2 units have a failure.

b. if 1 units has a failure.

c. if 1 units has a failure and you push the master caution annunciator or 2 units have a failure.

(B1) Ref: Reference: ATA 34 Navigation (1) - B737 Training book - Page 503



445. The GLS receives GPS signals through the GPS antennas. Thes data are

a. Position and velocity

b. Velocity and time

c. Position, velocity, and time

(B1) Ref: Reference: ATA 34 Navigation (1) - B737 Training book - Page 537



446. The flight crew sets the identity code that shows on the ATC/TCAS control panel. The code has

a. 4 digits

b. 5 digits

c. 6 digits

(B1) Ref: Reference: ATA 34 Navigation (2) - B737 Training book - Page 16



447. The transponder responds with pulse-coded signals at a frequency of

a. 172.80 MHz.

b. 1090 MHz.

c. 1090 KHz.

(B1) Ref: Reference: ATA 34 Navigation (2) - B737 Training book - Page 20



448. The traffic collision avoidance system (TCAS) transmits interrogation signal(s)

a. Whisper-shout.

b. Mode S.

c. Whisper-shout and Mode S.

(B1) Ref: Reference: ATA 34 Navigation (2) - B737 Training book - Page 58



449. The ground proximity warning system (GPWS) alerts the flight crew of an unsafe condition. The GPWS has

a. 5 modes

b. 7 modes

c. 9 modes

(B1) Ref: Reference: ATA 34 Navigation (2) - B737 Training book - Page 86



450. The GPWS operates when the airplane is

a. less than 2450 feet above the ground.

b. less than 3000 feet above the ground.

c. more than 2450 feet above the ground.

(B1) Ref: Reference: ATA 34 Navigation (2) - B737 Training book - Page 89



451. With GPWS, the PULL UP warning annunciation shows for these modes

a. mode 1, 2, 3 and 4 conditions

b. mode 1, 2, 3, 4 and 5 conditions

c. mode 1, 2, 4 and 6 conditions

(B1) Ref: Reference: ATA 34 Navigation (2) - B737 Training book - Page 166



452. With GPWS, the WINDSHEAR warning annunciation shows for

a. mode 1, 2, 3 and 7 conditions

b. mode 7 condition

c. mode 1, 2, 4 and 6 conditions

(B1) Ref: Reference: ATA 34 Navigation (2) - B737 Training book - Page 166



453. The desiccator prevents water condensation in the OHU lens assembly. When it has absorbed moisture, the color of desiccator is

a. Blue

b. Yellow

c. Pink

(B1) Ref: Reference: ATA 34 Navigation (2) - B737 Training book - Page 285



454. The flight management computer system (FMCS) does these function:

a. Navigation and performance

b. Performance and guidance

c. Navigation, performance and guidance

(B1) Ref: Reference: ATA 34 Navigation (2) - B737 Training book - Page 352



ATA 35:



456. Access to the flight crew oxygen cylinder

a. from the forward cargo compartment

b. from EE compartment

c. from the flight deck

(B1) Ref: Reference: AMM Part SDS 35-10-00 p08



457. The regulator has a fail safe relief valve. This relief valve opens when downstream line pressure is more than

a. 50 psi

b. 100 psig

c. 80 psi

(B1) Ref: Reference: AMM Part SDS 35-10-00 p10



458. Choose the WRONG answer about flight crew oxygen system

a. Still can read the oxygen cylinder pressure when BAT sw OFF

b. The battery switch must be ON to supply power to the indicator

c. The green discharge indication disk covers the line outlet. The released oxygen blows the disk out of its seat when system overpressure

(B1) Ref: Reference: AMM Part SDS 35-10-00 p12



459. Choose the right answer:

a. A white OXY ON flag on the box door shows when the stowage box shutoff valve is open when the box is closed

b. A flow indication blinker on the stowage box shows oxygen flow to the mask. A yellow cross indicates oxygen flow

c. A and B

(B1) Ref: Reference: AMM Part SDS 35-10-00 p18



460. In the demand mode, select the wrong answer

a. A mask regulator supplies oxygen to the crew member only when the crew member exhales.

b. A mask regulator supplies oxygen to the crew member only when the crew member inhales

c. To select continuous flow mode, turn the EMERGENCY knob to EMERGENCY

(B1) Ref: Reference: AMM Part SDS 35-10-00 p22



461. Flight crew oxygen mask in the diluter mode, ambient cabin air mixes with oxygen. Select the wrong answer:

a. To select pure oxygen, push the red N/100% dilution control to the 100% position

b. To select pure oxygen, push the yellow N/100% dilution control to the 100% position

c. The mix of air and oxygen is proportional to the cabin pressure altitude.

(B1) Ref: Reference: AMM Part SDS 35-10-00 p22



462. On flight crew oxygen mask stowed in box, the RESET/TEST selector is used

a. To do a test of the system

b. Reset the shutoff valve when the mask is stowed

c. A and B

(B1) Ref: Reference: AMM Part SDS 35-10-00 p22



463. The passenger oxygen system can be enable

a. Manually by the crew with a guarded toggle switch on the oxygen system control panel

b. Automatically by operation of a pressure switch (14000 feet cabin altitude)

c. A and B

(B1) Ref: Reference: AMM Part SDS 35-20-00 p02



464. The PSU oxygen door panels can be opened manually:

a. Cannot be opened manually

b. Insert a flat tool (6.0 in. pocket scale) in the door edge gap. Then push up against the latch release to open the door.

c. Insert a 0.125 in (3.0 mm) pin punch into the door panel release hole. Then push up against the latch release to open the door.

(B1) Ref: Reference: AMM Part SDS 35-20-00 p06



465. The attendant service oxygen panel doors and lavatory service oxygen panel doors can be opened manuall by:

a. insert a flat tool (6.0 in. pocket scale) in the door edge gap. Then push up against the latch release to open the door.

b. Insert a 0.125 in (3.0 mm) pin punch into the door panel release hole. Then push up against the latch release to open the door.

c. Cannot be opened manually

(B1) Ref: Reference: AMM Part SDS 35-20-00 p06



466. A heat sensitive indicator is a piece of tape shows the passenger oxygen generator condition:

a. Usually red, during operation change to black

b. Usually orange, during operation change to red

c. Usually orange, during operation change to black

(B1) Ref: Reference: AMM Part SDS 35-20-00 p09



467. A solid state electronic device uses a piezoelectric crystal to change the force of the gas pressure to an electrical signal

a. Pressure switch

b. Pressure regulator

c. Pressure transducer

(B1) Ref: Reference: AMM Part SDS 35-20-00 p09



468. The diaphragm in the pressure reducing regulator controls a metering valve that decreases the oxygen pressure from bottle pressure to

a. 50 - 60 psi

b. 100 psi

c. 60 - 85 psig

(B1) Ref: Reference: AMM Part SDS 35-10-00 p10



ATA 36:

469. Engine bleed air comes from

a. the 9th stages of the high pressure compressor

b. the 5th and 9th stages of the low pressure compressor

c. the 5th and 9th stages of the high pressure compressor

(B1) Ref: Reference: ATA 36 Pneumatic system - B737 Training book - Page 13



470. The 5th stage check valve prevents

a. Reverse flow into the 5th stage

b. Over pressure flow in the 5th stage

c. Under pressure flow in the 5th stage

(B1) Ref: Reference: ATA 36 Pneumatic system - B737 Training book - Page 13



471. The isolation valve switch has these positions:

a. ON, OFF, AUTO

b. CLOSE, OPEN, AUTO

c. CLOSE, OPEN

(B1) Ref: Reference: ATA 36 Pneumatic system - B737 Training book - Page 14



472. Choose the right answer:

a. Do not supply more than 50 psi of pressure to the pneumatic system

b. Do not supply more than 60 psi of pressure to the pneumatic system

c. Do not supply more than 55 psi of pressure to the pneumatic system

(B1) Ref: Reference: ATA 36 Pneumatic system - B737 Training book - Page 18



473. Choose the WRONG answer:

a. The 490F (254C) overtemperature switch is on the engine bleed air strut duct, upstream of the precooler

b. The 490F (254C) overheat switches turn on the BLEED TRIP OFF lights and close the pressure regulating shutoff valves.

c. The air conditioning accessory unit (ACAU) is an interface between the air conditioning bleed air controls panel and the pressure regulating shutoff valves

(B1) Ref: Reference: AMM Part SDS 36-11-00 p02



474. Choose the WRONG answer

a. The operation of the high stage regulator is automatic. There are no operational controls.

b. The operation of the high stage valve is automatic. Also there is a manual override to lock the valve in the OPEN position

c. The operation of the high stage valve is automatic. Also there is a manual override to lock the valve in the closed position

(B1) Ref: Reference: AMM Part SDS 36-11-00 p08



475. The PRSOV has a manual override and position indicator. You can manually lock the valve in:

a. Close or open position

b. Open position only

c. The closed position only

(B1) Ref: Reference: AMM Part SDS 36-11-00 p14



476. A precooler control valve controls the amount of fan air flows through the precooler. Which device control the precooler control valve:

a. The precooler control valve sensor

b. Wing thermal anti-ice (WTAI) solenoid valve

c. A and B

(B1) Ref: Reference: AMM Part SDS 36-12-00 p02



477. The bleed air regulator (BAR) has electrical control by signals from these devices. Choose the wrong answer:

a. Engine BLEED switch

b. Engine fire switch

c. PRSOV

(B1) Ref: Reference: AMM Part SDS 36-11-00 -27



478. If the temperature downstream of the precooler is more than 490F (254C), the 490F (254C) overtemperature switch operates and cause:

a. Bleed air regulator solenoid valve closes

b. Air conditioning/bleed air controls panel BLEED TRIP OFF light comes on

c. A and B

(B1) Ref: Reference: AMM Part SDS 36-11-00 -20



479. ACAU gets inputs from these controls and sensors to control the bleed air regulator (BAR) that operates the PRSOV. Choose the wrong answer:

a. The engine fire switch, Engine bleed switch

b. Engine bleed switch, Engine start valve

c. The 450F (232C) overheat switch

(B1) Ref: Reference: AMM Part SDS 36-11-00 -13



480. The APU bleed air system supplies bleed air to the pneumatic manifold

a. When airplane on ground

b. When airplane in air

c. When airplane on ground or in air up to 17000 feet

(B1) Ref: Reference: ATA 36 Pneumatic system - B737 Training book - Page 62



481. When does the high stage valve close?

a. Downstream pressure is more than 9th stage pressure

b. 9th stage pressure is more than 110 psi

c. Downstream pressure is more than 9th stage pressure or 9th stage pressure is more than 110 psi

(B1) Ref: Reference: ATA 36 Pneumatic system - B737 Training book - Page 26



482. The precooler get the cooling air from

a. Ram air

b. Fan air

c. 3th stage bleed air

(B1) Ref: Reference: ATA 36 Pneumatic system - B737 Training book - Page 40



483. A precooler system cools engine bleed air. Choose the wrong answer

a. It uses engine fan air to cool the engine bleed air

b. The 450F (232C) thermostat bleeds control pressure from the PRSOV if engine bleed air downstream of the precooler is 450F (232C) or higher.

c. It uses ram air heat exchanger to cool the engine bleed air

(B1) Ref: Reference: AMM Part SDS 36-11-00 p28



484. Before you supply air from an external pneumatic source, these conditions should be met:

a. Battery power on

b. Air conditioning pack switches off

c. A and B

(B1) Ref: Reference: AMM Part SDS 36-13-00 p12



485. The DUAL BLEED light comes on for either of these conditions:

a. Engine 1 BLEED switch ON and the APU bleed air valve open

b. Engine 2 BLEED switch ON, the isolation valve OPEN, and the APU bleed air valve open.

c. A and B

(B1) Ref: Reference: AMM Part SDS 36-14-00 p08



486. Choose the RIGHT answer:

a. The high stage valve is a butterfly valve and spring loaded to the closed position.

b. The high stage valve is a ball valve and spring loaded to the open position.

c. The high stage valve is a ball valve and spring loaded to the closed position.

(B1) Ref: Reference: ATA 36 Pneumatic system - B737 Training book - Page 24



487. The pressure indicator on the air conditioning/ bleed air controls panel

a. Indicates the pressure in APU bleed duct

b. Indicates the pressure in engine bleed duct

c. Indicates the pressure in left and right pneumatic duct

(B1) Ref: Reference: ATA 36 Pneumatic system - B737 Training book - Page 14, 72



488. The operation of the high stage bleed system is

a. Automatic and self-regulating

b. Controlled by a switch on the overhead panel

c. Controlled by a switch on the P7 panel

(B1) Ref: Reference: ATA 36 Pneumatic system - B737 Training book - Page 26



ATA 38:

489. When you drain the potable water system, you must drain water from

a. Water service panel

b. Forward lavatory

c. Water service panel and forward lavatory

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 11



490. To drain the potable water system, you open these valves:

a. Water tank drain valve, lavatory water supply shutoff valves

b. Forward lavatory drain valve and lavatory water supply shutoff valves.

c. Water tank drain valve, forward lavatory drain valve and lavatory water supply shutoff valves

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 11



491. The fill/overflow valve lets you fill the water tank. The fill/overflow valve is

a. a four-port rotary valve.

b. a three-port rotary valve.

c. a two-port rotary valve.

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 20



492. The water tank fill/overflow valve is operated by

a. Electrical motor

b. Manual control cable

c. pneumatic line.

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 20



493. What is the water tank capacity?

a. 62.1 gallons

b. 52.1 gallons

c. 42.1 gallons

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 22



494. The water level sensor is a LRU component, so we can replace the sensor with standard tool.

a. True

b. False

c. Not given.

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 22



495. The water tank drain valve lets water drain overboard. The water tank drain valve is

a. a two-port, single-ball, dual-seal valve

b. a four-port, dual-ball, dual-seal valve

c. a two-port, dual-ball, dual-seal valve

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 24



496. The forward lavatory drain valve operates manually. The valve has

a. a valve body and a red switch.

b. a valve body and a red handle.

c. a valve body and a blue handle.

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 26



497. The lavatory water supply shutoff valve is

a. a four-way valve

b. a four-port rotary valve.

c. a three-way valve

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 28



498. A hydraulic timer in the faucet assembly adjusts the water flow

a. from 1 to 4 seconds.

b. from 5 to 9 seconds.

c. from 10 to 15 seconds.

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 30



499. The overheat switch opens the power circuit if the water temperature is

a. more than 76 C

b. more than 86 C

c. more than 106 C

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 34



500. The pressure relief valve opens if pressure in the water heater is

a. more than 100 psig.

b. more than 120 psig.

c. more than 140 psig.

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 34



501. The water tank pressurization system pressurizes the potable water tank. Pressure comes from

a. The pneumatic system or an air compressor.

b. The pneumatic system only

c. An air compressor only

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 48



502. In the water tank pressurization system, the pressure regulator keeps the air pressure to a limit of 35 psig.

a. from the air compressor

b. from the pneumatic system

c. from the pneumatic system and the air compressor.

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 53



503. The air compressor pressurizes the water tank

a. The air compressor operates as long as the pneumatic system is not on.

b. The air compressor operates when the pressure limit switch senses that tank pressure is less than 30 psig

c. The air compressor start when the pressure limit switch senses that tank pressure is less than 30 psig and stop when tank pressure is 40 psig

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 53



504. The waste quantity indicator is displayed on

a. the aft attendant control panel (ACP)

b. the forward attendant control panel (ACP)

c. the aft and forward attendant control panel (ACP)

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 144



505. In normal circumstances, the logic control module (LCM) stops the operation of the toilets if

a. one point level sensor sends a tank full signal to the LCM

b. both point level sensor sends a tank full signal to the LCM

c. one point level sensor and continuous level sensor send tank full signals to the LCM

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 140



506. You use rinse water and the drain line blockage removal valve to loosen a blockage in the waste drain line.

a. True

b. False

c. Not given.

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 126



507. The flush control unit (FCU) opens the rinse valve to supply potable water to flush the toilet bowl for

a. 0.7 seconds

b. 7 seconds

c. 17 second

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 89



508. How long does the FCU open flush valve to let the toilet waste drain out of the toilet.

a. 0.4 seconds

b. 4 seconds

c. 14 seconds

(B1) Ref: Reference: ATA 38 Water and Waste - B737 Training book - Page 89



ATA 47:

509. The EFB system has these types of interfaces with other systems on the airplane

a. ARINC 429, ethernet, fiber optic, analog and analog discretes.

b. ARINC 429, analog and analog discretes.

c. ARINC 429, ethernet, analog and analog discretes

(B1) Ref: Reference: ATA 46 Information System - B737 Training book - Page 9



510. The electronics unit (EU) is the central processing unit (CPU) for the electronic flight bag (EFB)

a. There is only one EU for both captain DU and F/O DU.

b. There are two EUs. The left EU always connects to the captain DU. The right EU always connects to the first officer DU.

c. There are two EUs. At a time, one EU connects to both captain DU and F/O DU, the other is for back up.

(B1) Ref: Reference: ATA 46 Information System - B737 Training book - Page 16



511. What operating system does EFB electronics unit (EU) use?

a. Linux

b. Windows

c. Linux and Windows

(B1) Ref: Reference: ATA 46 Information System - B737 Training book - Page 16



512. Where do the EFB EUs get power?

a. 115v ac transfer bus.

b. 115v ac main bus.

c. 28v dc bus.

(B1) Ref: Reference: ATA 46 Information System - B737 Training book - Page 14



513. Where do the EFB DUs get power?

a. 28V dc power from the onside EU.

b. 115v ac main bus.

c. 28v dc bus.

(B1) Ref: Reference: ATA 47 Nitrogen generation system - B737 Training book - Page 10



514. Where is the BITE display unit?

a. In the forward section of the left air conditioning compartment.

b. In the forward section of the right air conditioning compartment.

c. In the air conditioning distribution compartment.

(B1) Ref: Reference: ATA 47 Nitrogen generation system - B737 Training book - Page 68



515. On the operability indicator, the DEGRADE blue light come on mean?

a. The system is temporarily serviceable, but in a decreased capacity and no maintenance is necessary.

b. The system is temporarily serviceable, but you must manually close and lock the nitrogen generation system shutoff valve.

c. The system is serviceable and no maintenance is necessary.

(B1) Ref: Reference: ATA 47 Nitrogen generation system - B737 Training book - Page 66



516. What is the purpose of the nitrogen genetation system?

a. To decreases the oxygen (O2) contents of the air in the center fuel tank

b. To decreases the nitrogen (N2) contents of the air in the center fuel tank

c. To decreases the oxygen (O2) contents of the air in the main tanks.

(B1) Ref: Reference: ATA 47 Nitrogen Generation System - B737 Training book - Page 5



517. The flow of the air through nitrogen genetation system is this sequence?

a. Pneumatic mainfold - NGS Shutoff valve - filter - heat exchanger - the ozone converter -overtemperature shutoff valve - air separation module - High flow valve - center tank.

b. Pneumatic mainfold - NGS Shutoff valve - the ozone converter - heat exchanger - filter - overtemperature shutoff valve - air separation module - High flow valve - center fuel tank.

c. Pneumatic mainfold - NGS Shutoff valve - the ozone converter - heat exchanger - filter - overtemperature shutoff valve - air separation module - High flow valve - main fuel tank.

(B1) Ref: Reference: ATA 47 Nitrogen Generation System - B737 Training book - Page 13



518. The nitrogen generation system controller (NGSC) closes the NGS shutoff valve (SOV) and the overtemperature shutoff valve (OTSOV) when the bleed air pressure is

a. More than 67 psi

b. More than 71 psi

c. More than 52 psi

(B1) Ref: Reference: ATA 47 Nitrogen Generation System - B737 Training book - Page 16



519. The nitrogen generation system controller (NGSC) sends signals to modulate the RAV to keep the air separation module inlet temperature at

a. 71F

b. 160F

c. 280F

(B1) Ref: Reference: ATA 47 Nitrogen Generation System - B737 Training book - Page 28



520. If the nitrogen generation system controller (NGSC) or the nitrogen generation system (NGS) shutoff valve (SOV) has a failure, how to stop the NGS?

a. The NGS can not be stopped.

b. Pushing the NGS Stop Switch on the flight comaprtment overhead panel.

c. The thermal switch gives back-up temperature protection. At a temperature of 280F (138C), the switch opens, the overtemperature shutoff valve closes (OTSOV).

(B1) Ref: Reference: ATA 47 Nitrogen Generation System - B737 Training book - Page 34



521. What is the nominal operation pressure of the NGS?

a. 67 psi

b. 52 psi

c. 71 psi

(B1) Ref: Reference: ATA 47 Nitrogen Generation System - B737 Training book - Page 18



522. On the NGS operability indicator, the blue light comes on

a. The system is temporarily serviceable, but in a decreased capacity. No maintenance is necessary.

b. The system is unserviceable. You must manually close and lock the nitrogen generation system shutoff valve

c. There is not blue light on the NGS operability indicator.

(B1) Ref: Reference: ATA 47 Nitrogen Generation System - B737 Training book - Page 66



523. How to access to the NGS BITE display unit (BDU)?

a. On the aft bulkhead of the right main wheel well

b. At the ceiling of the air conditioning distribution compartment

c. Through the access door to the pneumatic ground connector

(B1) Ref: Reference: ATA 47 Nitrogen Generation System - B737 Training book - Page 68



ATA 49:

524. How much electrical power can the APU generator supply up to 32.000 feet?

a. 115 KVA

b. 90 KVA

c. 66 KVA

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 6



525. What is the maximum airplane altitute that the APU can supply pneumatic power alone?

a. 17000 feet

b. 32000 feet

c. 14000 feet

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 6



526. When does the ECU energize the APU ignitor unit?

a. At 7 percent speed.

b. At approximately 30 percent speed.

c. At 0 percent speed and before the start system is energized.

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 13



527. An overspeed shutdown occurs if the APU speed is

a. More than 106 percent

b. More than 110 percent

c. More than 101 percent

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 118



528. The APU starter-generator has a shorted rotating diode that makes the FAULT light on. Can you start the APU?

a. Yes, follow normal APU start procedure.

b. No, you must replace the starter generator

c. Yes, after you enter STARTOK on the scratch pad of the CDU Current Status page of APU BITE TEST and then push the line select key on the top right side of the CDU.

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 118



529. What is the maximum airplane altitute that the APU can be start?

a. 41000 feet

b. Any altitude.

c. 32000 feet

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 6



530. Which component is not in the APU bleed air system?

a. Load compressor

b. APU engine compressor

c. Inlet guide vanes

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 85



531. How long does the APU make a cool down cycle?

a. 60 seconds

b. 120 seconds

c. There is no cool time.

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 15



532. The blue MAINT light on the P5 panel comes on and the LOW message shows on the APU oil quantity page of the CDU

a. When approximately 4.3 quarts (4.1 liters) of oil remains in the APU sump.

b. When approximately 3.8 quarts (3.6 liters) of oil remains in the APU sump.

c. When the APU sump holds 5.7 quarts (5.4 liters) of oil

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 99



533. The MAINT light shows that the APU oil level is at low oil quantity (LOQ). How do you know the APU operation time since low oil quantity?

a. In the APU operation log book.

b. APU BITE test and the CDU shows the APU operation hours since the start of the LOW message.

c. APU BITE test and the CDU shows the APU operation hours since the start of the ADD message.

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 139



534. You can check the APU oil quantity by using CDU - The OIL QUANTITY page of APU BITE TEST

a. Any time the ECU has power.

b. The ECU has power and airplane is on ground

c. The ECU has power, airplane is on ground and APU is not in operation or in the fisrt hour of operation after start.

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 139



535. The ECU shuts down the APU when APU speed is more than 95 percent and the oil pressure is less than 30-40 psi for more than 20 second, which lights in flight compartment come on?

a. LOW OIL PRESSURE (P5), MASTER CAUTION (P7), APU annunciator (P7)

b. FAULT (P5), MASTER CAUTION (P7), APU annunciator (P7)

c. LOW OIL PRESSURE (P5), FAULT (P5), APU annunciator (P7)

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 98



536. The ECU shuts down the APU when the APU speed is more than 95 percent and oil temperature is 290F/143C or more, which lights in flight compartment come on?

a. LOW OIL PRESSURE (P5), MASTER CAUTION (P7), APU annunciator (P7)

b. FAULT (P5), MASTER CAUTION (P7), APU annunciator (P7)

c. MAINT (P5), FAULT (P5), APU annunciator (P7)

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 98



537. When does the DUAL BLEED light come on?

a. APU bleed air valve is open, engine 1 or 2 bleed switch is ON and the isolation valve is close

b. APU bleed air valve is open, both engine bleed switches are OFF and the isolation valve is open.

c. APU bleed air valve is open, engine 1 or 2 bleed switch is ON and the isolation valve is open. (B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 98



538. How is the APU oil cooled?

a. Air from the APU inlet door

b. The APU exhaust causes a suction of air from outside through the eductor inlet duct.

c. Air from APU bleed system

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 93



539. How many APU bleed modes?

a. Two modes: On ground and in the air.

b. Four modes:duct pressurization, main engine start, air conditioning system (ACS) and NSG Modes.

c. Four modes:No bleed, duct pressurization, main engine start and air conditioning system (ACS).

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 77



540. How to deactivate/ activate the blue MAINT light in case of low oil quantity condition?

a. Open/close the MAINT light circuit breaker.

b. Enter LOQOFF/ LOQON on the IDENT/CONFIG page 2 of the CDU - APU BITE

c. Enter OFF/ ON on the IDENT/CONFIG page 1 of the CDU - APU BITE

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 139



541. The purpose of the 60 second APU cool down is

a. To prevent coke in the turbine bearing and fuel nozzles

b. To let the air completely go out of the bleed system.

c. To let the APU engine compartment cool

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 15



542. For APU operation, if there is no AC power for fuel boost pump,

a. The APU DC boost pump supplies fuel from the left main tank or the APU suction fuel feeds from the left main tank.

b. The APU DC boost pump supplies fuel from the right main tank

c. the APU suction fuel feeds from the right main tank

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 43



543. What is the function of APU start power unit (SPU)?

a. Changes the 270v dc power to three-phase ac start power

b. Changes 115v ac or 28v dc electrical power to 270v dc power

c. Changes 28v dc electrical power to 270v ac power

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 55,62



544. What is the function of APU start conerter unit (SCU)?

a. Changes the 270v dc power to three-phase ac start power

b. Changes 115v ac or 28v dc electrical power to 270v dc power

c. Changes 115v ac electrical power to 270v ac power

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 55,62



545. For maintenance practices on APU system, what is NOT recommened?

a. Read DMM data with special test equipment or with CDU.

b. Remove the data memory module and ECU at the same time.

c. Replace the data memory module with a blank module (a module with no data in memory).

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 147



546. Where does the APU bleed air come from?

a. APU engine compressor

b. APU load compressor

c. APU engine turbine

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 85



547. Which component are not line replaceable in APU bleed system?

a. Load compressor and surge control valve

b. Load compressor and bleed air valve

c. Load compressor and inlet guide vanes

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 65



548. What is the maximum duty cycle for APU start?

a. Three starts, one after the other, followed by a 15-minute cool down period.

b. Two starts, one after the other, followed by a 10-minute cool down period.

c. There is no limit.

(B1) Ref: Reference: ATA 49 APU - B737 Training book - Page 55



ATA 52:

549. You can operate entry, galley service, and cargo doors in winds up to

a. 40 knots

b. 55 knots

c. 65 knots

(B1) Ref: Reference: ATA 52 Doors (Book 1) - B737 Training book - Page 4



550. You can let the entry, galley service, and cargo doors stay latched open in winds up to

a. 40 knots

b. 55 knots

c. 65 knots

(B1) Ref: Reference: ATA 52 Doors (Book 1) - B737 Training book - Page 4



551. The dead bolt lever of flight compartment door has

a. 3 position: unlocked, locked with key operable, locked with key inoperable

b. 2 position: unlocked, locked with key operable

c. 2 position: unlocked, locked

(B1) Ref: Reference: ATA 52 Doors (Book 1) - B737 Training book - Page 144



552. The flight compartment door lock switch is a 3-position rotary switch

a. UNLKD, AUTO, and DENY

b. UNLKD, AUTO and LOCKED

c. ACCEPT, AUTO and DENY

(B1) Ref: Reference: ATA 52 Doors (Book 1) - B737 Training book - Page 145



553. Can you open the flight compartment door from the passenger compartment side if the door is not locked by dead bolt ?

a. No, the door is only opened from flight compartment.

b. Yes, by using a backup key.

c. Yes, by enterring the emergency access code on the keypad from the passenger compartment side.

(B1) Ref: Reference: ATA 52 Doors (Book 1) - B737 Training book - Page 151



554. Where can you control the forward airstair?

a. From inside the airplane only.

b. From outside the airplane only.

c. From inside and outside the airplane only.

(B1) Ref: Reference: ATA 52 Doors (Book 2) - B737 Training book - Page 54



555. How do you operate the forward airstar?

a. Fully by manual operation

b. Fully by electrical operation

c. By Electrically operate with manually operation of the handrail extension after the airstair fully extension and before airstair retraction.

(B1) Ref: Reference: ATA 52 Doors (Book 2) - B737 Training book - Page 54



556. The forward airstar door

a. Opens inwards the airplane by electric motors.

b. Opens outwards the airplane by manually.

c. Opens inwards or outwards the airplane depending on the operator.

(B1) Ref: Reference: ATA 52 Doors (Book 2) - B737 Training book - Page 7



557. How many modes of the forward airstair operation?

a. Two modes: Normal and manual

b. Two mode: Normal and standby

c. Three modes: Normal, standby and manual

(B1) Ref: Reference: ATA 52 Doors (Book 2) - B737 Training book - Page 54



558. What mechanism locks the passenger door in the fully open position?

a. Door latches

b. A guide pin

c. A lock mechanism in the upper hinge

(B1) Ref: Reference: ATA 52 Doors (Book 1) - B737 Training book - Page 8



559. Which components must be removed before you can remove the lining and insulation panel of passenger door?

a. the door assist handles

b. The emergency escape slide, the door assist handles, the control handle

c. The emergency escape slide, the door assist handles

(B1) Ref: Reference: ATA 52 Doors (Book 1) - B737 Training book - Page 11



560. What is the function of passenger door handle mechanism?

a. Moves a closed and latched door to the cocked open position

b. Moves a door in the cocked open position to the closed and latched position

c. Moves a closed and latched door to the cocked open position and Moves a door in the cocked open position to the closed and latched position

(B1) Ref: Reference: ATA 52 Doors (Book 1) - B737 Training book - Page 14



561. Where is the section 48 Access and Blowout Door?

a. On the left side of the lower fuselage, aft of the aft pressure bulkhead

b. On the right side of the lower fuselage, aft of the aft pressure bulkhead

c. On the left side of the lower fuselage, forward of the aft pressure bulkhead

(B1) Ref: Reference: ATA 52 Doors (Book 1) - B737 Training book - Page 114



562. Make sure that the gap between the electric strike assembly and flight compartment door is within:

a. 5.08 ±0.76 mm

b. 6.08 ±0.76 mm

c. 7.08 ±0.76 mm

(B1) Ref: Reference AMM TASK 52-51-03-400-801,Item 3. Electric Strike Installation, Item F.Electric Strike Installation, Item (4), Rev Sep2023, Maintenance Manual Part I, Xiamen Air



563. Before Door Warning System Test, what things must be checked?

a. Make sure the two MASTER CAUTION lights in the master caution annunciators on the Glareshield Panel, P7, come on

b. Make sure that the girt bar is not engaged in the bracket of the floor-mounted escape slide

c. Make sure the applicable door warning light on the Forward Overhead Panel, P5, comes on

(B1) Ref: Reference AMM TASK 52-71-00-730-801 Door Warning System Test, B. Door Warning System Test, Warning iterm, Rev Sep2023, Maintenance Manual Part I, Xiamen Air



564. The cargo doors have an interface with the door warning system. Each door has:

a. a pin-type microswitch on one of its latch fittings

b. two pin-type microswitches on one of its latch fittings

c. three pin-type microswitches on one of its latch fittings

(B1) Ref: Reference: ATA 52 Doors (Book 1) - B737 Training book - Page 102



565. You can open and close the cargo doors from

a. only inside

b. only outside

c. inside and outside

(B1) Ref: Reference: ATA 52 Doors (Book 1) - B737 Training book - Page 110



566. The IDG oil reservoir access door is:

a. On the left forward engine fan cowl

b. On the right forward engine fan cowl

c. On the left aftward engine fan cowl

(B1) Ref: Reference: ATA 52 Doors (Book 1) - B737 Training book - Page 114



567. The refueling station access door hinges on its forward edge. It is held closed by

a. four push-button latches on its aft edge

b. three push-button latches on its aft edge

c. two push-button latches on its aft edge

(B1) Ref: Reference: ATA 52 Doors (Book 1) - B737 Training book - Page 131



568. The refueling station access door is on:

a. the trailing edge of the right wing, outboard of the engine

b. the leading edge of the left wing, outboard of the engine

c. the leading edge of the right wing, outboard of the engine

(B1) Ref: Reference: ATA 52 Doors (Book 1) - B737 Training book - Page 131



569. The high pressure connector access door has hinges on its forward edge and has:

a. two pushbutton latches

b. three pushbutton latches

c. four pushbutton latches

(B1) Ref: Reference: ATA 52 Doors (Book 1) - B737 Training book - Page 135



570. The hydraulic brake accumulator access door is part of the wing to body fairing. It is

a. Aft of the left main landing gear wheel well

b. Aft of the left nose landing gear wheel well

c. Aft of the right main landing gear wheel well

(B1) Ref: Reference: ATA 52 Doors (Book 1) - B737 Training book - Page 137



ATA 51-57:

571. The length of the B737-700 airplane:

a. 33.6 M

b. 31.2 M

c. 39.5 M

(B1) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 10



572. Use these dimensions to find components on the fuselage:

a. Body station line, Body buttock line, Water line

b. Body station line, Water line

c. Body station line, Water line

(B1) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 12



573. The body buttock line (BL) is

a. is a horizontal dimension. It starts at station line zero

b. is a height dimension. Measure the water line from a horizontal reference plane below the airplane

c. a lateral dimension. Measure the buttock line to the left (LBL) or right (RBL) of the airplane center line

(B1) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 12



574. The nose of the airplane is

a. station 140

b. station 130

c. station 150

(B1) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 12



575. Measure the vertical stabilizer station

a. perpendicular to the rudder hinge centerline. Rudder station 0 starts at the body crown line.

b. perpendicular to the vertical stabilizer leading edge. Vertical stabilizer leading edge station 0 starts at the body crown line

c. Perpendicular to the vertical stabilizer rear spar. Vertical stabilizer station 0 starts at the body crown line

(B1) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 16



576. Measure the vertical stabilizer waterline

a. Perpendicular to the vertical stabilizer rear spar

b. perpendicular to the rudder hinge centerline

c. parallel to the body waterline

(B1) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 16



577. Measure stabilizer stations

a. perpendicular to the horizontal stabilizer rear spar

b. Perpendicular to the horizontal stabilizer leading edge

c. perpendicular to the elevator hinge centerline

(B1) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 18



578. When titanium is heated, different oxides having different colors form on the surface, a blue oxide coating will form at:

a. 700°F (371°C) to 800°F (427°C)

b. 800°F (427°C) to 950°F (510°C)

c. 1000°F (538°C) or higher

(B1) Ref: B737 CORROSION IDENTIFICATION - TYPES AND CAUSES - MAINTENANCE

PRACTICES, Reference AMM 51-00-50/201, item C. TITANIUM , Item (b) When titanium is heated, different oxides having different colors form on the surface TITANIUM, Rev Sep2023, Xiamen Air



579. When titanium is heated, different oxides having different colors form on the surface, a purple oxide will form at:

a. 700°F (371°C) to 800°F (427°C)

b. 800°F (427°C) to 950°F (510°C)

c. 1000°F (538°C) or higher

(B1) Ref: B737 CORROSION IDENTIFICATION - TYPES AND CAUSES - MAINTENANCE PRACTICES, Reference AMM 51-00-50/201, item C. TITANIUM , Item (b) When titanium is heated, different oxides having different colors form on the surface TITANIUM, Rev Sep2023, Xiamen Air



580. When titanium is heated, different oxides having different colors form on the surface, a gray or black oxide will form at:

a. 700°F (371°C) to 800°F (427°C)

b. 800°F (427°C) to 950°F (510°C)

c. 1000°F (538°C) or higher

(B1) Ref: B737 CORROSION IDENTIFICATION - TYPES AND CAUSES - MAINTENANCE PRACTICES, Reference AMM 51-00-50/201, item C. TITANIUM , Item (b) When titanium is heated, different oxides having different colors form on the surface TITANIUM, Rev Sep2023, Xiamen Air



581. What is not primary structure:

a. Doors

b. Radome

c. Landing Gear

(B1) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 22



582. Most of the material in the radome is

a. steel

b. fiberglass

c. Aluminium

(B1) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 32



583. The lightning diverter strips

a. increase lightning energy and transmit it to the airframe

b. decrease lightning energy and transmit it to the wing

c. decrease lightning energy and transmit it to the airframe

(B1) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 32



584. The winglets are made of

a. graphite spars, aluminum ribs and aluminum skins

b. graphite spars, aluminum ribs and graphite skins

c. aluminum spars, aluminum ribs and aluminum skins

(B1) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 46



585. Most of material in the horizontal stabilizer is

a. aluminum

b. graphite

c. fiberglass

(B1) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 50



586. Extra Critical aerodynamic surfaces are

a. those near static discharge, pitot probes and angle of attack sensors

b. those surfaces that must have a high level of aerodynamic smoothness

c. those near static pressure ports, pitot probes and angle of attack sensors

(B1) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 58



587. Dent is

a. a damaged area that is pushed in from its normal contour with no change in the crosssectional area of the material

b. a damaged area where the result is a crosssectional change caused by a sharp object

c. is damage that goes fully through a part thickness and has no regular shape

(B1) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 63



588. The process for evaluating waviness is

a. Measure the depth of the wave, plot measurements on the chart to see if wave is excessive or in the area of best aerodynamic performance

b. Measure the length of the wave in the direction of the airflow, plot measurements on the chart to see if wave is excessive or in the area of best aerodynamic performance

c. Measure the length of the wave in the direction of the airflow, measure the depth of the wave, plot measurements on the chart to see if wave is excessive or in the area of best aerodynamic performance

(B1) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 68



589. General types of repairs that can be used to restore the load-carrying capability on the fuselage

a. External rough repair, external clean repair, internal flush repair

b. External rough repair, internal flush repair

c. External clean repair, internal flush repair

(B1) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 72



590. External rough repair

a. affect the aerodynamic smoothness of the surface, it will increase the drag and the fuel burn

b. has no aerodynamic penalty

c. Aerodynamic sealer

(B1) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 72



591. Internal flush repair

a. affect the aerodynamic smoothness of the surface

b. Is sealed by the cabin differential pressure

c. no fuel burn penalty

(B1) Ref: Reference: ATA 51 STRUCTURES (Book 1) - B737 Training book - Page 72



592. These are the types of windows on the airplane:

a. Flight compartment windows (fixed and sliding), passenger compartment windows, door-mounted windows, overwing emergency exit door windows, mid cabin emergency exit door windows

b. Flight compartment windows (fixed and sliding), passenger compartment windows, door-mounted windows, overwing emergency exit door windows

c. Flight compartment windows (fixed and sliding), passenger compartment windows, overwing emergency exit door windows, mid cabin emergency exit door windows

(B1) Ref: Reference: ATA 56 STRUCTURES (Book 1) - B737 Training book - Page 3



593. Flight compartment windows can be opened?

a. windows 1 and 3

b. windows 2

c. windows 2 and 3

(B1) Ref: Reference: ATA 56 WINDOWS (Book 1) - B737 Training book - Page 5



594. Which windows get heat from the window anti-ice system?

a. Flight compartment windows 1, 2 and 3

b. Flight compartment windows 1 and 3

c. Flight compartment windows 1 and 2

(B1) Ref: Reference: ATA 56 WINDOWS (Book 1) - B737 Training book - Page 5



595. Which windows have a small hole in the upper forward corner of the inner pane?

a. Flight compartment window 3

b. Flight compartment window 1

c. Flight compartment window 2

(B1) Ref: Reference: ATA 56 WINDOWS (Book 1) - B737 Training book - Page 9



596. The passenger compartment windows have these components:

a. Outer pane,inner pane

b. Outer pane, Middle pane

c. Outer pane, middle pane, inner pane

(B1) Ref: Reference: ATA 56 WINDOWS (Book 1) - B737 Training book - Page 15



597. The middle pane gives the structural fail-safe function. It can hold

a. 1.5 times the normal pressure load

b. 2.5 times the normal pressure load

c. 3.5 times the normal pressure load

(B1) Ref: Reference: ATA 56 WINDOWS (Book 1) - B737 Training book - Page 15



598. The passenger compartment, which pane is not structural?

a. Outer pane

b. Inner pane

c. Middle pane

(B1) Ref: Reference: ATA 56 WINDOWS (Book 1) - B737 Training book - Page 15



599. Passenger Cabin Window Inspection, no need to replace the middle pane if

a. cracks that start from the vent hole and are 0.062 in. (1.575 mm) or less in length

b. it is crazed

c. the thickness is less than 0.157 in

(B1) Ref: B737 Passenger Cabin Window Inspection, Reference AMM TASK 56-21-00-200-801, E. Passenger Cabin Window Inspection, (2) Examine the middle pane for damage, Note item, Maintenance Manual Part 2, Rev Sep2023, Xiamen Air



600. The door-mounted windows have inner pane made from

a. stretched acrylic

b. polycarbonate

c. fiberglass.

(B1) Ref: Reference: ATA 56 WINDOWS (Book 1) - B737 Training book - Page 21



601. The outer pane of the door-mounted windows is made from

a. stretched acrylic

b. polycarbonate

c. fiberglass.

(B1) Ref: Reference: ATA 56 WINDOWS (Book 1) - B737 Training book - Page 21



602. The outer and middle panes are resistant to 1.5 times of the usual pressure loads at a temperature of

a. 70F

b. 80F

c. 90F

(B1) Ref: Reference: ATA 56 WINDOWS (Book 1) - B737 Training book - Page 21



603. The mid cabin emergency exit door window has these components:

a. Outer mounting ring, inner mounting ring

b. Prismatic viewer, inner mounting ring

c. Outer mounting ring, prismatic viewer, inner mounting ring

(B1) Ref: Reference: ATA 56 WINDOWS (Book 1) - B737 Training book - Page 19



604. The prismatic viewer is held to the door structure by

a. by the mounting rings and 3 attachment points

b. by the mounting rings and 2 attachment points

c. by the mounting rings and 4 attachment points

(B1) Ref: Reference: ATA 56 WINDOWS (Book 1) - B737 Training book - Page 19



605. Control cabin sliding windows can be opened from

a. inside and outside

b. only inside

c. only outside

(B1) Ref: Reference: ATA 56 WINDOWS (Book 1) - B737 Training book - Page 12



C. QUESTION BANK FOR B737NG CAT B2 (AIRFRAME)



ATA 00:

1. The controls and displays on the P7 glareshield panel include

a) Master caution annunciators, system caution annunciators, Display select panel, EFIS control

b) Master caution annunciators, system caution annunciators, lighting control, EFIS control panels, fire

c) Master caution annunciators, system caution annunciators, mode control panel, EFIS control panels,

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 39



2. The E6 equipment rack is in

a) The right side of forward cargo compartmen, aft of the cargo door

b) The right side of aft cargo compartmen, aft of the cargo door

c) The right side of EE compartment

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 55



3. The E1 rack includes electronics for

a) Autothrottle, autopilot, navigation, flight control

b) Autothrottle, communication, navigation, flight control

c) Autothrottle, autopilot, communication, navigation, flight control

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 59



4. Which equipment rack does not have forced air cooling

a) E2-1 rack

b) E2-2 rack

c) E3-1 rack

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 61



5. Which component gives an external method to customize a computer’s program?

a) Program switch module

b) Configuration box

c) Program switch module and configuration box

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 67



6. With Boeing BITE when BITE starts

a) EXISTING FAULTS? shows

b) FAULT HISTORY? shows

c) GROUND TEST? shows

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 135



7. This airplane has

a) 3 main jack points and 5 auxiliary jack points

b) 3 main jack points and 4 auxiliary jack points

c) 3 main jack points and 6 auxiliary jack points

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 151



8. What is the maximum wind speed, that you can put the airplane on jacks?

a) 35 knots

b) 30 knots

c) 25 knots

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 151



9. The airplane can jack at axle jack point

a) At its maximum zero fuel weight

b) At its maximum taxi weight

c) At its maximum takeoff weight

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 153



10. The airplane must be level when it is on jack for

a) Weighing the airplane, general airplane maintenance

b) Weighing the airplane, gear retraection test

c) Weighing the airplane, general airplane maintenance, gear retraection test

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 155



11. The inclinomenters in the left side wheel well is used

a) With the fuel sticks to find the fuel quantity when manual fueling

b) To level the airplane

c) With the fuel sticks to find the fuel quantity when manual fueling or to level the airplane

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 157



12. You can weigh the airplane with

a) Three equally accurate procedures

b) Four equally accurate procedures

c) Five equally accurate procedures

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 159



13. Which document you can find the instruction for lifting and shoring the airplane?

a) Structure repair manual

b) Airplane recovery document

c) Weight and balance control and loading manual

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 161



14. The pitot probe covers and static port covers are recommended

a) When the airplane is parked for more than a standard turnaround

b) When conditions such as insect activity, dust stoms or volcanic ash

c) When the airplane is parked for more than a standard turnaround or conditions such as insect

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 167



15. To prevents a discharge of the battery when you set the parking brake (such as for 24 hours

a) Open the circuit breaker of parking brake control unit

b) Open the circuit breaker of antiskid/autobrake valve

c) Open the circuit breaker for the antiskid/autobrake control unit and the parking brake valve

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 165



16. When grounding the airplane

a) Always attach the grouding cable to the ground connection first

b) Always attach the grouding cable to the airplane first

c) There is no spectial sequence

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 169



17. During pressure refueling

a) Grounding and electrical bond between the airplane and the refueling vehicle is recommended

b) Grounding is not necessary and electrical bond between the airplane and the refueling vehicle is

c) Grounding is recommended

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 169



18. The airplane is normally electrostatically grounded through

a) Grounding point

b) Static discharger

c) Conductive tires

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 169



19. You can find the procedures for long storage in

a) Aircraft maintenance manual

b) Structure repair manual

c) Airplane recovery document

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 171



20. The placards and markings includes

a) Pressure sensitive decals, vinyl placards, aluminum foil markers

b) Pressure sensitive decals, aluminum foil markers, stencil markings

c) Pressure sensitive decals, vinyl placards, aluminum foil markers, stencil markings

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 177



21. Which AMM chapter you can find the details airworthiness limitations?

a) Chapter 5

b) Chapter 6

c) Chapter 20

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 179



22. In AMM chapter 5 which section you can find the details the required conditional inspections

a) The zonal inspection section

b) Time limits/maintenance check section

c) Unscheduled maintenance check section

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 179



23. The fully charge brake accumulator can keep the brakes pressure for

a) At least 8 hours

b) At least 12 hours

c) At least 15 hours

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 187



24. When you tow the airplane from the main LDG the maximum turn angle is

a) 30 degree from the LDG center line

b) 90 degree from the LDG center line

c) 70 degree from the LDG center line

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 191



25. The maximum normal towing turning limits are indicated by the painted stripes on

a) The lower fuselage below left pax door

b) The nose gear doors

c) The lower fuselage below right pax door

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 185, 191



26. The design of the airplane will permit you to tow the airplane from

a) The nose landing gear

b) The main landing gear

c) The nose landing gear or main landing gear

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 189



27. When you tow the airplane from the main LDG

a) You must use the tow bar

b) You must use the towbarless

c) You must install a special eyebolt

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 189



28. When towing on the soft ground or an incline

a) You must towing from the NLG

b) You must towing from the MLG

c) You can towing from the NLG or MLG

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 191



29. Which documnent gives tasks for each type of scheduled maitenance check?

a) Maintenance planning document

b) Aircraft maintenance manual

c) Aircraft recovery manual

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 193



30. Observed faults are

a) The malfunctions that the flight crew can see

b) The malfunctions that the flight crew or cabin crew can see

c) The malfunctions that the flight crew or ground service crew can see

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 199



31. In the MMEL, the interval categories show ‘A’ mean

a) The repair interval is within 3 consecutive calendar days

b) The repair interval is within 10 consecutive calendar days

c) The repair interval is as show in the remarks

(B2) Reference: ATA 00 Introduction - B737 Training book - Page 202



ATA 21:

32. On B737-600/700 which component controls pack cooling temperature?

a) Pack/zone temperature controller

b) Cabin temperature controller

c) Air conditioning accessory unit

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 10



33. On B737-800/900 which component controls pack cooling temperature?

a) Pack/zone temperature controller

b) Cabin temperature controller

c) Air conditioning accessory unit

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 12



34. On B737-600/700 the ram air temperature sensor supply temperature data to

a) Cabin temperature controller

b) Pack/zone temperature controller

c) Ram air inlet controller

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 54



35. During cruise, the RAM DOOR FULL OPEN light will come on when

a) Heat exchangers are dirty or Electrical failure

b) Ram air system has a blockage or Electrical failure

c) Ram air system has a blockage or Heat exchangers are dirty or Electrical failure

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 58, 62



36. On B737-600/700 how to check the coalescer bag condition?

a) Observe the bag condition indicator while the pack operates in high flow and the air mix valve is in

b) Observe the bag condition indicator while the pack operates in high flow

c) Observe the bag condition indicator while the air mix valve is in full cold position

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 68



37. On B737-600/700 which component control the low limit valve?

a) Cabin temperature controller

b) Low limit controller

c) Pack/zone temperature controller

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 72



38. On B737-600/700 on the low limit controller which position of the rotary select switch does a

a) Position 3

b) Position 4

c) Position 5

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 78



39. How many water extractors are installed on B737-800/900 ?

a) There are four water extractors, two in each air conditioning pack

b) There are two water extractors, one in each air conditioning pack

c) This aircraft type does not use water extractor

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 88



40. On B737-600/700 and -800/900 water separator mix muffs are

a) The same and interchangeable

b) The same but not interchangeable

c) Different and not interchangeale

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 92



41. Which lights illuminate when a pack trip occurs?

a) PACK TRIP OFF light, MASTER CAUTION and AIR COND annunciator lights

b) PACK light, MASTER CAUTION and AIR COND annunciator lights

c) PACK TRIP OFF (600/700) light, PACK (800/900) light, MASTER CAUTION and AIR COND

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 114



42. How many zone the Conditioned Air Distribution system divides on B737-800/900?

a) Two zones: flight compartment and passenger compartment

b) Three zones: flight compartment, forward passenger compartment and aft passenger compartment

c) Four zones: flight compartment, forward passenger compartment, midle passenger compartment and

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 116



43. The sources of the main air distribution system are

a) Air conditioning packs, Ground conditioned air

b) Air conditioning packs, Recirculation system

c) Air conditioning packs, Ground conditioned air, Recirculation system

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 118



44. On B737-600/700 the hot and cold air mix together in

a) The mix chambers

b) The mix manifold

c) Main distribution manifold

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 126



45. The flight compartment normally get conditioned air from

a) Left air conditionng pack

b) Right air conditioning pack

c) Main distribution manifold

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 128



46. The recirculation fan system provides

a) Filtered air supply into the main distribution manifold

b) Unfiltered air supply into the main distribution manifold

c) Air supply directly from distribution manifold into the passenger cabin

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 138-140



47. How many recirculation fan installed on B737-600/700

a) One fan

b) Two fans

c) Three fans

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 140



48. On B737-800/900 with airplane on ground and recirculation fan switch in AUTO postion, the left recirculation fan will turn off when

a) Left and right pack low flow operation

b) Left and right pack high flow operation

c) Left or right pack high flow operation

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 149



49. On B737-600/700 The flight compartment temperature sensor fan comes on when

a) 115v ac is available, the left pack switch is in AUTO or HIGH

b) 115v ac is available, the left pack switch is in AUTO or LOW

c) 115v ac is available, the left pack switch is in LOW

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 158



50. On B737-600/700 the cabin temperature controller (CTC) monitors the air temperature from

a) Cabin temperature sensor, Duct temperature limit sensor

b) Cabin temperature sensor, Duct temperature anticipator sensor

c) Cabin temperature sensor, Duct temperature anticipator sensor, Duct temperature limit sensor

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 170



51. On B737-600/700 the cabin temperature indicator shows

a) The passenger cabin air temperature

b) The passenger supply duct air temperature

c) The passenger cabin air temperature or the passenger supply duct air temperature

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 180



52. The equipment coolong system removes heat from

a) Electronic components in the flight compartment and EE compartment

b) Electronic components in the flight compartment only

c) Electronic components in the EE compartment only

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 242



53. How many zone trim air modulating valves installed on B737-800/900 ?

a) One valve

b) Two valves

c) Three valves

(B2) Reference: ATA 21 Air conditioning system (1 of 2) - B737 Training book - Page 210



54. The cabin pressure relief system has

a) Two positive pressure relief valves and one negative pressure relief valve

b) One positive pressure relief valve and one negative pressure relief valve

c) Two positive pressure relief valves and two negative pressure relief valves

(B2) Reference: ATA 21 Air conditioning system (2 of 2) - B737 Training book - Page 2



55. The cabin altitude warning alarm

a) Will sound intermittent horn when the cabin altitude increases to more than 10,000 feet

b) Will sound intermittent hornwhen the cabin altitude increases to more than 14,000 feet

c) Will sound intermittent hornwhen the cabin altitude increases to more than 15,000 feet

(B2) Reference: ATA 21 Air conditioning system (2 of 2) - B737 Training book - Page 5, 64



56. When do the cabin pressure controllers (CPC) control cabin pressure?

a) When the system is in the MAN mode of operation

b) When the system is in the AUTO mode of operation

c) When the system is in the AUTO or ALTN mode of operation

(B2) Reference: ATA 21 Air conditioning system (2 of 2) - B737 Training book - Page 18



57. When both CPC systems fail

a) The AUTO FAIL and MASTER CAUTION lights come on, the FLT ALT and LAND ALT

b) The AUTO FAIL and ALTN lights come on, the FLT ALT and LAND ALT displays show five

c) The ALTN and MASTER CAUTION lights come on, the FLT ALT and LAND ALT displays show

(B2) Reference: ATA 21 Air conditioning system (2 of 2) - B737 Training book - Page 45



58. When the pressurization system is in the AUTO mode and an auto fail event occurs, the AUTO

a) You select the MAN position on the mode selector

b) You select the ALTN position on the mode selector

c) You select the ALTN or MAN position on the mode selector

(B2) Reference: ATA 21 Air conditioning system (2 of 2) - B737 Training book - Page 45



59. How to close the positive pressure relief valves after they open?

a) Manually by turn the select switch on cabin pressure selector panel to MAN and push the valve switch to close position when airplane on ground

b) Manually by turn the select switch on cabin pressure selector panel to MAN and push the valve

c) Automatically close when the cabin-to-ambient pressure is safe

(B2) Reference: ATA 21 Air conditioning system (2 of 2) - B737 Training book - Page 56



60. When the aft outflow valve fail in close position, which component will bleed fuselage pressure

a) The positive pressure relief valves

b) The negative pressure relief valve

c) The positive and negative pressure relief valves

(B2) Reference: ATA 21 Air conditioning system (2 of 2) - B737 Training book - Page 56



61. When does the negative pressure relief valve open?

a) When ambient pressure is 1.0 psi more than the pressure in the airplane (1.0 psid)

b) When pressure in the airplane is 1.0 psi more than the ambient pressure (1.0 psid)

c) When pressure in the airplane is 8.95 psi more than the ambient pressure (8.95 psid)

(B2) Reference: ATA 21 Air conditioning system (2 of 2) - B737 Training book - Page 58



62. The two red CABIN ALTITUDE lights come on when

a) The cabin altitude exceeds 8,000 feet

b) The cabin altitude exceeds 10,000 feet

c) The cabin altitude exceeds 14,000 feet

(B2) Reference: ATA 21 Air conditioning system (2 of 2) - B737 Training book - Page 66-68



ATA 22:

63. When airspeed is at a minimum operating speed and is close to a wing stall condition

a) The stall warning system operates the control column stick shakers to alert the crew.

b) An aural warning from the aural warning module, and the red A/P light on the autoflight status

c) The IAS/MACH Display has a warning flag that goes on and off for underspeed and overspeed (B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 9



64. These are part of the stall management function of the SMYD:

a) Stall warning, EFS, Autoslat, Performance data.

b) Stall warning, Yaw damping, Autoslat, Performance data.

c) Stall warning, Turn coordination, Autoslat, Performance data.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 13



65. The yaw damper indicator shows rudder movement because of

a) SMYD 1 primary yaw damping commands.

b) SMYD 1 or 2 primary yaw damping commands.

c) Rudder pedal. inputs

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 46



66. You engage the yaw damper system with a switch on the flight control panel. These conditions are necessary for primary yaw damping:

a) The system A hydraulic pressure is available and the FLT CTRL A switch must be ON.

b) The system B hydraulic pressure is available and the FLT CTRL B switch must be ON.

c) The system A & B hydraulic pressure is available.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 46



67. The wheel-to-rudder interconnect system (WTRIS) moves the rudder to help turns during flight

a) When on standby hydraulics.

b) When put the FLT CONT A or B switches to ON position.

c) When put the yaw damper switch to OFF.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 58



68. Conditions is necessary for SMYD BITE operation:

a) Flaps up and computed airspeed < 60 knots

b) Both engines shut down (on-side engine N1 < 15% and off-side engine N2 < 50%)

c) Flaps up and computed airspeed < 60 knots or both engines shut down (on-side engine N1 < 15% and off-side engine N2 < 50%)

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 75



69. The digital flight control system (DFCS) does these functions:

a) Autopilot, Flight director, Altitude alert, Speed trim, Mach trim, Autothrottle.

b) Autopilot, Flight director, Altitude alert, Speed trim, Mach trim.

c) Autopilot, Altitude alert, Speed trim, Mach trim, Autothrottle.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 93



70. In the CMD mode, how to control the ailerons and elevator?

a) The FCC calculates the commands that go to the autopilot actuators to control the ailerons and

b) Force transducers below the control columns sense control wheel and control column forces from the pilots and send these signals to the FCC. The FCC sends the commands to the autopilot actuators to

c) Force transducers below the control columns sense control wheel and control column forces from the pilots to control the ailerons and elevator.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 100



71. In the CWS mode, how to control the ailerons and elevator?

a) The FCC calculates the commands that go to the autopilot actuators to control the ailerons and

b) Force transducers below the control columns sense control wheel and control column forces from the pilots and send these signals to the FCC. The FCC sends the commands to the autopilot actuators to

c) Force transducers below the control columns sense control wheel and control column forces from the pilots to control the ailerons and elevator.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 100



72. Dual channel Autopilot operation is possible

a) Without any generator busses being energised.

b) When AC power is available to at least one generator bus.

c) Only when two generators are powering the busses.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 130



73. These are the CWS force transducers on the airplane:

a) Captain pitch CWS force transducer, First officer pitch CWS force transducer, Roll CWS force

b) Captain roll CWS force transducer, First officer roll CWS force transducer, Pitch CWS force

c) Captain CWS force transducer, First officer CWS force transducer, Standby CWS force transducer

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 137



74. The underspeed symbol in the MCP Speed window is a

a) Steady "A"

b) Flashing "A"

c) Flashing "8"

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 159, 182



75. During a dual pitch autopilot approach, the Autopilot Disengage light illuminates steady red when below 800 feet. This indicates

a) A normal condition

b) Both autopilots have reverted to CWS mode

c) The stabilizer is out of trim

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 164



76. If the crew wants to make a dual approach in CMD, they must put the other A/P in CMD at a

a) below 800 feet

b) more than 2500 feet

c) more than 800 feet

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 179



77. The localizer antenna switches

a) Determine if the dual VOR/LOC antenna or the localizer antenna is supplying the RF signals to the

b) Turn ON/OFF the localizer antenna.

c) Receive the localizer signal and send it directly to the localizer antenna.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 186



78. When does the receivers use the VOR/LOC antenna in the vertical stabilizer ?

a) When the FCC is in the approach or localizer mode and a localizer frequency is selected on the

b) When the FCC is in the approach or localizer mode and an ILS frequency is not selected on the

c) Always use when the FCC is in the approach or localizer mode.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 186



79. When does the receivers use the localizer antenna in the nose radome ?

a) When the FCC is in the approach or localizer mode and a localizer frequency is selected on the

b) When the FCC is in the approach or localizer mode and an ILS frequency is not selected on the

c) Always use when the FCC is in the approach or localizer mode.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 186



80. The altitude alert starts when aircarft approach the selected altitude from above or below and

a) Depending on the program pin options, 200 or 300 feet from the selected altitude.

b) Depending on the program pin options, 750 or 900 feet from the selected altitude.

c) 500 feet from the selected altitude.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 194



81. The DFCS calculates autopilot (A/P) and flight director (F/D) commands for these flight

a) Takeoff, Climb, Cruise, Descent, Go-around.

b) Climb, Cruise, Descent, Flare, Go-around.

c) Climb, Cruise, Descent, Approach, Go-around.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 213



82. Both master flight director indicator (MA) lights on the MCP panel are illuminated during

a) Approach mode is armed.

b) Independent Flight Director operation.

c) A Flight Director malfunction.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 225



83. If there is an engine failure at more than V2 plus 20 during takeoff, the target airspeed can

a) V2 is the target airspeed.

b) The IAS at the time of failure is the target airspeed.

c) There is no change to the target airspeed.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 226



84. One conditions for LNAV to engage when push the LNAV mode selector switch on the MCP is

a) The airplane heading is towards the flight path before the next waypoint or is within 3 nm of the

b) The airplane heading is towards the flight path before the next waypoint or is within 5 nm of the

c) The airplane heading is away from the flight path after the previous waypoint or is within 5 nm of

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 237



85. In this mode the airplane changes altitude with the A/P and the autothrottle (A/T).This mode gives commands for the airplane to go to the MCP selected altitude at the selected airspeed. This

a) LVL CHG.

b) VNAV.

c) ALT HLD.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 235



86. While the airplane does a climb to the FMC altitude and VNAV goes into operation, which

a) VNAV SPD.

b) VNAV PTH.

c) VNAV ALT.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 239



87. While the airplane does a descent, LNAV and VNAV are in operation, which VNAV mode

a) VNAV SPD.

b) VNAV PTH.

c) VNAV ALT.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 239



88. Condition is the autoland function in relation to the effect of a single failure. Fail operational

a) The level of redundancy is such that a single failure that occurs below alert height permits the landing to continue with the remainder of the automatic system.

b) A single failure lets the airplane stay in trim and does not cause a significant change from the flight

c) Autoland function is inoperational.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 252



89. Condition is the autoland function in relation to the effect of a single failure. Fail passive

a) The level of redundancy is such that a single failure that occurs below alert height permits the landing to continue with the remainder of the automatic system.

b) A single failure lets the airplane stay in trim and does not cause a significant change from the flight

c) Autoland function is passive and the aircraft cannot land automatically.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 252



90. If FLARE arm is not annunciated by approximately 350 feet radio altitude

a) Both autopilots will disconnect automatically.

b) Reselect APP mode on the MCP.

c) The second engaged autopilot will disengage automatically.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 254



91. Autopilot go-around arms when these conditions are true:

a) The airplane is below 2000 feet radio altitude, both autopilots are engaged to CMD and the flare

b) The airplane is below 2000 feet radio altitude, only one autopilots are engaged to CMD and the flare

c) The airplane is below 2500 feet radio altitude, both autopilots are engaged to CMD and the flare

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 268



92. During single channel approaches and the airplane is below 2000 feet of radio altitude, if the pilot pushes one of the TO/GA switches

a) The A/P disengages, the F/D go-around mode starts.

b) The A/P go-around mode starts.

c) The A/P go-around arms.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 271



93. Which categories of DFCS BITE group test require hydraulic power ?

a) Autotest.

b) Interactive.

c) Surface.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 275



94. Which categories of DFCS BITE group test require inputs from the BITE operator?

a) Autotest.

b) Interactive.

c) Surface.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 275



95. After replacing the LRU, you want to test the interface between the FCC and the LRU to ensure that the replaced LRU is working properly. What test do you take ?

a) LRU replacement tests.

b) Rigging tests.

c) Sensor values.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 279



96. After replacing, you want to check of the correct alignment of a components.What test do you

a) LRU replacement tests.

b) Rigging tests.

c) Sensor values.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 279



97. The red A/T warning lights on the ASAs come on

a) Only when the A/T disconnects.

b) Only when the A/T is in BITE.

c) When the A/T disconnects or when the A/T is in BITE.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 348



98. The message A/T LIM shows on the engine display indicates

a) The autothrottle computer calculates an FMC N1 limit for the affected engine.

b) The autothrottles are positioned at their normal operating limit as calculated by the FMC.

c) The autothrottle computer calculates one N1 limit for the two engines.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 359



99. During the take-off roll, the A/T goes to throttle hold mode:

a) When the airspeed gets to 60 kt.

b) When the airspeed gets to 80 kt.

c) When the airspeed gets to 84 kt.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 364



100. This is the takeoff sequence:

a) Preflight, Takeoff start, Takeoff roll, Climb out.

b) Preflight, Takeoff roll, Takeoff start, Climb out.

c) Preflight, Takeoff roll, Climb out, Takeoff start.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 364



101. During descent, in which pitch modes the A/T is in the ARM mode and the airplane continues to make a descent to the FMC or MCP selected altitude

a) Vertical navigation descent.

b) Level change descent.

c) Vertical speed descent.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 374



102. During descent, in which pitch modes the A/T moves the engine thrust to idle, and the airplane does a descent to the selected altitude on the MCP

a) Vertical navigation descent.

b) Level change descent.

c) Vertical speed descent.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 374



103. During descent, in which pitch modes the A/T controls thrust to keep a target airspeed on the MCP and the airplane does a descent to the target altitude on the MCP.

a) Vertical navigation descent.

b) Level change descent.

c) Vertical speed descent.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 375



104. During the approach while on glideslope the A/T mode is MCP SPD, the DFCS starts the flare maneuver to do a touchdown

a) At 27 feet radio altitude.

b) At 50 feet radio altitude.

c) At 10 feet radio altitude.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 378



105. When the crew push a TO/GA switch one time during a fully automatic approach

a) The autothrottle decreased thrust go-around mode operate.

b) The autothrottle maximum thrust go-around mode operate.

c) The autothrottle disengage.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 381



106. If FMC is valid and autopilot is not engaged, you can start A/T BITE from CDU when:

a) The EECs are not active - the start levers in CUTOFF position and the engine start switches OFF or the engines off (N2 less than 50%).

b) The EECs must be actived - the start levers in CUTOFF position and the engine start switches OFF or the engines off (N2 less than 50%).

c) The EECs active and the engines ON.

(B2) Reference: ATA 22 Autoflight system - B737 Training book - Page 383



ATA 23:

107. Where is the pilots audio selector panel located.

a) In Cockpit P8 panel

b) In Cockpit P8 and P6 panels

c) In cockpit Captain side only

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 36



108. With the Boom/Mask switch in the MASK position, transmission of a message is possible

a) By using the oxygen mask and headset only.

b) By using the oxygen mask only.

c) By using the oxygen mask or hand microphone only.

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 46 FCOM- System description - Communications - System description - Miscrophones



109. The VHF-1 transmitter selector switch on an audio selector panel is illuminated

a) Reception on VHF-1 is automatically provided

b) The ALT/NORM switch must be in NORM to obtain reception at a comfortable volume level.

c) Reception is achieved by pulling and rotating VHF-1 receiver switch.

(B2) Reference: Page 162 of ATA 23 Communication System - B737 Training book



110. Communications between the cockpit and the ground crew is possible by using the

a) Flight interphone system or the Service Interphone system provided the Service Interphone switch is

b) Flight interphone system only.

c) The Service interphone system irrespective of the position of the Service Interphone switch.

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 29,71



111. The GRD CALL switch on the Fwd Overhead panel when pressed

a) Sounds a horn in the nose wheel and main wheel wells until the ground crew select the GRD CALL CANCEL switch on the External Power receptacle panel.

b) Sounds a horn in the nose wheel and main wheel wells until released.

c) Sounds a horn in the nose wheel well until released

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 91



112. With the Alternate-Normal switch on the Captain's Audio Selector Panel selected to ALT

a) Only the VHF-1 radio is available for transmission and reception from the Captain's station.

b) Only the VHF-2 radio is available for transmission and reception from the Captain's station.

c) The VHF-1 and VHF-2 radios only are available for transmission and reception from the Captain's

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 47



113. With an audio selector panel selected to ALT ( degraded mode ), the only usable radio at that

a) At a preset volume through the headset and speaker.

b) At a variable volume through the headset and speaker.

c) At a preset volume through the headset only.

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 47



114. The pilot control wheel push to talk switch selected to INT allows

a) Direct transmission from the associated oxygen or boom microphone over the flight interphone, bypassing the Audio Selector Panel transmitter selector.

b) Direct transmission from the associated boom microphone only over the flight interphone, bypassing the Audio Selector Panel transmitter Selector.

c) Direct transmission from the associated oxygen or boom microphone over the flight interphone, provided the Audio Selector Panel Transmitter Selector is selected to FT INT.

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 46

FCOM- System description - Communications - Controls and indicators - Miscellaneous Communications control



115. Where are the service interphone jacks located.

a) External power only

b) At all flight attendance stations

c) C.APU, R&L W W, refuel station, external power, aft cabin rear ceiling, E&E, lower fuselage

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 82



116. Audio warnings for Altitude Alert, The GPWS and Windshear Warnings are heardthrough

a) The speakers only at preset volumes.

b) The speakers and headsets at preset volumes.

c) The speakers at preset volumes and the headsets at variable volumes.

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 33



117. What is the purpose of the ALT-NORM switch on the Audio Control Panel?

a) It selects an alternate radio.

b) It selects a degraded mode of operation of the ACP.

c) It swaps audio control panels with the observer.

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 47



118. In cased of degraded audio system operation:

a) Audio warnings for altitude alert are not heard.

b) Audio warnings for altitude alert and GPWS are not heard. Windshear alerts are not affected.

c) Audio warnings for altitude alert, GPWS and windshear are not heard.

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 33, 47



119. The Cockpit Voice Recorder in AUTO:

a) Always powers the CVR when DC bus 1 is powered.

b) Always powers the CVR when DC bus 2 is powered.

c) Always powers the CVR from first engine start until 5 minutes after last engine shutdown.

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 387



120. The Cockpit Voice Recorder in ON:

a) Power the CVR and will go back to the AUTO position only when you put the switch to AUTO position

b) Power the CVR and will go back to AUTO position when you manual put switch to AUTO or when engine running relay de-energizes.

c) Power the CVR and will go back to AUTO position when you manual put switch to AUTO or when

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 387



121. The CVR (orange box) is located:

a) In the forward Electronic & Equipment bay (E&E).

b) In the aft right side of the aft cargo compartment.

c) In the flight deck (under the captain's seat).

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 368



122. The call system from flight deck to cabin operates:

a) Pink lights and a hight/low chime

b) Green call lights and a twotone chime

c) Blue call lights and a single hightone chime

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 59



123. Where is observer audio control panel?

a) On the P5 aft overhead panel or the P8 aft electronics panel

b) On the P5 aft overhead panel or the P11 fwd electronics panel

c) On the P8 aft electronics panel and P11 fwd electronics panel

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 36



124. Where are The REU and the audio switching relays?

a) Above overhead panel in the cabin compartment

b) on the E4-1 rack in Electronic Equipment Compartment

c) In the flight compartment

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 37



125. Where is the external flight interphone jack?

a) On the P19 external power panel

b) In the electronic equipment compartment

c) In the main wheel well

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 40



126. The Service Interphone switch on the Aft overhead panel when selected ON

a) Deactivates external jacks sockets from the Service Interphone system.

b) Allows communications between the flight deck and the flight attendants when using the Flight

c) Adds external jack sockets to the Service Interphone system.

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 83



127. The Cockpit CALL (blue) light will illuminate along with an associated chime whenever the

a) By the flight attendants or the ground crew

b) By the ground crew only.

c) By the flight attendants only.

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 59, 91



128. The ATTEND (attendants call) is pressed and released in the cockpit and

a) A HIGHT chime sound will be heard in the passenger cabin.

b) A LOW tone chime sound will be heard in the passenger cabin.

c) A HIGHT/LOW chime sound will be heard in the passenger cabin.

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 59



129. The selcal system monitors selected frequencies in use on the

a) HF communications radios.

b) VHF communications radios.

c) HF and VHF communications radios.

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 213



130. The cockpit voice recorder keeps

a) Last 25 hour of communication data in memory.

b) Last 60 minutes of communication data in memory

c) Last 120 minutes of communication data in memory.

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 358



131. When using the Passenger address system, the priority of announcements are

a) Cockpit, Flight attendant, pre-recorded announcement, boarding music.

b) There is no priority system.

c) Cockpit, pre-recorded announcement, Flight attendant, boarding music.

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 120



132. Is it possible for the cabin attendants to communicate with the ground personnel from their respective stations

a) Yes using the flight interphone system with the Service Interphone switch selected OFF.

b) No it’s not possible

c) Yes using the service interphone system.

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 73



133. To test the Cockpit Voice Recorder

a) Press the test CVR test switch and after a slight delay observe the Monitor Indicator rise into the red

b) Plug a headset into the jack socket in the CVR panel and press the Erase switch.

c) Press the test CVR test switch and after a slight delay observe the Monitor Indicator rise into the

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 385



134. To erase the tape of the Cockpit Voice Recorder

a) Press the Erase button only when the aircraft is on the ground and the Parking Brake is OFF.

b) Press the Erase button at any time.

c) Press the Erase button 2 seconds only when the aircraft is on the ground and the Parking Brake is

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 392

FCOM- System description - Communications - Controls and indicators - Cockpit voice recorder



135. When an engine is on, the gain control circuit increases the amplifier gain by

a) 2db

b) 4db

c) 6db

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 120



136. If decompression occurs, the gain control circuit increases the amplifier gain by

a) 2db

b) 3db

c) 4db

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 121



137. Each radio communication panel can

a) Tune only one transceiver at a time

b) Tune all transceivers at a time

c) Tune only one transceiver

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 152



138. Where are the HF antenna couplers?

a) On the top of the vertical stabilizer

b) Inside the vertical stabilizer

c) On the E6 rack at the aft cargo compartment

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 184



139. The purpose of HF antenna coupler

a) Matches the transceiver 40 ohm impendance output to the antenna impendance at the set frequency

b) Matches the transceiver 50 ohm impendance output to the antenna impendance at the set frequency

c) Matches the transceiver 60 ohm impendance output to the antenna impendance at the set frequency (B2) Reference: ATA 23 Communication System - B737 Training book - Page 197



140. If the BITE in the RCP senses a failure

a) The frequency indicatiors show FAIL FAIL if the tranceiver fails

b) The frequency indicatiors show PANEL FAIL if the there is an internal failure of the RCP

c) The frequency indicatiors show FAIL FAIL if the tranceiver fails and the frequency indicatiors show PANEL FAIL if the there is an internal failure of the RCP

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 152-153



141. The ACARS MU sends a port select discrete to

a) The VHF 1 transceiver

b) The VHF 2 transceiver

c) The VHF 3 transceiver

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 148



142. When do the HF transceiver BITE test the “KEYINTERLOCK” light come on red mean?

a) HF transceiver has a failure

b) HF coupler has a failure

c) HF transceiver does not receive a signal from the RCP

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 206



143. The ELT sends homing signals to search and rescue crews on the

a) HF and VHF emergency channels

b) HF and UHF emergency channels

c) VHF and UHF emergency channels

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 231



144. How to reset if the ELT transmit accidentally?

a) Move the ELT swith on the ELT control panel to ON position then back to ARM position

b) Move the ELT swith on the ELT control panel to OFF position then back to ARM position

c) Move the ELT swith on the ELT control panel to ON the back to OFF position

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 237



145. When you can do the ELT operational test

a) Only within the first 5 minutes after the hour

b) Only within the last 5 minutes of the hour

c) At any time

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 247



146. The ACARS MU controls uplink and downlink data from

a) The HF transceiver

b) The VHF transceiver

c) The HF and VHF transceiver

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 261



147. The low noise amplifier/diplexer ( LNA/DIP)

a) Only lets the SATCOM system receive and transmit signals at the same time

b) Only increase the strength of the received low level satellite signals

c) Not only lets the SATCOM system receive and transmit signals at the same time but also increases the strength of the received low level satellite signals

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 301



148. The Satellite Data Unit ( SDU) use the inertial data from

a) ADIRU-1

b) ADIRU-2

c) ADIRU-1 and ADIRU-2

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 292



149. Which component makes the output from the Satellite Data Unit ( SDU) agree with the necessary input level for the High Power Amplifier ( HPA)

a) Intermediate gain anttenna

b) RF attenuator

c) Low noise amplifier/diplexer

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 297



150. How long the recorder independent power supply (RIPS) can supply to the voice recorder when aircraft power systems are off or malfunction?

a) 10 minutes.

b) 20 minutes.

c) 30 minutes.

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 362



151. When you do SDU BITE the SYSTEM LRU FAIL led show red mean

a) The SDU has a fault

b) Any SATCOM system LRU (include the SDU) has a fault

c) Any SATCOM system LRU (except the SDU) has a fault

(B2) Reference: ATA 23 Communication System - B737 Training book - Page 326



ATA 24:

152. Generator Drive Disconnect switch when operated

a) Disconnects the Generator Drive from the engine in the event of a Generator Drive malfunction, only if the engine has been shut down first

b) Disconnects the Generator Drive from the engine in the event of a Generator Drive malfunction

c) Disconnects the CSD from the generator in the event of a Generator Drive malfunction

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 81



153. Re-coupling of the Generator Drive drive shaft to the engine may be accomplished

a) At any time in flight provided the Generator Breaker and the Generator Control Relay have

b) At any time on the ground or in flight.

c) Only on the ground.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 71



154. One of the basic principles of the electrical system is

a) The AC sources of power can be connected in parallel if necessary

b) There is no paralleling of the AC sources of power.

c) The AC sources of power are always connected in parallel.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 91



155. When both engines are running with external power connected then

a) External power will automatically disconnect when both engine generators are brought on line.

b) External power must be selected OFF before the engine generators are brought on-line.

c) External power will automatically disconnect when either engine generator is brought on-line.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 91,110



156. To have all three Generators (APU and engines) on-line simultaneously

a) Is possible in flight only.

b) Is not possible.

c) Is possible on the ground only.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 91



157. The APU generator has

a) A Generator drive unit which will disconnect when the APU Generator drive disconnect switch is

b) A Generator drive unit which will automatically disconnect when its oil temperature is high.

c) No Generator drive unit since the APU itself is governed and will maintain a constant generator

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 118



158. An engine electrical generator is rated at

a) 90 KVA

b) 45 KVA

c) 55 KVA

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 9



159. The AC STANDBY BUS power can be supplied from

a) The APU or engine generators, external power or the battery through the Static Inverter

b) The APU or engine generators, external power or directly from the Hot Battery Bus.

c) The APU or engine generators only.

(B2) Reference: Page 21 of ATA 24 Electrical Power System - B737 Training book



160. Under normal conditions the Standby AC bus is energised from the

a) 115-volt Transfer bus No. 1

b) 115-volt Transfer bus No. 2

c) The Static Invertor.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 21



161. Pulling up an engine fire handle will

a) Trip the associated Generator Control Relay and disconnects the Generator Drive

b) Trip the associated Generator Control Relay and Breaker.

c) Trip the associated Generator Control Relay only.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 105-110



162. If the Battery switch is selected OFF, the airstairs can be lowered from the outside

a) By using the STANDBY system, but can only be raised again by use of the NORMAL system.

b) By using the NORMAL system with ground power plugged in.

c) By using the STANDBY system

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 146,164



163. To connect the External Ground power to the aircraft's Generator busses

a) The Battery switch must be OFF

b) The Battery switch must be ON.

c) The Bus Transfer switch must be in the AUTO position

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 59



164. Which of the following statements is correct

a) TR 3 normally backs up TR 2 only.

b) TR 3 normally backs up TR 1 and TR 2 provided that the BUS TRANS switch is in AUTO

c) TR 3 normally backs up TR 1 and TR 2 provided that the BUS TRANS switch is in OFF.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 145-149



165. After an overload situation has been resolved, how do you recover the galley buses?

a) It happens automatically.

b) Move the CAB/UTIL switch to OFF then ON.

c) A ground engineer should reselect the appropriate switch in the E/E

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 190



166. The electrical system incorporates an automatic load shedding feature. What is the second bus

a) Galleys on transfer bus 1

b) Galleys on transfer bus 2

c) The AC ground service bus.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 191



167. The electrical system incorporates an automatic load shedding feature. What is the first bus that is shed?

a) Galleys on transfer bus 1 are shed first.

b) Galleys on transfer bus 2 are shed first.

c) The AC standby bus is shed first.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 191



168. Which bus supplies electrical power to the auxiliary battery charger?

a) AC ground service bus 1

b) AC ground service bus 2

c) Transfer bus 2

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 91



169. On the ground, with the BATTERY switch OFF and STANDBY POWER Switch in BAT, the

a) Not powered

b) Powered by TR 3

c) Powered by the Hot Battery Bus

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 30



170. The purpose of the DC BUS tie relay is to:

a) Isolate DC bus 1 and DC bus 2

b) Connect DC bus 1 and DC bus 2

c) Disconnect TR1 and TR3

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 147



171. The switched hot battery bus is powered whenever:

a) Transfer bus 1 is powered.

b) AC ground service bus is powered.

c) The battery switch is ON.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 25



172. Illumination of the STANDBY POWER OFF light indicates:

a) DC bus 1 unpowered

b) DC bus 2 unpowered

c) AC standby bus unpowered

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 29



173. What is the purpose of the GROUND SERVICE switch?

a) Provide automatic control of ground handling bus.

b) Provide automatic control of ground service bus.

c) Provide manual control of ground service bus.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 22



174. DC busses powered from the battery following a loss of both generators are:

a) DC standby Bus, Hot Battery Bus & Switched hot battery bus.

b) Battery bus, DC Standby bus, Hot battery bus & Switched hot battery bus (even when the battery

c) Battery bus, DC Standby bus, Hot battery bus & Switched hot battery bus.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 169



175. In flight if APU is the only source of electrical power:

a) All galley busses are automatically shed

b) Only galley bus 1 is automatically shed

c) Only galley bus 2 is automatically shed

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 191



176. With the STANDBY switch in the AUTO position, battery switch ON, the loss of all engine or APU electrical power results in the automatic switching from the normal power source to the

a) On the ground only.

b) Either inflight or on the ground.

c) Will not occur.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 177



177. What is the significance of an illuminated ELEC light?

a) One of the three TRs has failed.

b) The DC system or standby power system has failed.

c) The battery is discharged.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 25



178. The ELEC light will illuminate in flight if:

a) A fault exists in the AC or Standby power system.

b) A fault exists in the AC, DC or the Standby system.

c) The ELEC light only operates on the ground.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 25



179. The TR UNIT will illuminate in flight if:

a) Any TR unit fails.

b) TR1 fails or TR2 and TR3 fail.\

c) TR2 fails.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 25



180. On the ground, with the battery switch OFF and STANBY POWER Switch in AUTO, the

a) Not powered.

b) Powered by TR3.

c) Powered by the Hot Battery Bus.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 29



181. Illumination of the blue GEN OFF BUS light indicates:

a) The associated generator bus is not powered

b) The associated transfer bus is not powered

c) The IDG is not supplying power to its associated transfer bus

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 34



182. The 115V AC Standby Bus is powered by:

a) The 115V Transfer Bus No.1 under normal conditions.

b) The Battery Bus through the Static Inverter under normal conditions.

c) The Battery through the Static Inverter with a failure of both engine driven generators.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 172



183. The GROUND POWER AVAILABLE light will extinguish when:

a) The GROUND POWER switch is positioned ON

b) The GROUND SERVICE switch is positioned ON

c) The AC ground power cart has been disconnected

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 33



184. For ground service, a ground service switch is placed:

a) On aft overhead panel on the Flight Deck

b) On aft attendant´s panel

c) On forward attendant´s panel

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 23



185. Illumination of the GND POWER AVAILABLE light indicates:

a) Ground power is connected and meets airplane power quality standards.

b) Ground power is connected however no airplane power quality is measured.

c) The Ground Service Bus is powered by a ground power supply.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 33



186. After the loss of all generators, a fully charged battery can furnish power to the STANDBY Bus equipment for a minimum of:

a) 30 minutes

b) 60 minutes

c) 90 minutes

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 158



187. The constant speed drive (CSD):

a) Are not use in this A/C

b) Turn the generator at variable speed

c) Turn the generator at constant speed

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 81



188. If the selected AC source powering a transfer bus fails, the transfer bus will

a) Remain unpowered

b) Powered by another AC source if aviable

c) Not give

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 91



189. With the aircraft on the ground (both engine generators on-line) and external power connected up to the aircraft, momentarily positioning the Ground Power switch to ON

a) Will trip both engine generators and connect external power to both generator busses

b) Will trip the right engine generator only and connect external power to the right generator bus

c) Will trip the left engine generator only and connect external power to the left generator bus (B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 21



190. A Generator Breaker can be closed

a) When power quality from the generator is correct.

b) Irrespective of power quality from the generator.

c) At any time the engine is running at or above idle power

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 105



191. If the No. 2 TRU fails in the cruise

a) There would be no immediate indication.

b) The Master Caution and ELEC annunciator lights would illuminate.

c) The Battery Ammeter would show a discharge.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 25



192. The Switched Hot Battery Bus is powered from

a) The Battery Bus Bar whenever the Battery Switch is ON.

b) The Battery Bus whenever the Battery Switch is OFF.

c) The Battery whenever the Battery switch is OFF.

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 164



193. DC Standby Bus power is normally supplied from

a) The Battery Bus

b) The Hot Battery Bus

c) DC Bus No. 1

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 13



194. If ground power is available and the Ground Service switch on the forward attendant's panel is switched on, then power is supplied to

a) All the aircraft electrical busses.

b) The Ground Service bus for utility outlets, cabin lighting and battery charger.

c) The Ground Service bus for utility outlets and cabin lighting only

(B2) Reference: ATA 24 Electrical Power System - B737 Training book - Page 22



ATA 25:

195. The captain and first officer seats are

a) Difference

b) Oppsite assemblies

c) Identical

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 6



196. The fight compartment seats are

a) Manually control

b) Electrically control

c) Manually and electrically control

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 6-7



197. To remove the flight crew seats

a) You must first remove stops on the inboard seat tracks, then slide the seats forward off the tracks

b) You must first remove stops on the outboard seat tracks, then slide the seats forward off the tracks

c) You must first remove stops on the outboard and inboard seat tracks, then slide the seats forward off

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 7



198. How many observer seat can be installed?

a) One observer seat

b) Two observer seats

c) Three observer seats

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 9



199. The first and second observer seats are

a) Adjustable seats

b) Non-adjustable seats

c) Identical

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 9



200. In passenger cabin the service outlets provide

a) 115 Volt ac

b) 28 Volt dc power

c) 115 Volt ac and 28 Volt dc power

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 11



201. The lowered ceiling panels are installed in

a) Entry areas and lavatories

b) Entry areas and galleys

c) Entry areas, galleys and lavatories

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 14



202. Fiberglass insulation blankets are

a) Thermally insulates the passenger compartment

b) Acoustically insulates the passenger compartment

c) Thermally and acoustically insulates the passenger compartment

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 14-15



203. Roll shades are

a) Over all the passenger windows

b) Over the windows in the emergency exit hatches

c) Over all the flight compartment windows

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 18



204. The air return grilles

a) Let air move from the upper lobe to the lower lobe for normal conditioned air circulation

b) Let air move from the upper lobe to the lower lobe for air circulation during rapid decompression

c) Let air move from the upper lobe to the lower lobe for normal conditioned air circulation or air (B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 19



205. The passenger service units provide

a) Emergency oxygen and advisory information

b) Emergency oxygen and call switches

c) Emergency oxygen, advisory information and call switches

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 21



206. How to open the passenger service units?

a) Insert a small allen wrench or other applicable tool into the latch release hole, then lower the service

b) Push the passenger service units up to release the latch, then lower the service unit

c) Remove the lanyard then lower the service unit

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 21



207. Which statement is correct about the attendant service units?

a) They provide emergency oxygen for attendants or passengers

b) They provide advisory information for attendants

c) They provide emergency oxygen and advisory information for attendants

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 23



208. Where are the windscreens installed?

a) At forward of the forward service or entry door

b) At aft of the aft entry or service door

c) At aft of the forward service or entry door or forward of the aft entry or service door

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 25



209. The Holes in the blanket

a) Will allow water into the fiber center, so reduce the blanket efficiency, increase weight, and can

b) Will allow air to circulate between the inboard side of the blanket and the sidewall lining

c) Will allow moisture to drain into the bilge drain valves

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 33



210. Emergency equipment typically includes

a) Overwing escape strap, Escape lanyards, Overwater survival equipment, Escape slides

b) Overwing escape strap, Escape lanyards, Detachable emergency equipment, Escape slides

c) Overwing escape strap, Escape lanyards, Overwater survival equipment, Detachable emergency

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 35



211. Where are the overwing escape straps?

a) In stowage tubes above each emergency exit door

b) In stowage tubes above each entry door

c) In stowage tube above the flight compartment door

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 37



212. The escape lanyard kevlar cord rated at

a) 1000 pounds

b) 1500 pounds

c) 2000 pounds

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 39



213. Where are the escape lanyard located?

a) In the stowage bag behind doors in the flight compartment lining above the number 2 windows

b) In the stowage bag above the flight compartment door

c) In the stowage bag below the second observer seat

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 39



214. Where are the escape slides installed?

a) On the lower inboard face of each entry and service door

b) On the lower inboard face of each entry and emergency exit door

c) On the lower inboard face of each entry, service and emergency exit door

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 42



215. Put the slide warning pennant across the door window when

a) The slide is armed

b) The slide is dis-armed

c) The slide is Unserviceable

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 43



216. To ARM the escape slide

a) Move the ARM-DISARM handle to ARM position

b) Remove the girt bar from the stowage hooks on the door and install it in the floor brackets

c) Remove the girt bar from the floor brackets and install it in the stowage hooks

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 45



217. If the escape slide does not inflate automatically

a) Pull the inflation handle sharply to inflate the escape slide manually

b) Push the inflation handle to inflate the escape slide manually

c) Push and pull the inflation handle to inflate the escape slide manually

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 45



218. The escape slide will fully inflate in

a) Approximately three seconds

b) Approximately six rseconds

c) Approximately ten seconds

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 45



219. The inflation cylinder pressure relief valve opens at

a) 3500 PSIG

b) 4000 PSIG

c) 4500 PSIG

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 49



220. Which equipment protects the escape slide inflation cylinder from hight temperature?

a) The fusible plug

b) The pressure relief valve

c) The frangible disk

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 49



221. What precaution should be taken when removing a door escape slide?

a) Install the safety pin

b) Remove the safety pin

c) Remove the airplane power

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 49



222. How do you check an escape slide cylinder pressure?

a) The pressure indicator

b) The pop out indicator on ACP

c) The bottle must be removed and weighted

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 49



223. How to deflate the slide after inflation test?

a) Open the pressure relief valve

b) Open the deflation valve

c) Hold the aspirator flapper valve open

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 49



224. The escape slide light system power by

a) The 28 Volts dc BAT BUS

b) The 28 Volts dc HOT BAT BUS

c) Its own battery

(B2) Reference: ATA 25 Equipments and Furnishings system - B737 Training book - Page 51



ATA 26:

225. When does the engine fire detection system is in dual loop operation?

a) The OVHT DET switch is in the A position and both loops are operating correctly

b) The OVHT DET switch is in the B position and both loops are operating correctly

c) The OVHT DET switch is in the NORMAL position and both loops are operating correctly

(B2) Reference: ATA 26 Fire protection system - B737 Training book - Page 13



226. The ENG fire detection system has

a) Two detector loops and four detector assemblies

b) Two detector loops with three detector assemblies

c) Two detector loops with two detector assemblies

(B2) Reference: ATA 26 Fire protection system - B737 Training book - Page 16



227. The ENG fire detector sense

a) Overheat, fire, fault

b) Overheat, fault

c) Fire, fault

(B2) Reference: ATA 26 Fire protection system - B737 Training book - Page 16



228. Holding the test switch in the OVHT/FIRE position with AC power will illuminate the?

a) MASTER CAUTION and OVHT/DET lights, Two red FIRE WARN lights, ENG 1, ENG 2, and APU fire handle switch lights, Amber ENG 1 and ENG 2 OVERHEAT lights

b) MASTER CAUTION and OVHT/DET lights, Two red FIRE WARN lights, ENG 1, ENG 2, and APU fire handle switch lights, Red WHEEL WELL light

c) MASTER CAUTION and OVHT/DET lights, Two red FIRE WARN lights, ENG 1, ENG 2, and APU fire handle switch lights, Amber ENG 1 and ENG 2 OVERHEAT lights, Red WHEEL WELL light

(B2) Reference: ATA 26 Fire protection system - B737 Training book - Page 21, 22



229. The two engine fire extinguishing bottles are installed in

a) The top left corner of the main wheel well

b) Right hand side of aft cargo compartment

c) Right hand side of forward cargo compartment

(B2) Reference: ATA 26 Fire protection system - B737 Training book - Page 24, 28



230. When does the BOTTLE DISCHARGED amber light on?

a) An engine fire extinguisher bottle pressure is less than 350 psi

b) An engine fire extinguisher bottle pressure is less than 300 psi

c) An engine fire extinguisher bottle pressure is less than 250 psi

(B2) Reference: ATA 26 Fire protection system - B737 Training book - Page 36



231. The APU fire detector sense

a) Overheat, fire, fault

b) Overheat, fault

c) Fire, fault

(B2) Reference: ATA 26 Fire protection system - B737 Training book - Page 46



232. The APU fire extinguishing bottle is in

a) The horizontal stabilizer accessory compartment

b) The APU compartment foward bulkhead

c) Right hand side of aft cargo compartment

(B2) Reference: ATA 26 Fire protection system - B737 Training book - Page 50, 54



233. Where is the APU ground control panel?

a) In the left main wheel well aft bulkhead

b) In the right main wheel well aft bulkhead

c) In the right main wheel well forward bulkhead

(B2) Reference: ATA 26 Fire protection system - B737 Training book - Page 50



234. When does the APU fire extinguishing bottle safety relief port break open?

a) The bottle temperature increases to 266F (130C) or bottle pressure to approximately 1800 psi

b) The bottle temperature increases to 266F (130C) or bottle pressure to approximately 1600 psi

c) The bottle temperature increases to 266F (130C) and bottle pressure to approximately 1500 psi (B2) Reference: ATA 26 Fire protection system - B737 Training book - Page 54



235. When you pull the APU fire control handle on APU ground control panel (P28)

a) The APU system stops and APU fire extinguisher bottle discharges

b) The APU
